32" POLY SPIKER/SPREADER
..................................................................4
ENGLISH..........................................................6
Without your product review, we don't exist.
Customer Care
M-F 7:00 a.m. - 5:00 p.m. CST
800-448-9282
www.agri-fab.com
the fastest way to purchase parts www.speedepart.com
45-05431
THANK YOU
FOR YOUR PURCHASE!
If you are happy with our quality products & service,
please take just a moment to leave positive feedback and
a short review of our product on our website or your retailer's website.
Not totally satisfied?
If you have any issues, don't hesitate to contact us.
We make mistakes sometimes, but please give us the chance
to make it right before leaving negative feedback against our product.
ESPAÑOL..........................................................13
FRANÇAIS.........................................................16
MADE IN
USA
WITH GLOBAL COMPONENTS
FORM NO. 45941 (09/15/2021)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 45-05431 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Agri-Fab 45-05431

  • Page 1 Want more information or assembly tips? Video Instruction Guide y o u t u b e . c o m / c / a g r i f a b 45-05431 32" POLY SPIKER/SPREADER ESPAÑOL............13 ..............4 ENGLISH............6 FRANÇAIS............16 THANK YOU FOR YOUR PURCHASE! Without your product review, we don’t exist.
  • Page 3 PARTS FOR 32" POLY SPIKER/SPREADER MODEL 45-05431 REF. PART NO. QTY. DESCRIPTION REF. PART NO. QTY. DESCRIPTION 47953 COVER, CHAIN R19171616 WASHER, .531 X 1 X .059 24743BL1 LEVER, FLOW CONTROL 43081 WASHER, .375 X .875 X .083 24747BL1 BRACE, CENTER...
  • Page 4 RULES FOR SAFE OPERATIONS Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times, when using power equipment. • Wear eye and hand protection when handling and using •...
  • Page 5 43661 44215 44180 44292 (12) 46524 741-0249 47025 47189 (13) 45100 47810 44731 43009 43182 44101 43093 47623 43019 43088 43081 1543-69 R19212016 R19171616 NOT SHOWN FULL SIZE 43848 43943 47959 712-0421 24571 47960 47777 49449 46497 47969 23520...
  • Page 6: Tools Required For Assembly

    ASSEMBLY TOOLS REQUIRED FOR ASSEMBLY • On the right side, assemble the handle brace bracket (2) 7/16" Wrenches (5) to the lift handle (9) using a 5/16" x 3/4" hex bolt (32) (2) 1/2" Wrenches and 5/16" nylock nut (27). Tighten. See figure 2. (2) 3/4"...
  • Page 7 • On the left side, insert a 5/16" x 3-1/2" hex bolt (14) • Attach the hitch brackets (13) to the hitch tubes using through the upper hole on the transport tube (10), a two 5/16" x 2" hex bolts (17) and 5/16" nylock hex nuts spacer (42), and the hitch tube.
  • Page 8 • Screw a 1/4" nylock hex nut (26) all the way onto the • Place the flow control lever into the slot in the hopper. flow control link (44). Assemble the ferrule (46) onto the See figure 9. link and then start a 1/4" nylock hex nut one or two turns •...
  • Page 9 • Move the flow control lever (2) as far as it will go to • Push a flanged bearing (22) into each side of the drive the "OFF" position. Push the feed plate back as far as it disk (8). See figure 12. will go to the closed position.
  • Page 10 • Place a large washer (38), short spacer tube (41), and • Place a 5/8" flat washer (33), the compression spring the drive disk (8) onto the shaft. Fit the short spacer tube (49) and another 5/8" flat washer onto the shaft. See and large washer onto the flanged bearing in the end figure 17.
  • Page 11: Connecting Link

    • Place two spike disks (7), separated by a long spacer • Place a 5/8" flat washer (33) onto the end of the spike tube (20), onto the shaft. Fit the long spacer tube onto the disk shaft and secure the shaft with a 1/8" x 1-1/2" cot- ends of the flanged bearings in the disks.
  • Page 12: Operation

    OPERATION SETTING CHART Flow Rate Setting MATERIAL TYPE At 3 M.P.H. HOW TO USE YOUR SPIKER/SPREADER Fertilizer Granular / Pelleted 0-1 / 1. Refer to the instruction label on the material package and to the instruction decal on your spreader to help Grass Seed Fine / Coarse 5-6 /...
  • Page 13: Reglas Para Una Operación Segura

    ESPAÑOL REGLAS PARA UNA OPERACIÓN SEGURA Cualquier equipo motriz puede causar lesiones si no se opera correctamente o si el usuario no entiende la forma de operar el equipo. Tenga siempre cuidado cuando use un equipo motriz. • Lea este manual de instrucciones con mucho cuidado antes •...
  • Page 14 • Monte el casquillo (46) en el orificio del extremo de la palanca • Coloque los cojinetes embridados (22) en ambas placas de control de flujo (2) con una tuerca hexagonal de seguridad terminales. Consulte la figura 14. de nylon de 1/4" (26). Apriete la tuerca, pero déjela lo bastante suelta como para que el casquillo pueda girar.
  • Page 15: Operación

    ESPAÑOL OPERACIÓN CUADRO DE AJUSTE MATERIAL TIPO Ajuste de la cantidad de FORMA USAR EQUIPO SURCADOR- flujo a 3 M.P.H. (4.8 kph) ESPARCIDOR Fertilizante Granular / En forma 0 - 1 0 - 2 de pelotillas 1. Lea la etiqueta de instrucciones en el paquete de materiales y la calcomanía de instrucciones en el esparcidor para Semilla Fina / Gruesa...
  • Page 16 FRANÇAIS RÈGLES DE SÉCURITÉ D’UTILISATION Tout équipement à moteur peut causer des blessures s’il est mal utilisé ou si l’utilisateur ne sait pas comment l’utiliser. Il faut faire attention en permanence pour utiliser l’équipement à moteur. et utiliser les produits chimiques de pelouse. •...
  • Page 17 • Visser un écrou nylock de 1/4 po (26) jusqu’à la tige de • Insérer un palier avec bride (22) dans chacune des plaques commande de débit (44). Assembler la ferrule (46) sur la tige d’extrémité. Voir figure 14. et puis visser un écrou nylock hexagonal de 1/4 po un ou deux tours sur la tige.
  • Page 18 FRANÇAIS FONCTIONNEMENT TABLEAU DE RÉGLAGE MATÉRIAU TYPE Réglage de débit à COMMENT UTILISER CRAMPONNEUSE/ 5 km/h (3 milles/hr) RÉPANDEUSE Fertilisant Granulaire / à boulettes 0-1 / 0-2 1. Se reporter à l’étiquette d’instructions sur l’emballage du matériau et à l’autocollant d’instructions sur la répandeuse Semence Fine / lourde 5-6 / 7-8...
  • Page 20: Repair Parts

    REPAIR PARTS Agri-Fab, Inc. 303 West Raymond Sullivan, IL. 61951 217-728-8388 www.agri-fab.com...
