KwikGoal 2F701 Assembly Instructions Manual

ASSEMBLY INSTRUCTIONS FOR 2F501 & 2F701 FIELD HOCKEY GOALS
1. Unpack all parts and check for damage that may have occurred during shipping. If damage has occurred,
notify Kwik Goal immediately. Lay out all parts. Remove all cardboard and packaging immediately. Wet or
damp packaging may damage contents.
2. Read through entire instruction before beginning assembly and installation.
NOTE: Components may be packaged in one or more additional boxes.
Left Arm (1)
( Part# SEE TABLE )
Side Board (2)
( Part# WZ1176-03
This equipment has been designed to be used for the game of field hockey only. Field equipment
must be anchored AT ALL TIMES and shall be secured against overturning. Do not climb on the net
or equipment framework at anytime! All fastenings must be checked to insure they are fully
tightened before and after each use of this product. Equipment not in use must be disassembled
and properly stored in a safe, secure area. Assembled field equipment should not be left
unattended. Remove nets when equipment is not in use. Do not use this equipment during the
threat of high winds. Field equipment must be checked for safety before and after each use. All
warning and safety labels included with this product must be visible at all times. Any modifications
to this or any Kwik Goal product will void any and all warranties.
Right Arm (1)
( Part# SEE TABLE )
GOAL #
2F501
2F701
)
***CAUTION***
140 Pacific Drive Quakertown, PA 18951
800-531-4252 Kwikgoal.com
© 2011, Rev 2021 Kwik Goal Ltd.
Crossbar (1)
( Part# SEE TABLE )
GOAL #
2F501
2F701
(A)
LEFT ARM RIGHT ARM
UZ738 UZ733
UZ877 UZ876
End
View
PART # DIM (A)
UZ734 136"
UZ875 109-3/4"
NZ261 Rev. 08/25/2021
