3. Operation

■
About the operation method, refer to the operation manual that comes with each remote controller.
3.1. Turning ON/OFF
[ON]
ON
OFF
Note:
Even if you press the ON/OFF button immediately after shutting down the operation is progress, the air conditioner will not start for about 3
minutes.
This is to prevent the internal components from being damaged.
■
Operation status memory
Operation mode
Preset temperature
Fan speed
■
Settable preset temperature range
Operation mode
Cool/Dry
Heat
Auto
Fan/Ventilation
en
7
Press the [ON/OFF] button.
The ON/OFF lamp will light up in
green, and the operation will start.
When "LED lighting" is set to "No," the
ON/OFF lamp will not light up.
* Refer to the installation manual of
wired remote controller.
Remote controller setting
Operation mode before the power was turned off
Preset temperature before the power was turned off
Fan speed before the power was turned off
Preset temperature range
19 – 30 °C, 67 – 87 °F
17 – 28 °C, 63 – 83 °F
19 – 28 °C, 67 – 83 °F
Not settable
[OFF]
Press the [ON/OFF] button again.
The ON/OFF lamp will come off, and
the operation will stop.
ON
OFF
