■ Hot start
The indoor unit prevents cold drafts when the Heating operation be-
gins.
The indoor unit fan will not operate or it will operate at a very low speed
until the heat exchanger reaches the set temperature.
■ Auto-restart function
In event of power interruption such as a blackout, the air conditioner
stops once. But it restarts automatically and performs previous operation
when the power supply is resumed.
■ Malfunctions caused by other electrical
devices
Use of other electrical appliances such as an electric shaver or nearby
use of a wireless radio transmitter may cause the malfunction of the air
conditioner.
If you encounter such a malfunction, disconnect the power supply once.
Then reconnect it, and resume operation by using the remote controller.
■ Indoor unit temperature and humidity range
Permissible ranges of temperature and humidity are as follows:
Indoor temperature Cooling/Dry
Heating
Indoor humidity
*1) If the air conditioner is used continuously for many hours, water may
condense on the surface and drip.
• If the unit is operated under the conditions except the permissible
temperature range, the air conditioner operation may stop because
of the automatic protection circuit working.
• Depending on the operating conditions, the heat exchanger may
freeze, causing water leakage or other malfunction. (in the Cooling
or Dry mode).
■ When indoor and outdoor temperatures are
high
When both indoor and outdoor temperatures are high during use of the
Heating mode, the outdoor unit's fan may stop at times.
■ Low ambient cooling
When the outdoor temperature drops, the outdoor unit's fans may switch
to low speed, or one of the fans may stop intermittently.
■ Other information
• Do not use the air conditioner for any purpose other than room
cooling/dry, room heating or fan.
• For the permissible ranges of temperature and humidity for the
outdoor unit, refer to the outdoor unit installation manual.
• During the Heating mode, the top of the indoor unit may become
warm, but this is due to the fact that coolant is circulated through the
indoor unit even when it is stopped; it is not a malfunction.

8. OPTIONAL PARTS

8.1. Wireless remote controller

The optional wireless remote controller can be used.
To check the available model of remote controller, consult authorized
service personnel.
<Restricted functions for wireless remote controller>
• Airfl ow direction setting
• Weekly timer
<Additional functions for wireless remote controller>
• Program timer
• Sleep timer
• 10 °C Heat operation
NOTE: Depending on the remote controller, some function may be
restricted. Refer to the operation manual of the remote controller
for details.
En-5
[°C] 18 to 32
[°C] 16 to 30
1)
[%] 80 or less *
You can use both wireless and wired remote controller together.
However, some functions of the wireless remote controller may be
restricted.

8.2. Wired remote controller

You can use other types of the wired remote controller.
To check the available model of remote controller, consult authorized
service personnel.
NOTE: Depending on the remote controller, some function may be
restricted. Refer to the operation manual of the remote controller
for details.

8.3. Multiple remote controller

You can connect two wired remote controllers to one air conditioner.
Either remote controller can control the air conditioner.
However, the timer functions cannot be used by the secondary unit.

8.4. Group control

One wired remote controller can control up to 16 air conditioners. All of
the air conditioners will be operated with the same settings.

8.5. Multi-split type air conditioner

This indoor unit can be connected to a Multi-split type outdoor unit. The
Multi-split type air conditioner allows multiple indoor units to be operated
in multiple locations. The indoor units may be operated simultaneously,
in accordance with their respective output.
Simultaneous Use of Multiple Units
● When using a Multi-split type air conditioner, the multiple indoor units
can be operated simultaneously, but when 2 or more indoor units of
the same group are operated simultaneously, the heating and cooling
effi ciency will be less than when a single indoor unit is used alone.
Accordingly, when you wish to use more than 1 indoor unit for cooling
at the same time, the use should be concentrated at night and other
times when less output is required. In the same way, when multiple
units are used simultaneously for heating, it is recommended that they
be used in conjunction with other auxiliary space heaters, as required.
● Seasonal and outdoor temperature conditions, the structure of
the rooms and the number of persons present may also result in
diff erences of operating effi ciency. We recommend that you try various
operating patterns in order to confi rm the level of heating and cooling
output provided by your units, and use the units in the way that best
matches your family's lifestyle.
● If you discover that 1 or more units delivers a low level of cooling or
heating during simultaneous operation, we recommend that you stop
simultaneous operation of the multiple units.
● Operation cannot be done in the following diff erent operating modes.
Heating mode and Cooling mode (or Dry mode)
Heating mode and Fan mode
● Operation can be done in the following diff erent operating modes.
Cooling mode and Dry mode
Cooling mode and Fan mode
Dry mode and Fan mode
● The operating mode (Heating mode or Cooling (Dry) mode) of the out-
door unit will be determined by the operating mode of the indoor unit
that was operated fi rst. If the indoor unit was started in the Fan mode,
the operating mode of the outdoor unit will not be determined.
For example, if indoor unit (A) was started in the Fan mode and then
indoor unit (B) was then operated in the Heating mode, indoor unit (A)
would temporarily start operation in the Fan mode but when indoor
unit (B) started operating in the Heating mode, indoor unit (A) would
go into standby mode. Indoor unit (B) would continue to operate in the
Heating mode.
