PET Lite Clip Screens
Date
Page No.
10/15/2020
1-19
Page No.
2 - 4
5-7
8-13
14-17
18-19
www.ais-inc.com
Description of change
Released
Table of Contents
Screen Installation
Surface Mount Territory and Front/Rear
Under Surface Mount Territory and Front/Rear
Oxygen – Under Surface Mount Territory
Aloft – Under Surface Mount Territory and Front/Rear
Freestanding
C-LTCLIPINSTALL Revision 10.15.2020
Name
S. Powers
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AIS PET Lite
Summary of Contents for AIS PET Lite
- Page 1 PET Lite Clip Screens Date Page No. Description of change Name 10/15/2020 1-19 Released S. Powers Table of Contents Page No. Screen Installation 2 - 4 Surface Mount Territory and Front/Rear Under Surface Mount Territory and Front/Rear Oxygen – Under Surface Mount Territory 8-13 Aloft –...
- Page 2 Surface Mount PET Lite Clip Screens Territory and Front/Rear Item Replacement Circle Sheet Description Image Part number Part Number RA-PETUMT RA-PETUMT Lite Clip #6 X 1” Long RH-01071946 RH-01071946 Flat Head Screw www.ais-inc.com C-LTCLIPINSTALL Revision 10.15.2020...
- Page 3 Surface Mount PET Lite Clip Screens Territory and Front/Rear Step 1: Install clips to surface using #6 x 1” long flat head screws. #6 x 1” long Flat head screw 2 places per bracket As desired Lite Clip Surface Mount 24 –...
- Page 4 Surface Mount PET Lite Clip Screens Territory and Front/Rear Step 2: Carefully position screen in clips. Use a rubber mallet and a block of wood to gently tap the top of the PET screen until the screen is fully seated at the bottom of the clips.
- Page 5 Under Surface Mount PET Lite Clip Screens Territory and Front/Rear Item Replacement Circle Sheet Description Image Part number Part Number RA-RETUMC RA-RETUMC Lite Clip Under Surface Mounting Bracket RH-QS0978 RH-QS0978 Flat Head Screw #9 x 7/8” Long www.ais-inc.com C-LTCLIPINSTALL Revision 10.15.2020...
- Page 6 Under Surface Mount - Front/Rear PET Lite Clip Screens Step 1: Install clips to surface using #9 x 7/8” long flat head screws. Lite Clip Under Surface Mount 24 – 54W use 2 clips 60 – 72W use 3 clips...
- Page 7 Under Surface Mount - Front/Rear PET Lite Clip Screens Step 2: Carefully position screen in clips. Use a rubber mallet and a block of wood to gently tap the top of the PET screen until the screen is fully seated at the bottom of the clips.
- Page 8 Oxygen- Under Surface Mount PET Lite Clip Screens Territory Item Replacement Circle Sheet Description Image Part number Part Number RA-PETUMCR (right) RA-PETUMCR Territory Under Mount RA-PETUMCL (left) (right) Rear Bracket Left/Right RA-PETUMCL (left) OX-SLSBMB OX-SLSBMB Territory Screen Back Mounting Bracket...
- Page 9 Oxygen- Under Surface Mount PET Lite Clip Screens Territory - End Step 1: Install rear under mount brackets. Territory Under Mount Rear Brackets Left/Right (left hand shown) Rear of Surface Territory Screen Back Mounting Bracket #9 x 7/8” long ¼-20 x 5/16 inch...
- Page 10 Oxygen- Under Surface Mount PET Lite Clip Screens Territory - End Step 2: Install front under mount brackets. Territory Under Mount Front Bracket #9 x 7/8” long Flat head screw #2 Philips drive 2 places per bracket Step 3: Install lite clip brackets.
- Page 11 Oxygen- Under Surface Mount PET Lite Clip Screens Territory - End Step 4: Carefully position screen in clips. Use a rubber mallet and a block of wood to gently tap the top of the PET screen until the screen is fully seated at the bottom of the clips.
- Page 12 Oxygen- Under Surface Mount PET Lite Clip Screens Territory - Shared Step 1: Install front and rear under mount brackets. Territory Under Mount Front Center Bracket Front Surface #9 x 7/8” long Flat head screw #2 Philips drive 2 places per bracket...
- Page 13 Oxygen- Under Surface Mount PET Lite Clip Screens Territory - Shared Step 2: Install lite clip brackets. #6-32 x ¼” long Flat Head Screw Lite Clip Bracket #2 Philips drive 2 places 2 places per bracket Step 3: Carefully position screen in clips. Use a rubber mallet and a block of wood to gently tap the top of the PET screen until the screen is fully seated at the bottom of the clips.
- Page 14 Aloft - Under Surface Mount PET Lite Clip Screens Territory and Rear/Front Item Replacement Circle Sheet Description Image Part number Part Number RA-PETUMCF RA-PETUMCF Territory Under Mount Front Bracket RH-QS0978 RH-QS0978 Flat Head Screw #9 x 7/8” Long RA-PETUMT RA-PETUMT Lite Clip #6-32 X ¼”...
- Page 15 Aloft - Under Surface Mount PET Lite Clip Screens Territory Step 1: Install two territory under mount brackets. Territory Under Mount Front Brackets 2 places #9 x 7/8” long Flat head screw #2 Philips drive #6-32 x ¼” long 2 places per bracket...
- Page 16 Aloft - Under Surface Mount PET Lite Clip Screens Territory Step 3: Carefully position screen in clips. Use a rubber mallet and a block of wood to gently tap the top of the PET screen until the screen is fully seated at the bottom of the clips.
- Page 17 Aloft - Under Surface Mount PET Lite Clip Screens Rear/Front Step 1: Install clips to surface using #9 x 7/8” long flat head screws. Lite Clip Under Surface Mount 24 – 54W use 2 clips 60 – 72W use 3 clips 78W and longer use 4 clips #9 x 7/8”...
- Page 18 Freestanding PET Lite Clip Screens Item Replacement Circle Sheet Description Image Part number Part Number RP-SP12 RP-SP12 Freestanding Foot RA-PETUMT RA-PETUMT Lite Clip #6-32 X ¼” long RH-90273A144 RH-90273A144 Flat Head Screw RH-34ARD RH-34ARD Adhesive Rubber Dots www.ais-inc.com C-LTCLIPINSTALL Revision 10.15.2020...
- Page 19 Freestanding PET Lite Clip Screens Step 1: Assemble freestanding feet. #6-32 x ¼” long Flat Head Screw Lite Clip Bracket #2 Philips drive 2 places per bracket Freestanding Foot Adhesive Rubber Dots Step 2: Carefully position screen in clips. Use a rubber mallet and a block of wood to gently tap the top of the PET screen until the screen is fully seated at the bottom of the clips.
