Hurricane
®
Swim Jet
Installation and Operating
Instructions
Note: The Hurricane Swim Jet is not intended for use by young children or infirm persons without supervision.
Please ensure that young children as supervised to ensure that they do not play with the Swim Jet.
Please pass these instructions on to the operator of this equipment.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Davey Hurricane H300M
Summary of Contents for Davey Hurricane H300M
- Page 1 Hurricane ® Swim Jet Installation and Operating Instructions Note: The Hurricane Swim Jet is not intended for use by young children or infirm persons without supervision. Please ensure that young children as supervised to ensure that they do not play with the Swim Jet. Please pass these instructions on to the operator of this equipment.
-
Page 3: General Considerations
1. SAFETY 2. GENERAL CONSIDERATIONS 2.1. Introduction Safety warnings. The swim-against-the-current unit is a piece of The following set of symbols equipment for swimming pools that propels a large alongside a text indicates a potential hazard if the jet of water by means of an electric pump. It is appropriate instructions are not heeded. - Page 4 hold it firmly in place while the two screws (13) b) Pre-assembly, with the canvas removed from are driven into the holes A and B. (Fig. D) the panel and according to the drawing: Clean the contact surfaces between the gaskets Ensure that the rear body (3) is in correct position.
-
Page 5: Repair And Maintenance
Connections, trunks and branch connections must always be housed in IMPORTANT INFORMATION: Your Davey pump is leaktight boxes. Double Insulated to Water Circuit. If equipotential bonding Installation and assembly must be entrusted to structure is required, then a Equipotential Bonding Point is provided. - Page 6 6. POSSIBLE PROBLEMS, CAUSES AND SOLUTIONS PROBLEMS CAUSES SOLUTIONS – Water flow is – Recirculation of water. – Test the right components assembly and insufficient – Maximum flow of the pump is small. especially the joint. – Verify the right pump sizing. –...
- Page 7 Fig. 2 Main components of the panel or fibreglass structure. Part Description DIN 7982 Ø4,8x45 DIN 965 M5x30 DIN 7982 Ø5,5x16 Ø63-Ø63 Ø63-2"...
- Page 8 Fig. A Fig. B Fig. C Fig. F Fig. D Fig. E Fig. G Fig. H Fig. I Fig. J...
- Page 9 Fig. K 5XEEHU JDVNHW MANUAL DE INSTRUCCIONE Fig. L Fig. M Fig. N Fig. O Flow valves...
- Page 10 Fig. P Wiring diagram Single-phase control cabinet Three-phase control cabinet Fig. R Fig. S Fig. Q Maximum Medium flow Minimum...
-
Page 11: Dimensions And Weights
Fig. 3 Fig. 4 Interior part of the swimming pool Interior part of the swimming pool 7. DIMENSIONS AND WEIGHTS MODEL WEIGHT (kg) Kit NCRL... - Page 12 To the fullest extent permitted by law Davey disclaims any warranties regarding the accuracy, completeness or reliability of App data. Davey is not responsible for any direct or indirect loss, damage or costs to the User arising from its reliance on internet connectivity.
