Self Oscillation Driver Circuit for MZB1001T02
Sample Drive Circuit P/N:
•
This product is a sample for evaluation purposes only.
Do not use this drive circuit in your finished product.
Murata will not be liable for any claims if the sample drive circuit is shipped into the market.
• Please note that Murata doesn't guarantee the performance and reliability of our pump with this circuit. We
recommend using the drive circuit outlined in the MZB1001T02 specification for guaranteed performance.
•
Appearance
Vdc input（GND）
Vdc input（＋）
•
Spec.
V1.3
MZBD002
Operating Voltage
8～ 21Vdc
Output (No polarity）
Output (No polarity）
Operating condition
Room temperature,
Normal pressure
