Please read these User Instructions carefully before operating your wheelchair! Failure
to follow these instructions can result in serious personal injury and/or damage to the
wheelchair! This is a type-approved medical device. Alterations to the construction or
electronics will void the warranty and the product liability.
If you have questions or difficulties, please contact your dealer or:
Hersteller:
LEVO AG
Anglikerstrasse 20
CH-5610 Wohlen
Tel: +41 (0)56 618 44 11
office@levo.ch
www.levo.ch
LEVO AG
A
NGLIKERSTRASSE
S
CH-5610 W
WITZERLAND
User Manual
LEVO Summit MA
20
T
EL
F
OHLEN
AX
Vertreter:
+41 (0)56 618 44 11
+41 (0)56 618 44 10
@
.
OFFICE
LEVO
CH
.
.
WWW
LEVO
CH
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Summit MA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Levo Summit MA

Summary of Contents for Levo Summit MA

  • Page 1 User Manual LEVO Summit MA Please read these User Instructions carefully before operating your wheelchair! Failure to follow these instructions can result in serious personal injury and/or damage to the wheelchair! This is a type-approved medical device. Alterations to the construction or electronics will void the warranty and the product liability.

  • Page 2: Table Of Contents

    4. Warranty ............................9 5. General Information for Stand-up Wheelchairs ..............10 6. Benutzerprofil - LEVO Summit MA .................... 11 7. Important Safety Information before operating LEVO Summit MA ........12 8. Initial commissioning ........................14 8.1. Check armrest function ......................14 8.2.
  • Page 3 11.4.1. Raising up ........................20 11.4.2. Adjusting the armrests - raising or lowering ............21 11.4.3. Pull both front release levers and lift the armrests. Release the front release levers and continue to lift the armrests until they click securely into place (see illustrations below).
  • Page 4 15.4. 8 Activating the Brakes ....................... 33 15.5. Picking up objects ........................ 33 15.6. Transfer sideways ......................... 34 15.7. Detachable components ..................... 34 16. Transport ............................35 16.1. Transport in a motor vehicle - wheelchair only ............. 35 16.2. Transport of a user in a motor vehicle ................35 16.3.
  • Page 5 LEVO strongly recommends that wheelchair users a) fully acquaint themselves with the instructions for their device b) always have access to 3rd-party assistance in case of emergency. LEVO AG EU SRN: CH-MF-000008751 The EU Authorized Representative for the MDR (EU) 2017/745 is: be-on-Market GmbH, Lilienstrasse 33, D-91244 Reichenschwand.

  • Page 6: Eu - Declaration Of Conformity

    1. EU - Declaration of Conformity...

  • Page 7: Product Identification - Product Label

    The device is absolutely identified by the serial number and the extended barcode GS1-128. The following is an example of the LEVO serial number plate or sticker: Bedeutung Visuelle Identification Example...

  • Page 8: Meaning Of Symbols

    3. Meaning of symbols Read the instruction manual carefully before using your wheelchair. Read these instructions carefully before using your wheelchair. Failure to do so can result in serious injury and/or damage to the wheelchair. Anchorage points for tie-down the wheelchair only for transportation. Symbol of a wheelchair which is not used as a seat in a motor vehicle or to transport in a motor vehicle.

  • Page 9: Warranty

    Any structural or technical changes on the chair are prohibited and will void all warranty or product liability claims. Please notify your dealer and LEVO of any warranty claim or possible issues with your chair. LEVO contact information can be found on the first page of this manual.

  • Page 10: General Information For Stand-Up Wheelchairs

    We would like to thank you for putting your trust in LEVO and our product. The LEVO Summit standing wheelchair is a unique aid for use by those with the inability to stand and/or walk on their own. As well as performing all the functions of a lightweight wheelchair, the LEVO enables you to stand up on command.

  • Page 11: Benutzerprofil - Levo Summit Ma

    You are often on the move and need a maneuverable compact wheelchair with an integrated manual standing function that provides you with optimal support in every situation at work or in your free time. The LEVO Summit MA is the ideal partner for people weighing up to 125 kg.

  • Page 12: Important Safety Information Before Operating Levo Summit Ma

    Regarding visual and cognitive skills, the physician, therapist or dealer must decide whether the LEVO Summit MA is suitable for the user in terms of physical condition, personal safety and on the intended environment and use.
  • Page 13 Please note that all product safety information can be obtained on our website, from your dealer and in the user manuals which will be available at your retailer. In case of product recalls you will be informed by your retailer, as the LEVO products are sold exclusively through retailers.

  • Page 14: Initial Commissioning

    8. Initial commissioning 8.1. Check armrest function • Make sure that the armrests lock into place in every position and cannot be moved. • To do this, press the small front lever on the armrest and move it to the next locking position.

  • Page 15: Rear Wheel Inspection

    8.3. Rear wheel inspection The LEVO Summit MA is equipped with quick release rear axles that allow the wheels to be removed and replaced for transport or storage needs. To attach or take off the rear wheels, press the •...

  • Page 16: Standing Stability Inspection

    8.5. Standing stability inspection The wheelchair can be brought into the standing position using the long rear operating lever on the armrests. It is important to sit in the wheelchair when doing this and never to operate these levers when the chair is empty in order to avoid the risk of injury from the catapult-like movement.

  • Page 17: Knee Support And Chest Strap

    9. Knee support and chest strap Two very important safety features of a standing wheelchair are the knee support and the chest strap. It is essential to position yourself securely and comfortably before attempting to stand. Caution: Be mindful to carry out each step carefully before standing. If not done, the possibility of injury is greatly increased.

  • Page 18: Chest Strap

    9.2. Chest strap The chest strap secures the upper body in place as the chair rises to the standing position. The straps wrap around the backrest tubes and are adjoined to one another with two adjustment rings (see picture). Weaving in and out of the rings, the straps can be lengthened or shortened adapting to different size clients.

  • Page 19: Safety Information For Standing

    Please take care to avoid any pinching or squeezing of the client or attendant. To insure standing stability and avoid risk, the LEVO Summit MA must be located on flat and level surfaces with the brakes engaged. Be certain to check for objects which would prevent the legrests from reaching the ground simultaneously preventing solid contact.

  • Page 20: Aufstehmechanismus

    11. Aufstehmechanismus 11.1. The LEVO Summit MA is equipped with two-hand operation as standard. The two armrests to the left and right of the seat serve as armrests and are part of the stand-up mechanism. 11.2. There are two levers on both sides. The longer more in the rear (image 1) release the gas springs, which you can pull to easily push yourself up on the armrests toward standing.

  • Page 21: Adjusting The Armrests - Raising Or Lowering

    11.4.2. Adjusting the armrests - raising or lowering 11.4.3. Pull both front release levers and lift the armrests. Release the front release levers and continue to lift the armrests until they click securely into place (see illustrations below). Image 3 11.4.4.

  • Page 22: Gas Springs

    11.6. Gas Springs The gas pressure springs are set to keep your weight approximately at the floating point. With the help of minimal arm force support, i.e. by gently pushing off the armrests, you can stand up or sit down again effortlessly by gently pulling on the armrests.

  • Page 23: Correct Seated And Standing Positions

    12. Correct seated and standing positions Correct seated and standing positions must be evaluated by your LEVO dealer and the chair should be adjusted for the proper fit. If you should feel uncomfortable in any position, please do not hesitate to contact your LEVO dealer.
  • Page 24 Correct seating position Seat cushion too high Back adjustment too low Back cushion Seat cushion Cushion for pressure relief Backrest cushion or solid in seated position back for more comfort or stability Back Spine cushion Hyper (physiological) lordosi Hyper Seat extended cushion spine...

  • Page 25: Seating Adjustments

    13. Seating adjustments All LEVO wheelchairs are tailored to the specific anatomical dimensions of the client. The completed order form dictates how the chair is to be built. The chair is delivered with those pre-sets. In addition, many features can be further customized as the chair is fitted to the client.

  • Page 26: Footrest Adjustment

    13.2. Footrest adjustment The height of the footrest is important for proper positioning both seated and standing. The footrest is set according the lower leg length of the client and will come pre-set from the factory as specified on the order form. However, if necessary it can be adjusted. There is a choice of different heights for mounting the footrest.

  • Page 27: Backrest Height

    13.3. Backrest height The backrest height is easily adjustable. To do so, modify both the right and left backrest tubes. Begin by removing the backrest upholstery and • the uppermost tension adjustable hook and loop strap. Remove the button head screw on the backrest •...

  • Page 28: Calf / Heel Strap

    The Velcro fasteners keep the cushion positioned correctly both seated and standing. Please remember that the thickness of the seat cushion will have an effect on the set to footplate length and standing positioning as well. Please consult your LEVO dealer with any additional questions.

  • Page 29: Components

    10bar/600-1000 KPa. 14.1.1. Quick-release axle The LEVO Summit EL is equipped with quick release rear axles that allow the wheels to be removed and replaced for transport or storage needs. To attach or take off the rear wheels, press the •...

  • Page 30: General Information On The Use Of A Wheelchair

    15. General Information on the Use of a Wheelchair 15.1. Driving the wheel chair: How to avoid tipping over Please note that when starting pushing the wheel chair, the front wheels are going to lose traction due to acceleration. Depending on weight distribution this may cause the wheels to lift off the ground and the wheel chair to tip over backwards.

  • Page 31: Gradients

    15.2. Gradients Bear in mind that, when turning around on a steep hill, you will pass through a crosswise position first before the turn is completed. Whilst in the crosswise position, there is a risk of slipping sideways down the hill. Both you and any assisting person should be aware of this risk and counter steer accordingly.
  • Page 32 To descend a major obstacle (e.g. to go down stairs), always use an assistant! The assistant should first tilt the wheelchair until the front wheels are off ground slightly, then move the chair forwards slowly. Should you have to be carried over certain obstacles, please make sure to request the assistance of at least two persons.

  • Page 33: Activating The Brakes

    15.4. 8 Activating the Brakes When using the wheelchair in situations where increased stability is particularly important, the brakes must be activated. This is especially important when standing up, transferring into your wheelchair or when you want to transfer yourself from the wheelchair into another seat.

  • Page 34: Transfer Sideways

    15.6. Transfer sideways Drive as close as possible to the object you wish to transfer to. • Put on the brakes • Flip up the footrest of the wheelchair and put your feet on the ground. • Transfer yourself in your usual way out of the wheelchair or have yourself transferred •...

  • Page 35: Transport

    16.3. Public transport of the wheelchair - wheelchair only The LEVO Summit MA can be transported in every kind of public transportation without any restrictions. For airplanes there are Instructions which have to be followed. 16.3.1. Transport of the wheelchair in an airplane - wheelchair only According to IATA Regulation 2.3.2.4 the wheelchair can be transported as checked...

  • Page 36: Maintenance And Functional Check

    17. Maintenance and Functional check To keep the LEVO Summit MA running perfectly and to ensure personal safety and proper operation, please ensure your wheelchair is being serviced by your local LEVO dealer at least once a year and observe the following rules: •...

  • Page 37: Functional Check

    Please make sure that the wheelchair is being maintained at least once a year by your LEVO dealer to assure and to guarantee the safe functioning of the chair. The LEVO Summit MA is delivered already greased. Additional greasing should only be carried out professionally by your dealer.

  • Page 38: Cleaning

    Disinfection by professionals or trained staff 19. Storage 19.1. Storage in general The LEVO LAE is equipped with a folding backrest which allows you to reduce significantly space required to store. • Grasp the cord in with one hand and twist (not pull) to release the back locking pins.

  • Page 39: Storage For More Than 4 Months

    20. Disposal • At the end of its service life the wheelchair should be returned to your LEVO dealer for proper disposal. • Used batteries should also be returned to your LEVO dealer or to the place...

  • Page 40: Technical Information

    21. Technical Information Min. Max. 35.5” / 900 mm 39.5” / 1005 mm Overall Length (with footplate) 22” / 560 mm 28” / 710 mm Overall Width 31.5” / 800 mm 36.5” / 930 mm Folded Length (without wheels) 19” / 480 mm 25”...

  • Page 41: Trouble Shooting

    • Caution: There is no safety of stability in • Leg supports don’t rest standing position! Levo dealer must check and on the ground in the adjust the rear wheel axle mounting, front uppermost standing fork and leg supports.

  • Page 42: Stand-Up Mechanism

    22.2. Stand-up mechanism Fault Rectification • Mechanism works only • Recharge batteries very slowly • Have batteries replaced • Mechanism doesn’t always • Check gas spring strength corresponds to user function at the same body weight. If needed replace gas springs. speed, i.e.

  • Page 43: Versionen Management

    23. Versionen Management Versionsnr. Datum Beschreibung Freigabe Entwurf 2021-06-15 Entwurf 2022-01-06 Separated according to ISO 7176-15 Abschnitt 3.9 2022-10-18 Draft TÜV Test 2024-08-01 Adjustments acc. to 12183-14/22...
