1. General Safety Instructions....................................................................................... 2
1.1 SAFETY: General Safety ......................................................................................... 2
1.2 SAFETY: General Power Safety ............................................................................... 4
2. Exploded view diagram with list of items ................................................................ 5
3. Wiring connectivity diagram ..................................................................................... 8
5. Mechanical Instruction ............................................................................................ 11
5.1 Disassembly Procedures: .................................................................................... 12
5.2 Assembly Procedures: ......................................................................................... 17
6. Trouble shooting instructions ................................................................................ 21
Model No.: G2724D
Regulatory model: G2724Dc
Content Index
Service Manual
Dell G2724D
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G2724D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dell G2724D

Summary of Contents for Dell G2724D

  • Page 1: Table Of Contents

    4. How to connect and disconnect power cable/ connectivity cable ......9 5. Mechanical Instruction .................... 11 5.1 Disassembly Procedures: ..................12 5.2 Assembly Procedures: ..................17 6. Trouble shooting instructions ................21 Model No.: G2724D Regulatory model: G2724Dc  ...

  • Page 2: General Safety Instructions

    IMPORTANT NOTICE FOR USE IN HEALTHCARE ENVIRONMENTS: Dell products are not medical devices and are not listed under UL or IEC 60601 (or equivalent). As a result, they must not be used within 6 feet of a patient or in a manner that directly or indirectly contacts a patient 1.1 SAFETY: General Safety...
  • Page 3 pool or in a wet basement.  Do not use AC powered equipment during an electrical storm. Battery powered devices may be used if all cables have been disconnected.  Do not spill food or liquids on your equipment.  Before you clean your equipment, disconnect it from the electrical outlet. Clean your device with a soft cloth dampened with water.

  • Page 4: Safety: General Power Safety

     Be sure to grasp the plug, not the cable, when disconnecting equipment from an electric socket. If your equipment uses an AC adapter:  Use only the Dell provided AC adapter approved for use with this device. Use of another AC adapter may cause a fire or explosion.

  • Page 5: Exploded View Diagram With List Of Items

    Exploded view diagram with list of items  ...
  • Page 6 Description Q’ty Remark LOGO DELL DECO_BEZEL L27W-Fdell2-p2 BEZEL_BTM SPONGE LCD M270DAN08.CU0 (S02) SZ AUO MIDDLE_FRAME L27W-Fdell2-p2 KEY_POWER KEY BOARD SCREW Q2 2.5 KEY BOARD KEY_FUNCTION INSULATING SHEET 205.5*131.9*26.49 For EMEA Only, SCREW M3 8 not for other ADAPTER BOARD :...
  • Page 7 See “NOTE" NOTE: For replacement of power cord, connectivity cable and external power supply (if applicable), contact Dell: 1. Go to https://www.dell.com/support. 2. Verify your country or region in the Choose A Country/Region drop-down menu at the bottom-right corner of the page.

  • Page 8: Wiring Connectivity Diagram

    Wiring connectivity diagram FFC 1 Wire 1 Wire 2 Wire 5 Wire 4 Wire 3  ...

  • Page 9: How To Connect And Disconnect Power Cable/ Connectivity Cable

    How to connect and disconnect power cable/ connectivity cable  ...
  • Page 10  ...

  • Page 11: Mechanical Instruction

    NOTE: This “Disassembly and Assembly Procedures” is for EMEA only, not for other regions. Please note that Dell will deem warranty void if any disassembly is done on the monitors. Tools Required List the type and size of the tools that would typically can be used to disassemble the product to a point where components and materials requiring selective treatment can be removed.

  • Page 12: Disassembly Procedures

    5.1 Disassembly Procedures: Step Figure Remark Turn off power, unplug S1.Before external cables from disassemble product Lay down the MNT on a cushion. S2.Remove the STAND-BASE ASS’Y Use a Philips-head screwdriver to push the button to remove the stand-base ass’y. ...

  • Page 13: Rear Cover

    Use a Philips-head screwdriver to remove 4 screws for unlocking mechanisms (No.1~4 screw size=M4x10; Torque: 12±2kgf.cm) S3.Remove the REAR COVER Use Penknife to seperate rear cover follow the arrows in sequence, then you can take out rear cover. Disconnect the pins to remove the connectors.
  • Page 14 Turn over the mainframe, disconnect the FFC cable. Remove the mylar Use a Philips-head screwdriver to remove 9 screws for unlocking the main board, power board and converter S5. Remove the board. main board， (No.1~9 screw size=M3x6, power board and Torque=6±...
  • Page 15 S6. Remove the Remove the mainframe Mainframe Use a Philips-head screwdriver to remove 9 S7. Remove the screws for unlocking the Panel and middle middle frame frame (No.1~9 screw size=M3x4, Torque=3± 0.5kgf.cm) S8. The Panel Use a Philips-head screwdriver to remove 5 screws to remove the S9.Remove the DECO_BEZEL.
  • Page 16 Use a Philips-head screwdriver to remove 2 screws for disassembling the deco bezel. ( No.1~2 screw size=Q2x2.5, Torque=0.9± 0.3kgf.cm) S10. Remove the DECO BEZEL and Use a Philips-head KEY BOARD screwdriver to remove 3 screws for unlocking the key board ( No.1~3 screw size=Q2x2.5, Torque=0.9±...

  • Page 17: Assembly Procedures

    5.2 Assembly Procedures: Step Figure Remark Use a Philips-head screwdriver to lock 2 screws for tightening the deco bezel. ( No.1~2 screw size=Q2x2.5, Torque=0.9± 0.3kgf.cm) S1.Assemble the DECO BEZEL and Use a Philips-head KEY BOARD screwdriver to lock 3 screws for tightening the key board.
  • Page 18 Use a Philips-head screwdriver to lock 9 screws to assemble the he middleframe and the panel. (No.1~9 screw size=M3x4 Torque=3± 0.5kgf.cm) Connect the connectors S4.Assemble the main board, power board and converter board.  ...
  • Page 19 Use a Philips-head screwdriver to lock 9 screws for locking the main board, power board and converter board. (No.1~9 screw size=M3x6, Torque=6± 1kgf.cm Paste the mylar. Connect the FFC cable. Connect the pins S5. Connect the connectors and paste the tapes Paste 4 pieces of aluminum...
  • Page 20 Connect the pins. S6.Assemble the REAR COVER Assemble the rear cover. Use a Philips-head screwdriver to lock 4screws for rear cover (No.1~4 screw size=M4x10; Torque: S7.Assemble the 12±2kgf.cm) Stand Assemble the stand- base ass’y.  ...

  • Page 21: Trouble Shooting Instructions

    6. Trouble shooting instructions  ...
  • Page 22  ...
  • Page 23  ...
  • Page 24  ...
