SLOPING ROOF SHED
1530mm wide x 1080mm depth x 1830mm - 1770mm high
BEFORE YOU BEGIN:
To avoid any confusion with your new shed build, we
strongly suggest that you unpack and identify each
part before you begin to put it together.
ASSEMBLY
INSTRUCTIONS
YOU SHOULD HAVE ONE PACKAGE:
• 1 cardboard package
TOOLS REQUIRED:
• Battery or electric drill
• 3.3mm (1/8th inch) drill bit
• Screwdriver or riveter
• Tape measure
• Ladder
• Non-slip gloves, good shoes and goggles
• A set of helping hands
DOWNLOAD THE
STORITE APP
Some parts have sharp edges and should be handled very carefully.
We recommend the use of protective gloves and footwear when assembling.
DO NOT attempt to erect this shed in windy weather. All dimensions are approximate.
2
THIS SHED
WAS PROUDLY
PACKED BY:
Please quote this code
for any correspondence
back to the supplier
CALL 0508 454 873
for an installer near you
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Storite rite 2
Summary of Contents for Storite rite 2
- Page 1 • Non-slip gloves, good shoes and goggles • A set of helping hands DOWNLOAD THE STORITE APP Some parts have sharp edges and should be handled very carefully. We recommend the use of protective gloves and footwear when assembling. CALL 0508 454 873 DO NOT attempt to erect this shed in windy weather.
-
Page 2: Components Checklist
COMPONENTS CHECKLIST Please check the parts carefully and advise immediately if any are damaged or missing. 1 x 1770mm x 780mm door sheet 1 x narrow 1830mm x 715mm sheet 2 x 1770mm x 780mm sheets for front wall beside door for back wall 2 x 1200mm x 780mm sheets 2 full and 2 half 1830mm - 1770mm... -
Page 3: Door Assembly
STEP 1 DOOR ASSEMBLY YOU WILL NEED 1 x 1770mm x 780mm door sheet Attach the 780mm 'U' channels to the top and bottom of the door sheet 2 x 1770mm 'U' channels for door sides at the centre ribs only. Attach the 1770mm 'U' channels to the door sheet 2 x 780mm 'U' channels (door top through the top and bottom channels... -
Page 4: Front Wall
STEP 3 FRONT WALL YOU WILL NEED 2 x 1515mm 'U' channels Lay out the door with the sheet attached and the corner door jamb with the 2 x 793mm door spacers 'U' channel attached . (as shown below). Cap the sheets with the 1515mm 1 x 1830mm x 715mm sheet channels . - Page 5 STEP 4 BACK WALL YOU WILL NEED 2 x 1770mm x 780mm sheets Join the two sheets together with 2 fixings through the overlapping ribs, 2 x 1515mm 'U' channels making sure the ends of the sheets are flush. Cap the sheeting with the 1515mm 'U' channels Fix the channels through the end ribs and every second rib in between.
- Page 6 STEP 6 END WALLS YOU WILL NEED 2 x 1830mm - 1770mm end walls Cap the sloping sheets with the 1035mm 'U' channels . Fix the channels 2 x 1035mm 'U' channels per side through the end ribs and every second rib in between. Make sure you put at least two fixings up through the underside of the channel into the pan of the sheet.
-
Page 7: Installation
STEP 8 INSTALLATION SIDE WALL ASSEMBLY BUILDING YOUR SHED • Stand up the back wall and as your helping hand is holding it up, bring the left end wall in to meet it at the left corner (diagram 1) overlapping the corners The basic task is to join the sheets (diagram 2). - Page 8 Available from your local Mitre 10 store. sku:295563 FLAT FLOOR CLAMPS INTERNAL DIMENSIONS For existing concrete only. Water FOR THE RITE 2: can seep underneath. Available from your local Mitre 1485MM X 1035MM 10 store. sku:295564 KITSET WOODEN FLOORS Every shed must have a floor.
