Ventilador de Techo de 1,3 m
Acabado en Bronce Tono Petróleo
4 Aspas Reversibles (Color Arce/Bronce Tono Petróleo)
Juego de Luces de Vidrio de Corte Rectangular
Incluye Control Remoto de Funcionamiento Completo

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CF452BR-H25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HAMPTON BAY CF452BR-H25

  • Page 1 Ventilador de Techo de 1,3 m Acabado en Bronce Tono Petróleo 4 Aspas Reversibles (Color Arce/Bronce Tono Petróleo) Juego de Luces de Vidrio de Corte Rectangular Incluye Control Remoto de Funcionamiento Completo...
  • Page 3: Lifetime Limited Warranty

    Hampton Bay Lifetime Limited Warranty The retailer warrants the fan motor to be free from defects in workmanship and Date purchased material present at time of shipment from the factory for a lifetime after the date of purchase by the original purchaser. The retailer also warrants that all other fan...
  • Page 4: Table Of Contents

    Safety Rules Unpacking Your Fan Installing Your Fan Hanging the Fan Make the Electric Connections Finishing the Installation Attching the Fan Blades Installing the Light Kit Operating Your Transmitter Care of Your Fan Troubleshooting Specifications Table of Contents...
  • Page 5: Safety Rules

    1. To reduce the risk of electric shock, ensure electricity has been 7. Do not operate reversing switch while fan blades are in motion. turned off at the circuit breaker or fuse box before beginning. Fan must be turned off and blades stopped before reversing blade direction. 2.
  • Page 6: Unpacking Your Fan

    Set of blades (4) Light kit 13. Loose parts bag containing: Canopy assembly Glass shade a. Blade attachment hardware Ball/downrod assembly Receiver+6 wire nuts (9 screws and paper washers) 10. Transmitter b. Mounting hardware & extra downrod (1) 10A. Mounting plate with 2 mounting ( 3 plastic wire connectors) Collar cover screws...
  • Page 7: Tools Required

    Tools Required Angled ceiling maximum Pr ovi de st rong P h i l l i p s s c r e w d r i v e r , s t r a i g h t s l o t 20 angle sup por t screwdriver, adjustable wrench, step ladder,...
  • Page 8: Hanging The Fan

    Hanging the Fan UL Listed WARNING electrical FAILURE TO PROPERLY INSTALL LOCKING to turn off the power. Follow the REMEMBER PIN AS NOTED IN STEP 7 COULD RESULT IN steps below to hang your fan properly: Ceiling Washers Step 6. Tighten two set screws on top of the fan mounting Step 1.
  • Page 9: Make The Electric Connections 5

    settings will operate the fan as long as the Pin in Lead wires locked transmitter and receiver are set to the same position Ball/downrod position.(Figure 7) assembly Step 1. (Figure 8) Insert the receiver into Code switch the mounting bracket with the flat side Ceiling of the receiver facing the ceiling.
  • Page 10: Finishing The Installation

    Finishing the Installation SUPPLY CIRCUIT Outlet box Step 1. Tuck connections neatly into ceiling Ground Hanger outlet box. Conductor bracket BLACK Step 2. Remove one screw from the hanger Outlet Box Screw bracket and loosing the other one screw around Green 1/4″...
  • Page 11: Attaching The Fan Blades

    The following procedure should correct Attaching the Fan WARNING most fan wobble. Check after each step. TO REDUCE THE RISK OF PERSONAL INJURY, Blades DO NOT BEND THE BLADE HOLDERS 1. Check that all blade and blade bracket WHILE INSTALLING, BALANCING THE screws are secure.
  • Page 12: Installing The Light Kit

    Step 4. Place the 2 CFL bulbs into the Light kits. REMEMBER to disconnect the power. The fan blades must already be attached to the Step 5. Install the glass shade to the switch fan. housing with 1 nut,1 washer and finial provided. Your fan and light kit though pre-wired have (Figure 15) Plug...
  • Page 13: Operating Your Transmitter 9

    Restore power to ceiling fan and test for Speed settings for warm or cool weather depend on factors such as the room size, proper operation. ceiling height, number of fans, etc. 1. " LOW, MED, HI" buttons: The Reverse switch is located on top of the These three buttons are used to set the fan motor assembly.
  • Page 14: Care Of Your Fan

    Here are some suggestions to help you maintain your fan Installing the battery: 1. Because of the fan's natural movement, some connections may become loose. Install 9 volt battery (not included), to Check the support connections, brackets, and blade attachments twice a year. prevent damage to transmitter, remove Make sure they are secure.
  • Page 15: Troubleshooting 11

    Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. 3. Check to make sure the dip switches from the transmitter and receiver are set to the same frequency. Fan sounds noisy.
  • Page 16: Specifications

    0.23 1800 9 kgs 9.6 kgs 0.39 3500 1.67 High 0.52 5055 12.Specifications...
