ADJUSTING THE TEMPERATURE LIMITER AND WATER FLOW ON THE VALVE

The limiter on the valve can be set to allow partial or full access to hot water by limiting how far the

handle can be turned to the hot side of the valve. The limiter is typically set at the factory to allow only

warm water to pass through the valve. Follow the directions in this section if you wish to adjust the

amount of hot water that is allowed through the valve.

1. Unscrew and remove the handle assembly (F) and

escutcheon (E) from the valve body (D).

2. Remember the position of the stop ring (1) on

the cartridge assembly (L). Remove the stop

ring (1) from the cartridge assembly (L).
