Summary of Contents for Physio Logic ProScan
- Page 1 Model: 016-660...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Features ................2 Introduction ................3 Advantages of temporal artery (T.A.) temperature ....4 Safety precautions ..............5 Important notes..............6 Appearance, configuration and menu functions ....7 • Choosing the temperature unit of measure • Audio alert set-up •... -
Page 3: Features
FEATURES • Non-contact thermometer • Instant readings (1 second) • Professional accuracy and reliability • Easy to use • Multi-usage: body, surface and air • Programmable alerts • 3 languages + silent mode for taking temperature when child is sleeping •... -
Page 4: Introduction
. This means accurate, reliable and safe readings in an instant. As with any thermometer, it is essential to use the ProScan Non-Contact Thermometer properly to ensure accurate temperatures. Intended Use: This non-contact IR thermometer is designed for body temperature measurement without contacting the human body. -
Page 5: Advantages Of Temporal Artery (T.a.) Temperature
ADVANTAGES OF TEMPORAL ARTERY (T.A.) TEMPERATURE The ProScan Non-Contact Thermometer has been designed to produce an instant forehead temperature reading without any contact with the temporal artery. As this artery is quite close to the surface of the forehead skin, it allows precise reading of temperature. -
Page 6: Safety Precautions
SAFETY PRECAUTIONS • This device may be used for professional purposes or for personal home use. It must only be used for the purposes described in this instruction manual. • This device must only be used in an ambient temperature range of between 10°C and 40°C. -
Page 7: Important Notes
IMPORTANT NOTES • This thermometer is calibrated and ready to use. • The reliability of the reading cannot be guaranteed if the body temperature is measured over any part of the body that is not the forehead temporal region. • Body temperature increases by 0.5°C between 6:00 AM and 3:00 PM. -
Page 8: Appearance, Configuration And Menu Functions
APPEARANCE, CONFIGURATION AND MENU FUNCTIONS Choosing the Temperature Unit of Measure Note: ProScan Non-Contact default is °C. 1. When the device is “on”, press “MODE” button for 2 seconds, the screen will display “F1”. MODE ENG. FR. ESP. 2. Then press “MODE” button to switch between degree Celsius (°C) and Fahrenheit (°F). -
Page 9: Audio Alert Set-Up
Audio Alert Set-up Note: The audio alert threshold default value is 38°C (100.4°F) and is for body and surface temperature only. If the audio alerts threshold default settings are changed, only the audio alerts will be pertinent, not the colour alerts. 1. -
Page 10: Choice Of Default Display Mode: Body Or Surface Temperature
Choice of Default Display Mode: Body or Surface Temperature Note: The ProScan Non-Contact IR Thermometer default is set to BODY mode. 1. When the device is “on”, press the “MODE” button and the screen should display Body...°C, which MODE ENG. FR. -
Page 11: How To Calibrate The Thermometer
Note: If in doubt, do not modify this setting. Each time there is a significant change in the ambient temperature due to a change in environment, allow the ProScan Non-Contact Thermometer to adapt to the new ambient temperature for at least 15 minutes before using it. -
Page 12: Audio On/Off & Language Selection
Audio ON/OFF & Language Selection 1. When the device is “on” press the “ENG. FR. ESP.” button to display a choice of three languages (English, French and Spanish), MODE ENG. FR. ESP. or “Off” to close the audio. 2. To confirm selection, press the “MEM”... -
Page 13: Data Memory
DATA MEMORY 1. When the device is on, press the “MEM” button to display the last temperature and to view MODE ENG. FR. ESP. of the last 32 measurements. 2. When the device is on, press “MEM” button and hold for 5 seconds to delete memory data. -
Page 14: Temperature Reading Options
1. The ProScan Non-Contact Thermometer has been specially designed to take the body temperature. 2. You can also use the ProScan Non-Contact Thermometer to measure the temperature of an object, food (baby food, etc.) or liquid (bath water, milk bottle, etc.) 3. -
Page 15: How To Measure Temperature
HOW TO MEASURE TEMPERATURE Note: If the thermometer has been stored at a very low or very high temperature, allow the unit to adjust to room temperature for at least 15 minutes before using the device. 1. Before taking temperature readings, make sure to avoid any drafts like air conditioning, etc. -
Page 16: Cleaning & Maintenance
The protective glass over the lens is the most fragile part • ofthe thermometer. Do not touch the glass with your fingers. Do not immerse or soak your ProScan in either alcohol • or water. Do not use benzene, thinner, gasoline or other strong •... -
Page 17: Specifications
(89.6°F ~ 109.2°F) • Surface mode: 0°C - 60°C (32°F - 140°F) • Air mode: 0°C - 40°C (32°F - 104°F) Precision Note: The ProScan Non-Contact Infrared Thermometer can take temperature readings below 32°C or above 42.9°C (89.6°F - 109.2°F) but precision is not guaranteed outside of this range. -
Page 18: Troubleshooting
TROUBLESHOOTING Note: If you have one of the following problems while using your thermometer, please refer to this guide to help resolve the problem. If the problem persists and the product is still under warranty, please contact A.M.G. Medical’s Customer Service Team at 1-800-363-2381 between 8:30 AM and 5:00 PM EST. -
Page 19: Emc Declaration
EMC DECLARATION • This device should not be used adjacent to or stacked with other equipment and that if adjacent or stacked use is necessary, this device should be observed to verify normal operation in the configuration in which it will be used. •... - Page 20 Table 1 Guidance and manufacturer’s declaration on electromagnetic emissions Emmission Test Compliance RF emissions CISPR 11 Group 1 RF emissions CISPR 11 Class B Harmonic emissions IEC 61000-3-2 Not applicable Voltage fluctuations / flicker emissions IEC 61000-3-3 Not applicable Table 2 Guidance and manufacturer’s declaration on electromagnetic immunity Immunity Test IEC 60601 Test level...
- Page 21 Table 3 Guidance and manufacturer’s declaration on electromagnetic immunity Test Radiated RF Band Distance Immunity IEC 61000-4-3 Frequency Service Modulation Modulation (MHz) (MHz) (MHz) (Test specifications for ENCLOSURE TETRA Pulse 380-390 PORT IMMUNITY 18 Hz to RF Wireless communications GMRS 460 equipment) 430-470 ±...
-
Page 22: Limited Warranty
LIMITED WARRANTY The ProScan Non-Contact Thermometer is guaranteed for three years from the date of purchase. If the thermometer does not function properly due to defective components or poor workmanship,we will repair or replace it free of charge. All components are covered by this warranty excluding the battery. - Page 23 Manufactured and printed in China for: Fabriqué et imprimé en Chine pour : A.M.G. Medical Inc. 8505 Dalton, Montréal, QC H4T 1V5 Canada • 1-800-363-2381 Distributed in the USA by: Distribué aux É.-U. par : AMG Medical, Inc. 8396 State Route 9, West Chazy, NY 12992 USA •...
