Installation
1.
Turn off your computer and unplug your computer's power cord.
2.
Connect the signal cable to the DP (optional) and/or VGA (optional) and/or HDMI (optional) input socket of the
monitor, and the VGA (optional) and/or DP (optional) and/or HDMI (optional) output socket of the graphics card on
the computer. Then tighten the thumbscrews on the signal cable connector.
3.
Optional: Connect the audio input socket (AUDIO IN) of the LCD monitor and the line-out port on the computer with
the audio cable.
4.
Insert the monitor power cable into the power port at the back of the monitor.
5.
Plug the power cords of your computer and your monitor into a nearby electrical outlet.
DP
HDMI
VGA IN
----------------------------------------------------------------------------------------------------------------------------------------------------------
Note: Audio output is only for audio output model. Please check user manual for more instruction.
*POWER CORD specifications refer to page15
*For the installation of replaceable parts, please refer to the above installation instructions.
*Users may go to the local service network to replace /purchase the qualified replaceable parts.
For local service centers and service contacts, please refer to https://www.acer.com/ac/en/US/content/support
AUDIO IN
