Power Systems
Installing an NVMe Expansion Drawer -
24 devices (NED24)
IBM
GI11-9941-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NED24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IBM NED24

Summary of Contents for IBM NED24

  • Page 1 Power Systems Installing an NVMe Expansion Drawer - 24 devices (NED24) GI11-9941-00...
  • Page 2 Note Before using this information and the product it supports, read the information in “Safety notices” on page v, “Notices” on page 19, the IBM Systems Safety Notices manual, G229-9054, and the IBM Environmental Notices and User Guide, Z125–5823. ®...

  • Page 3: Table Of Contents

    Installing an NVMe Expansion Drawer - 24 devices (NED24)........1 Installing or setting up an NED24 NVMe expansion drawer...............1 Preparing the system to install or set up an NED24 NVMe expansion drawer........1 Completing inventory for installing the NED24 NVMe expansion drawer..........2 Determining and marking the location in the rack................
  • Page 4 iv  ...

  • Page 5: Safety Notices

    Das Produkt ist nicht für den Einsatz an Bildschirmarbeitsplätzen im Sinne § 2 der Bildschirmarbeitsverordnung geeignet. Laser safety information IBM servers can use I/O cards or features that are fiber-optic based and that utilize lasers or LEDs. Laser compliance IBM servers may be installed inside or outside of an IT equipment rack.
  • Page 6 • Each rack cabinet might have more than one power cord. – For AC powered racks, be sure to disconnect all power cords in the rack cabinet when directed to disconnect power during servicing. vi  Power Systems: Installing an NVMe Expansion Drawer - 24 devices (NED24)
  • Page 7 – For racks with a DC power distribution panel (PDP), turn off the circuit breaker that controls the power to the system unit(s), or disconnect the customer’s DC power source, when directed to disconnect power during servicing. • Connect all devices installed in a rack cabinet to power devices installed in the same rack cabinet.
  • Page 8 In addition, do not lean on rack-mounted devices and do not use them to stabilize your body position (for example, when working from a ladder). Stability hazard: • The rack may tip over causing serious personal injury. viii  Power Systems: Installing an NVMe Expansion Drawer - 24 devices (NED24)
  • Page 9 • Before extending the rack to the installation position, read the installation instructions. • Do not put any load on the slide-rail mounted equipment mounted in the installation position. • Do not leave the slide-rail mounted equipment in the installation position. (L002) (L003) Safety notices  ix...
  • Page 10 CAUTION: Hazardous moving parts nearby. (L008) (L018) CAUTION: High levels of acoustical noise are (or could be under certain circumstances) present. Use approved hearing protection and/ or provide mitigation or limit exposure. (L018) (L031) x  Power Systems: Installing an NVMe Expansion Drawer - 24 devices (NED24)
  • Page 11 CAUTION: Enclosure Integrity. • Access covers are intended only for occasional removal. • Follow documented procedures when opening during live or temporary service. • When service is complete, promptly reinstall all covers, lids, and/or doors for correct operation. (L031) All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class 1 laser products.
  • Page 12 Exchange only with the IBM-approved part. Recycle or discard the battery as instructed by local regulations. In the United States, IBM has a process for the collection of this battery. For information, call 1-800-426-4333. Have the IBM part number for the battery unit available when you call.
  • Page 13 Freewheeling will cause uneven cable wrapping around winch drum, damage cable, and may cause serious injury. • This TOOL must be maintained correctly for IBM Service personnel to use it. IBM shall inspect condition and verify maintenance history before operation. Personnel reserve the right not to use TOOL if inadequate.
  • Page 14 Systems: Installing an NVMe Expansion Drawer - 24 devices (NED24)

  • Page 15: Installing An Nvme Expansion Drawer - 24 Devices (Ned24)

    • If your NED24 NVMe expansion drawer arrived to your site preinstalled in a rack, continue with the step “3” on page 1. • If your NED24 NVMe expansion drawer needs to be installed into a rack, continue with step “4” on page 1.

  • Page 16: Completing Inventory For Installing The Ned24 Nvme Expansion Drawer

    Installing an extender to the rack (http://www.ibm.com/support/knowledgecenter/POWER10/ p10hbf/p10hbf_s42extender.htm). • Help to lift the NED24 NVMe expansion drawer into the rack, which requires two people. b) Determine where to install a new NED24 NVMe expansion drawer. Consider several elements that include size, security, and environmental factors. For more information, see Site preparation and physical planning (http://www.ibm.com/support/...
  • Page 17 • If you must install the NED24 NVMe expansion drawer below the system, the placement of the NED24 NVMe expansion drawer in relation to your system is important so that the cable management arm can function properly. General location information includes the following recommendations: •...
  • Page 18 Use tape, a marker, or a pencil to mark the top mounting hole of this EIA unit. c) Count up two holes and place another mark beside that mounting hole. You now have two marks on the rack, with one mounting hole between the marks. 4  Power Systems: Installing an NVMe Expansion Drawer - 24 devices (NED24)

  • Page 19: Attaching The Mounting Hardware To The Rack

    EIA rack unit. 11. If you are installing the system in a non-IBM rack with square holes, install the rail locator studs. To install the rail locator studs, complete the following steps: a.
  • Page 20 About this task To install an NED24 NVMe expansion drawer into a rack, complete the following steps. Procedure 1. Ensure that you have the electrostatic discharge (ESD) wrist strap on and that the ESD clip is plugged into a ground jack or connected to an unpainted metal surface. If not, do so now.

  • Page 21: Connecting An Ned24 Nvme Expansion Drawer To Your System

    About this task Note: If you are connecting the NED24 NVMe expansion drawer to a server in the same rack,use 3-meter copper cables. If you are connecting the NED24 NVMe expansion drawer to servers in other racks, use optical cables.
  • Page 22 Then, grasping the cover on the long edge (A) with the index finger and thumb on your other hand, pull off the protective cover as shown in the following figure. Note: Keep your fingers close to the closed end of the protective cover. 8  Power Systems: Installing an NVMe Expansion Drawer - 24 devices (NED24)
  • Page 23 12. If you have another pair of cables to connect, repeat step “11” on page 8. 13. Connect the cables to the rear of the drawer and route them through the cable-management arm. Installing an NVMe Expansion Drawer - 24 devices (NED24)  9...
  • Page 24 Close the cable-management arm. To close the cable management arm, insert the inner cable management arm tab into the outer mounting bracket until it clicks into place. The inner mounting bracket is not used. 10  Power Systems: Installing an NVMe Expansion Drawer - 24 devices (NED24)
  • Page 25 Note: Before you perform the next task, ensure that the current service operation has completed. Multiple service operations are not allowed at the same time. b. Select Serviceability > Add FRU > NED24 NVMe Expansion Drawer Connection. Installing an NVMe Expansion Drawer - 24 devices (NED24)  11...

  • Page 26: Preparing Your System For Operation After Connecting An Ned24 Nvme Expansion Drawer To Your System

    1. If the system has a rear door, close or replace it. 2. Verify that the system or logical partition recognized the NED24 NVMe expansion drawer. To verify that the system or logical partition recognizes the disk drive enclosure, see Verifying the installed part (www.ibm.com/support/knowledgecenter/POWER10/p10haj/pxhaj_hsmverify.htm).

  • Page 27: Connector Locations For Power10 Servers

    Learn about connector locations for Power10 servers. Connector locations for the 9105-22A, 9105-22B, and 9786-22H systems Learn about connector locations for the 9105-22A, 9105-22B, and 9786-22H systems. Figure 8. Connector locations for the 9105-22A, 9105-22B, and 9786-22H systems © Copyright IBM Corp. 2023...

  • Page 28: Connector Locations For The 9105-41B, 9105-42A, And 9786-42H Systems

    Connector locations for the 9105-41B, 9105-42A, and 9786-42H systems Learn about connector locations for the 9105-41B, 9105-42A, and 9786-42H systems. Figure 9. Connector locations for 9105-41B, 9105-42A, and 9786-42H systems 14  Power Systems: Installing an NVMe Expansion Drawer - 24 devices (NED24)

  • Page 29: Connector Locations For The 9043-Mrx Systems

    5887 disk drive enclosure or an ESLS storage enclosure. For more information about FC EJ0K, see PCIe3 RAID SAS quad-port 6 Gb adapter (FC EJ0K; CCIN 57B4) (http://www.ibm.com/support/knowledgecenter/POWER10/p10hcd/fcej0k.htm). Table 2 on page 16 shows the slot priorities for the FC EJ0K adapter in the 9043-MRX system.
  • Page 30 11, 8 10, 7 11, 8, 5, 10, 7, 11, 8, 5, 3, 10, 4/6/8 CXP converter 7, 4, 2 adapter (FC EJ08; CCIN 2CE2); Adapter part number: 041T9901 16  Power Systems: Installing an NVMe Expansion Drawer - 24 devices (NED24)

  • Page 31: Connector Locations For The 9080-Hex System

    Connector locations for the 9080-HEX system Learn about connector locations for the 9080-HEX system. Figure 11. Rear view of the 9080-HEX system Table 4 on page 17 shows the slot priorities for the FC EJ0M and EJ14 adapters, which support the attachment of SAS hard disk drives (HDDs) and solid-state devices (SSDs) in the 9080-HEX system.
  • Page 32 Slot priorities Node max EJ07 PCIe3 cable adapter for 1, 7, 3, 5, 2, 8, 4, 6 the PCIe3 expansion drawer (FC EJ07; CCIN 6B52); Adapter part number: 00TK704 18  Power Systems: Installing an NVMe Expansion Drawer - 24 devices (NED24)

  • Page 33: Notices

    Consult your local IBM representative for information on the products and services currently available in your area. Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property right may be used instead.

  • Page 34: Homologation Statement

    This product uses standard navigation keys. Interface information The IBM Power servers user interfaces do not have content that flashes 2 - 55 times per second. The IBM Power servers web user interface relies on cascading style sheets to render content properly and to provide a usable experience.

  • Page 35: Related Accessibility Information

    Related accessibility information In addition to standard IBM help desk and support websites, IBM has a TTY telephone service for use by deaf or hard of hearing customers to access sales and support services:...

  • Page 36: Canada Notice

    Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung von IBM verändert bzw.

  • Page 37: Japan Electronics And Information Technology Industries Association (Jeita) Notice

    Tel: +49 (0) 800 225 5426 email: HalloIBM@de.ibm.com Generelle Informationen: Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022 / EN 55032 Klasse A. Japan Electronics and Information Technology Industries Association (JEITA) Notice This statement applies to products less than or equal to 20 A per phase.
  • Page 38 Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Proper cables and connectors are available from IBM-authorized dealers. IBM is not responsible 24  Power Systems: Installing an NVMe Expansion Drawer - 24 devices (NED24)

  • Page 39: Class B Notices

    Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der IBM empfohlene Kabel angeschlossen werden. IBM übernimmt keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das Produkt ohne Zustimmung von IBM verändert bzw.
  • Page 40 This statement applies to products less than or equal to 20 A per phase. This statement applies to products greater than 20 A, single phase. This statement applies to products greater than 20 A per phase, three-phase. 26  Power Systems: Installing an NVMe Expansion Drawer - 24 devices (NED24)

  • Page 41: Terms And Conditions

    Contact for FCC compliance information only: fccinfo@us.ibm.com Terms and conditions Permissions for the use of these publications are granted subject to the following terms and conditions. Applicability: These terms and conditions are in addition to any terms of use for the IBM website. Notices  27...
  • Page 42 IBM reserves the right to withdraw the permissions granted herein whenever, in its discretion, the use of the publications is detrimental to its interest or, as determined by IBM, the above instructions are not being properly followed.
  • Page 44 IBM® Part Number: 03KG458 GI11-9941-00...
