IN240200045V02_US_CA
846-103V30_846-103V80
YF-01JY03-B
EN
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
ASSEMBLY INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 846-103V30 and is the answer not in the manual?

Questions and answers

Related Manuals for Outsunny 846-103V30

Summary of Contents for Outsunny 846-103V30

  • Page 1 IN240200045V02_US_CA 846-103V30_846-103V80 YF-01JY03-B IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY INSTRUCTIONS...

  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS 1. Read the instruction manual carefully before use and keep it for future reference. Failure to comply with the instructions can result in death, serious injury or property damage. 2. For outdoor use ONLY! Do not use indoors. 3.
  • Page 3 DANGER If you smell gas: Shut off gas to the appliance. Extinguish any open flame. Open lid. If odor continues, keep away from the appliance and immediately call your fire department. Failure to follow these instructions could result in fire or explosion which could cause property damage, personal injury or death.
  • Page 4 WARNING 1.Never leave the appliance unattended. Keep children and pets away from the appliance at all times. 2.The use of alcohol, prescription or non-prescription drugs may impair the consumer's ability to properly assemble or safely operate the appliance. 3.This appliance shall not be used on or in any apartment or condominium balcony or deck.
  • Page 6 WARNING Never leave the appliance unattended.Keep children and pets away from the apploance at all times. This appliance is not intended for and should never be used as a heater. Never operate appliance with LP tank out of correct position specified in assembly instructions.
  • Page 7 LP (Liquefied Petroleum Gas) LP gas is non toxic, odorless and colorless when produced. For your safety, LP gas has been given an odor (similar to rotten eggs) so that it can be smelled. LP gas is highly flammable and may ignite uncpectedly when mixed with air. LP Tank Filling Use only licensed and experienced dealers.
  • Page 8 Do not insert any tool or foreign objects into the valve outlet or safety relief valve. You may damage the valve and cause a leak. Leaking propane may result in exposion, fire, severe personal injury, or death. Never attempt to attach this appliance to the self-contained LP system of a camper, trailer or a motor home.
  • Page 9 If burner does not light OR if burner flame is accidentally extinguished, turn knob to OFF, wait 5 minutes, try again. If the burner does not ignite with valve open OR if burner flame accidentally extinguished after lighting, gas will continue to flow out of the burner and could accidentally ignite with risk of injury.
  • Page 10 The connection between the Check and make sure the regulator coupling nut is tightened regulator and LP to the LP tank valve. tank are not in good condition. The burner dose The LP tank valve not light up. control valve do The LP tank valve is opened in counter-clockwise direction.
  • Page 11 All cleaning and maintenance should only be done when the appliance is cool self-cleaning oven. The extreme heat will damage the finish. Correct care and maintenance will keep your appliance operating smoothly. Clean regularly as determined by the amount of use. NOTE: Clean the entire appliance each year and tighten all hardware on a regular basis (1-2 times a year or more depending on usage).

  • Page 13: Part List

    PART LIST Pic. Pic. M4 *6 screw +3(spare) M5*12 screw Top door pin Bottom door pin M3*nut M3*10 screw M3*10 self-tap screw M6*12 screw...
  • Page 14 Assembly Note: Please do not tight the screws and nuts till all assembly steps completed. F:M3 * 10 screw x 2 G:M3*10 st x 2 E:M3 nut x 2 1. Assemble the LH and RH frame plates (5C) to LH & RH legs (5A, 5B, 6A &...
  • Page 15 M5*12 Screw M6*12 Screw 2. Assemble the LH and RH frame (5&6) to bottom shelf (7) with 4pcs M5*12 screws(B).
  • Page 16 3. Assemble the back shelf (9) to the frames with 4 pcs M5 screws (B).
  • Page 17 4. Assemble the front beam (8) to the front of frames with 4pcs M5 screws (B).
  • Page 18 5. Assemble the 4pcs wheels (10&11) to the end of frame legs. Note: the 2pcs wheels with break (10) are always in the same side.
  • Page 19 B:M5*12 screw 6. The body (1) is slided into the frame legs with 8 pcs pre-assembled M5 screws (See detailed pic.). Tight screws after body slided into position. Thermometer (18) is fixed to the lid by its own screw. Note: make sure the 8pcs screws are pre-assembled before sliding.
  • Page 20 7. LH side shelf (14) is asssembled to the body with 6 pcs M5 screws (B).
  • Page 21 8. RH side shelf (15) is asssembled to the body with 6 pcs M5 screws (B).
  • Page 22 9. Handles (13) are assembled to front doors (12) with 4pcs M4 screws (A). Totally 2 pcs doors.
  • Page 23 10. Doors are assembled to frames’ front legs with top and bottom pins (C&D).
  • Page 24 11. Warming grid (2), cooking grids (3) and heat tents (4) are fixed into the body.
  • Page 25 12. Oil cup (21) is assembled to the oil pan.
  • Page 26 Outdoor Cooker Safety Precautions FAILURE TO FOLLOW THESE INSTRUCTIONS AND WARNINGS COULD RESULT IN FIRE, EXPLOSION, BURN HAZARD OR CARBON MONOXIDE POISONING WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. WARNING: This product can expose you to chemicals including lead, known to the State of California to cause cancer, birth defects, or other reproductive harm.

  • Page 27: Instructions D'assemblage

    IN240200045V02_US_CA 846-103V30_846-103V80 YF-01JY03-B IMPORTANT - CONSERVEZ CES INFORMATIONS POUR VOTRE CONSULTATION ULTÉRIEURE: LISEZ ATTENTIVEMENT INSTRUCTIONS D'ASSEMBLAGE...
  • Page 33 Vanne de la bonbonne de GLP VCapuchon de sécurité Sangle de retenue...
  • Page 35 Roue à main OPD Sortie de type 1 avec filetage à l'extérieur Soupape de sécurité Droit Capucho Maintenez l'écrou de couplage et le détendeur comme indiqué pour une connexion adéquate à la vanne de la bonbonne de GLP. Le mamelon doit être centré dans la vanne de la bonbonne de GLP.

  • Page 41: Liste Des Pieces

    LISTE DES PIECES Pic. Pic. M4 *6 Vis +3(spare) M5*12 Vis M3 Ecrou M3*10 Vis M3*10 Vis M6*12 Vis...
  • Page 42 Assemblage Remarque: Ne serrez pas les vis et les écrous avant d'avoir terminé toutes les étapes d'as- semblage. M3 * 10 Vis x 2 M3*10 st x 2 M3 Ecrou x 2 1. Assemblez les plaques de cadre gauche et droite (5C) aux pieds gauche et droit (5A, 5B, 6A et 6B) avec 8 vis M5 (B).
  • Page 43 M5*12 Vis M6*12 Vis 2. Assemblez le cadre LH et RH (5 et 6) sur l'étagère inférieure (7).
  • Page 44 3.Assemblez l'étagère arrière (9) aux cadres avec 4 vis M5 (B).
  • Page 45 4.Assemblez la poutre avant (8) à l'avant des cadres avec 4 vis M5 (B).
  • Page 46 5.Assemblez les 4 roues (10 et 11) à l'extrémité des pieds du cadre. Remarque : les 2 roues avec frein (10) sont toujours du même côté.
  • Page 47 B:M5*12 Vis 6.Le corps (1) est glissé dans les pieds du cadre avec 8 vis M5 pré- assemblées (voir photo détaillée). Serrez les vis après avoir fait gliss- er le corps en position. Le thermomètre (23) est fixé au couvercle avec sa propre vis. Remarque : assurez-vous que les 8 vis sont préassemblées avant de faire glisser.
  • Page 48 7.L'étagère latérale LH (14) est assemblée au corps avec 6 vis M5 (B).
  • Page 49 8.L'étagère latérale RH (14) est assemblée au corps avec 6 vis M5 (B).
  • Page 50 9.Les poignées (13) sont assemblées aux portes avant (12) avec 4 vis M4 (A). Au total, 2 portes.
  • Page 51 10.Les portes sont assemblées aux pieds avant des cadres avec des goupilles supérieure et inférieure (C et D).
  • Page 52 11.La grille de maintien au chaud (2), les grilles de cuisson (3) et les tentes de chaleur (4) sont fixées au corps.
  • Page 53 12. La coupelle d'huile (21) est assemblée au bac à huile.
  • Page 54 Conseils de sécurité pour le cuisinière d'extérieur AVERTISSEMENT! LE NON-RESPECT DE CES INSTRUCTIONS ET AVERTISSEMENTS PEUT ENTRAÎNER UN INCENDIE, UNE EXPLOSION, DES RISQUES DE BRÛLURES OU UN EMPOISONNEMENT AU MONOXYDE DE CARBONE, CE QUI PEUT ENTRAÎNER DES DOMMAGES MATÉRIELS, DES BLESSURES PERSONNELLES OU INDUIRE UN DANGER DE MORT.
