ONE-WAY CASSETTE TYPE

Installation Manual

SAK-06-OCT1/220V

SAK-09-OCT1/220V

SAK-12-OCT1/220V

SAK-18-OCT1/220V

SAK-06-OCT2/220V

SAK-09-OCT2/220V

SAK-12-OCT2/220V

SAK-18-OCT2/220V

IMPORTANT NOTE:

Read this manual carefully before installing

or operating your new air conditioning unit.

Make sure to save this manual for future reference.

AIR CONDITIONER

Table of Contents

Need help?

Do you have a question about the SAK-06-OCT1/220V and is the answer not in the manual?

Questions and answers

Summary of Contents for ComfortStar SAK-06-OCT1/220V

Page 1 ONE-WAY CASSETTE TYPE AIR CONDITIONER Installation Manual SAK-06-OCT1/220V SAK-09-OCT1/220V SAK-12-OCT1/220V SAK-18-OCT1/220V SAK-06-OCT2/220V SAK-09-OCT2/220V SAK-12-OCT2/220V SAK-18-OCT2/220V IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
Page 3: Table Of Contents
CONTENTS SAFETY PRECAUTIONS PRODUCT OVERVIEW PRODUCT INSTALLATION REFRIGERANT PIPING CONNECTION WIRING PRECAUTIONS AIR EVACUATION NOTE ON ADDING REFRIGERANT ELECTRICAL AND GAS LEAK CHECKS PANEL INSTALLATION TEST RUN PACKING AND UNPACKING THE UNIT...
Page 4: Safety Precautions
SAFETY PRECAUTIONS It is really important you read Safety Precautions Before Operation and Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classiﬁed as either a WARNING or CAUTION. Explanation of Symbols WARNING This symbol indicates the possibility of personal injury or loss of...
Page 5 WARNINGS FOR PRODUCT INSTALLATION Turn o the air conditioner and disconnect the power before performing any ● installation or repairing. Failure to do so can cause electric shock. Installation must be performed by an authorized dealer or specialist. Defective ● installation can cause water leakage, electrical shock, or ﬁre.
Page 6 For the units with refrigerant sensors, when the unit detects a refrigerant leak, the minimum air ow of the indoor unit is as follows: Indoor Nominal Model Indoor unit Outdoor unit air volume SAK-06-OCT1/220V 580m³/h SAK-06-OCT2/220V 342CFM 580m³/h 342CFM SAK-09-OCT1/220V SAK-09-OCT2/220V 600m³/h...
Page 7 [ft/m] inst 6.0~7.3/ c or 7.6/2.3 8.3/2.5 8.9/2.7 9.9/3.0 [oz/kg] 1.8~2.2 12/1.10 ≤62.6/1.776 63.4/1.8 60/5.53 57/5.29 53/4.87 49/4.51 44/4.06 70.5/2.0 67/6.15 64/5.88 59/5.41 54/5.01 49/4.51 77.5/2.2 73/6.76 70/6.47 65/5.95 60/5.51 54/4.96 84.6/2.4 80/7.38 76/7.06 70/6.49 65/6.01 59/5.41 91.7/2.6 86/7.99 83/7.64 76/7.03 71/6.51 64/5.86...
Page 8 1. Installation(where refrigerant pipes are allowed) - Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certiﬁcate from an industry-accredited assessment authority, which authorises their competence to handle refrigerants safely in accordance with an industry recognised assessment speciﬁcation. - Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of ﬂammable refrigerants.
Page 9 design pressure and the minimum test pressure for the high side of the system shall be the high side design pressure, unless the high side of the system cannot be isolated from the low side of the system in which case the entire system shall be pressure tested to the low side design pressure.
Page 10 NOTE Examples of leak detection ﬂuids are - bubble method, - ﬂuorescent method agents. If a leak is suspected, all naked ﬂames shall be removed/extinguished. If a leakage of refrigerant is found which requires brazing, all of the refrigerant shall be recovered from the system, or isolated (by means of shut o valves) in a part of the system remote from the leak.
Page 11 Explanation of symbols displayed on the indoor unit or outdoor unit This symbol shows that this appliance used a ﬂammable refrigerant. If the refrigerant is leaked and exposed to an WARNING external ignition source, there is a risk of ﬁre. This symbol shows that the operation manual should be CAUTION read carefully.
Page 12: Product Overview 1
PRODUCT OVERVIEW NOTE ON ILLUSTRATIONS: Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be slightly di erent. The actual shape shall prevail. Display panel Air inlet (with air ﬁlter in it) Connection cable (purchase separately) Circuit breaker Air outlet(Air ﬂow louver)
Page 13: Product Installation
PRODUCT INSTALLATION ACCESSORIES The air conditioning system comes with the following accessories. Use all of the installation parts and accessories to install the air conditioner. Improper installation may result in water leakage, electrical shock and ﬁre, or cause the equipment to fail. The items are not included with the air conditioner must be purchased separately.
Page 14: Select Installation Location
Install Your Indoor Unit Select installation location NOTE Before installing the indoor unit, you must choose an appropriate location. The following are standards that will help you choose an appropriate location for the unit. Before Installation: • Determine the route to move the unit to the installation site. •...
Page 15 Conﬁrm various sizes Installation place (unit: inch/mm) Roof Perspective A ＞19.69 in ＞19.69 in (500mm) (500mm) Wall Ceiling hole Ceiling GROUND Perspective B Wall Ceiling ＞7.87 in (200mm) air inlet air outlet Ceiling hole GROUND Indoor parts installation size (unit: inch/mm) Perspective A Perspective B 43.5in (1105mm)
Page 16: Indoor Unit Installation
Indoor Unit Installation Make sure that only speciﬁed components are used for the installation works. Model A: with circuit breaker Remove the four screws to open the indoor Connect the wire to the air breaker according ● ● control box and circuit breaker box. to the wire connecting diagram.
Page 17 Model B: with terminal Fasten and ﬁx the wire body with a tie. ● Remove the four screws to open the indoor ● control box and terminal box. Four screws Fasten and ﬁx the wire body with a tie Install the circuit breaker cover by ﬁxing the ●...
Page 18 Connect the wire to the terminal according to Install the terminal cover by ﬁxing the two screws. ● ● the wire connecting diagram. Two screws Select one to connect ground wire 2. Install the indoor air handler NOTE: After you have ﬁnished installing the main body, when choosing where to start, determine the direction of the pipes to be drawn out.
Page 19 Connecting the other side of the connecting ● cable to the wired controller. Wired controller Purchase separately For ground wire CN41 2-core wire (purchase separately) Pass a tie through the hole to ﬁx wire WARNING Please follow local regulations and take mea- sures to isloate high voltage and low voltage.
Page 20 Install Your Outdoor Unit Select installation location : PRIOR TO INSTALLATION NOTE Before installing the outdoor unit, you must choose an appropriate location. The following are standards that will help you choose an appropriate location for the unit. Proper installation locations meet the following standards: 20in (500mm) or more when front and sides of the unit are clear ...
Page 21: Install Drain Joint
Install drain joint Base pan hole of outdoor unit Step 1： Find out the base pan hole of outdoor unit. Seal Step 2： Fit the rubber seal on the end of the drain joint that will connect to the ● outdoor unit.
Page 22: Anchor Outdoor Unit
Anchor Outdoor Unit WARNING WHEN DRILLING INTO CONCRETE, EYE PROTECTION IS RECOMMENDED AT ALL TIME. The outdoor unit can be anchored to the ground or to a wall-mounted bracket with bolt(M10). Prepare ● the installation base of the unit according to the dimensions below. The following is a list of di erent outdoor unit sizes and the distance between their mounting feet.
Page 23 If you are installing the outdoor unit on the ground,or a concrete mounting platform,use the following steps: 1. Mark the positions for four expansion bolts based on dimensions in the Mounting Dimensions chart and illustrations above. 2.Pre-drill holes for expansion bolts. 3.Clean concrete dust away from the holes.
Page 24: Drainpipe Installation
Drainpipe Installation The drainpipe is used to drain water away from the unit. Improper installation may cause unit and property damage. CAUTION: Before installing a wall-mounted unit,make sure that the wall is made of solid brick, concrete, or a similarly strong material. The wall must be able to support at least 4 times the weight of the unit. Insulate all piping to prevent condensation, which could lead to water damage.
Page 25 • To prevent the pipe from sagging, space hanging wires every 39-59in (1-1.5m). • If the outlet of the drainpipe is higher than the body’s pump joint, provide a lift pipe for the exhaust outlet of the indoor unit. The lift pipe must be installed no higher than 20.8in (53cm) from the drain port on the cassette and the distance between the unit and the lift pipe must be less than 11.8in (30cm) .
Page 26: Refrigerant Piping Connection
REFRIGERANT PIPING CONNECTION When connecting refrigerant piping, DO NOT let substances or gases other than the speciﬁed refrigerant enter the unit. The presence of other gases or substances will lower the unit’s capacity, and can cause abnormally high pressure in the refrigeration cycle. This can cause explosion and injury.
Page 27: Connection Instructions-Refrigerant Piping
Connection Instructions—Refrigerant Piping CAUTION • The branching pipe must be installed horizontally. An angle of more than 10° may cause malfunction. • DO NOT install the connecting pipe until both indoor and outdoor units have been installed. • Insulate both the gas and liquid piping to prevent condensation. Step 1: Cut pipes Pipe Reamer...
Page 28: Step 4: Connect Pipes
PIPING EXTENSION BEYOND FLARE FORM CAUTION Pipe Tightening Ensure to wrap insulation around the piping. Flare shape Flare dimension(A) gauge torque Direct contact with the bare piping may result in burns or frostbite. Ø1/4in 0.33~0.34in (8.4~8.7mm) Ø6.35mm • Make sure the pipe is properly connected. (180-200kgf.cm) Over tightening may damage the bell 32-39 N.m...
Page 29: Wiring Precautions
WIRING PRECAUTIONS WARNING BEFORE PERFORMING ANY ELECTRICAL WORK, READ THESE WARNINGS. All wiring must comply with local and national To avoid getting an electric shock, never ● ● electrical codes, regulations and must be installed touch the electrical components soon by a licensed electrician.
Page 30: Outdoor Unit Wiring
NOTE ON CIRCUIT BREAKER When the maximum current of the air conditioner is more than 16A, a circuit breaker or leakage protection switch with protective device shall be used (purchased seperately). When the maximum current of the air conditioner is less than 16A, the power cord of air conditioner shall be equipped with plug (purchased seperately).
Page 31: Indoor Unit Wiring
INDOOR UNIT WIRING 1. Prepare the cable for connection 4. Connect the u-lugs to the terminals. a. Using wire strippers, strip the rubber jacket Match the wire colors/labels with the labels on from both ends of the signal cable to reveal the terminal block.
Page 32: Air Evacuation 3
AIR EVACUATION NOTICE When opening valve stems, turn the hexagonal wrench until it hits against the stopper. Do not try to force the valve to open further. Close the Low Pressure side of the manifold Preparations and precautions gauge, and turn o the vacuum pump. Wait for 5 minutes, then check that there Air and foreign matter in the refrigerant circuit has been no change in system pressure.
Page 33: Note On Adding Refrigerant 3
NOTE ON ADDING REFRIGERANT CAUTION DO NOT mix refrigerant types. Some systems require additional charging depending on pipe lengths. In North America, the standard pipe length is 25ft (7.5m). The refrigerant should be charged from the service port on the outdoor unit’s low pressure valve.
Page 34: Electrical And Gas Leak Checks 3
ELECTRICAL AND GAS LEAK CHECKS WARNING – RISK OF ELECTRICAL SHOCK ALL WIRING MUST BE INSTALLED BY A LICENSED ELECTRICIAN AND COMPLY WITH LOCAL, STATE, AND NATIONAL ELECTRICAL CODES. Gas Leak Checks There are two di erent methods to check for gaseous leaks.
Page 35: Panel Installation
PANEL INSTALLATION Step1: Prepare and install ceiling ST3.9*16 screw Drill 16.93in x51.18in (430 mm x 1300 mm ) ● hole into the ceiling based on the layout of the installation board. The centre of the ceiling opening should match the centre of the body of the indoor unit.
Page 36 Install the control box cover and turn the palstic buckle ● circuit breaker to ON, then close the two plastic covers on both sides of the panel. Manually rotate the air deﬂector, ﬁx the panel ● to the cassette by using 3×M4*22 screws and a ST3.9*16 screw.
Page 37 Install the control box cover and turn the ● circuit breaker to ON, then close the two plastic covers on both sides of the panel. Open the cover with display panel, loosen the ● screw and remove the cover. Re-install the air grille by pushing the latchto ●...
Page 38: Test Run 3
TEST RUN CAUTION Failure to perform the test run may result in unit damage, property damage, or personal injury. Before test run NOTE: If the unit malfunctions or does not operate according to your expectations, A test run must be performed after the entire please refer to the Troubleshooting section system has been completely installed.
Page 39: Packing And Unpacking The Unit
Packing and unpacking the unit Instructions for packing and unpacking the unit: Unpacking: Indoor unit: 1. Cut the sealing tape on the carton with a knife, one cut on the left, one cut in the middle and one cut on the right. 2.Use the vice to take out the sealing nails on the top of the carton.
Page 40 The design and speci cations are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. Any updates to the manual will be uploaded to the service website, please check for the latest version. QS002I-T2(B)-FKJ(R454B) 16122000A79746...
