SCHEMATIC DIAGRAM
WA R R A N T Y P O L I C Y
Your power supply has been tested and conforms to our rigid requirements on
performance and durability. It is guaranteed to be free of original factory defects for
a period of two years from the date of purchase. For the first three months, you get
full coverage at absolutely no charge. For the remaining 21 months, a nominal
service charge is required to cover mailing and handing.
Four Linear
Regulated Supplies
Instruction
Manual
Model XP-581A
Elenco
®
Electronics, Inc.
150 Carpenter Ave. • Wheeling, IL 60090
(847) 541-3800 • www.elenco.com • e-mail: elenco@elenco.com
REV-C
753249
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Elenco Electronics XP-581A
Summary of Contents for Elenco Electronics XP-581A
- Page 1 Regulated Supplies Instruction Manual Model XP-581A WA R R A N T Y P O L I C Y Your power supply has been tested and conforms to our rigid requirements on performance and durability. It is guaranteed to be free of original factory defects for Elenco ®...
- Page 2 INTRODUCTION SPECIFICATIONS (continued) The Model XP-581A is a solid-state DC power supply. It contains four fully Line Regulation Less than 100mV for each output regulated power supplies. Three fixed voltage supplies are +5VDC @ 3A, Ripple Less than 10mV rms for each output +12VDC @ 1A, –12VDC @ 1A.
