IPT-2CH
Smart
Temperature
Controller
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPT-2CH and is the answer not in the manual?

Questions and answers

Related Manuals for Inkbird IPT-2CH

Summary of Contents for Inkbird IPT-2CH

  • Page 1 IPT-2CH Smart Temperature Controller Manual...
  • Page 2 QR code below to visit our official website for product usage videos. For any usage issues, please feel free to contact us at support @inkbird.com. Wenn Sie eine Bedienungsanleitung in deutscher Sprache benötigen, scannen Sie bitte den QR-Code und besuchen Sie unsere Website, um sie zu erhalten und ein Video über...
  • Page 3 Warm tips To quickly jump to a specific chapter page, click on the relevant text on the contents page. You can also use the thumbnail or document outline in the top left corner to quickly find a specific page.

  • Page 4: Table Of Contents

    Contents INTRODUCTION CAUTION Features Technical Parameters Product Layout APP CONTROL Download The App Pair With Your Phone Add Devices in SmartConfig Mode Add Devices in AP Mode OPERATING INSTRUCTIONS Factory Reset Quick Query of The Start Heating Temperature Quick Setup of The ControllingTemperature Temperature Unit Setting Start Heating Temperature of P1 (ST1) Stop Heating Temperature of P1 (SP1)

  • Page 5: Introduction

    INTRODUCTION CAUTION KEEP CHILDREN AWAY TO REDUCE THE RISK OF ELECTRIC SHOCK, USE ONLY INDOORS DO NOT PLUG INTO ANOTHER RELOCATABLE POWER TAPS OR AN EXTENSION CORD USE ONLY IN DRY LOCATION Features Plug-n-Play, easy to use. Dual relay control, controls two sets of outputs. Users can set different target temperatures according to different environments.

  • Page 6: Product Layout

    Temperature Measurement Range: -5.0℃~50.0℃ Temperature Measurement Range: -5.0℃~50.0℃ /23.0℉~122℉ /23.0℉~122℉ Temperature Display Accuracy: 0.1℃/℉ (T<100℃/℉), Temperature Display Accuracy: 0.1℃/℉ (T<100℃/℉), 1℃/℉ (≥100℃/℉) 1℃/℉ (≥100℃/℉) Temperature Measurement Accuracy: ±1℃/±2℉ Temperature Measurement Accuracy: ±1℃/±2℉ Temperature Unit: Celsius ℃ or Fahrenheit ℉ Temperature Unit: Celsius ℃ or Fahrenheit ℉ Operating Ambient Temperature: -20℃~60℃/-4℉~140℉...

  • Page 8: Add Devices In Smartconfig Mode

    Tap “+” or “add device” in home page of the APP to add devices. If the controller is in the normal working state, you can hold for 2 seconds to reset the Wi-Fi network, the device will enter the Smartconfig state by default, short press to switch between the Smartconfig mode and the AP mode.

  • Page 9: Add Devices In Ap Mode

    How to make indicator slowly blink Connect Now Confirm indicator slowly blink Go back to the app and click “Done” when the device is successfully connected to the Wi-Fi network. Then you can set and control the device via InkBird Pro app.
  • Page 10 Device Name IPT-2CH Probe1 Current Temperature of Probe1 ℉ 69.3 Start Heating Temperature of Probe1 77.0 ℉ 78.0 ℉ Stop Heating Temperature of Probe1 Probe2 Current Temperature of Probe2 ℉ 78.6 Start Heating Temperature of Probe2 77.0 ℉ 78.0 ℉...
  • Page 11 Setting Temperature Unit ℃ ℉ Temperature Unit Switch Alarm Sound ON/OFF Alarm Sound Setting Temperature Setting temperature 77.0℉ 78.0℉ Start Heating Stop Heating High Temperature High Temperature Alarm Value 86.0℉ Alarm Value Low Temperature 82.0℉ Low Temperature Alarm Value Alarm Value Temperature 0.0℉...

  • Page 12: Operating Instructions

    OPERATING INSTRUCTIONS Factory Reset Unplug the controller, then hold and plug in the power cord to reset the controller. Display before the factory reset Display after the factory reset Note: The buzzer will beep a short sound to remind you that all the parameters have been restored to the default data.

  • Page 13: Quick Query Of The Start Heating Temperature

    Quick Query of The Start Heating Temperature For example, the start heating temperature of P1 is 77.0°F and the stop heating temperature is 78.0°F; the start heating temperature of P2 is 80.0°F, and the stop heating temperature of P2 is 82.0°F. The device displays the stop heating temperature of P1 and P2 by default.

  • Page 14: Quick Setup Of The Controllingtemperature

    Quick Setup of The Controlling Temperature For example, the start heating temperature of P1 is 77.0°F and the stop heating temperature is 78.0°F; the start heating temperature of P2 is 80.0°F, and the stop heating temperature of P2 is 82.0°F. Press once, then the P1 SET TEMP 77.0 (the start heating temperature value) will flash.

  • Page 15: Temperature Unit Setting

    Press to adjust the start heating temperature value. Press once, then the P2 SET TEMP 82.0 (the stop heating temperature value) will flash. Press to adjust the stop heating temperature value. The controller will save the settings and exit automati- cally if there’s no operation in 30 seconds, or you can hold for 2 seconds to exit settings manually.

  • Page 16: Start Heating Temperature Of P1(St1)

    Press to select between ℃ and ℉. Note: The buzzer will beep a short sound to remind you that all the parameters have been restored to the default data. The controller will save the settings and exit automati- cally if there's no operation in 60 seconds, or you can hold for 2 seconds to exit settings manually.

  • Page 17: Stop Heating Temperature Of P1(Sp1)

    Stop Heating Temperature of P1(SP1) Hold for 2 seconds and press once again to enter the setting menu, then select SP1. Short press to adjust the setting values, hold to adjust the setting values quickly. ， The controller will save the settings and exit automati- cally if there's no operation in 60 seconds, or you can hold for 2 seconds to exit settings manually.

  • Page 18: High Temperature Alarm Of P1(Ah1)

    High Temperature Alarm of P1(AH1) Hold for 2 seconds and press once again to enter the setting menu, then select AH1. Short press to adjust the setting values, hold to adjust the setting values quickly. For example 84.0℉ The controller will save the settings and exit automati- cally if there's no operation in 60 seconds, or you can hold for 2 seconds to exit settings manually.

  • Page 19: The Setting Of The P1 Calibration Value(Ca1)

    Short press to adjust the low temperature alarm value, hold to adjust the setting values quickly. For example 78.0℉. The controller will save the settings and exit automati- cally if there's no operation in 60 seconds, or you can hold for 2 seconds to exit settings manually.

  • Page 20: Start Heating Temperature Of P2(St2)

    Short press to adjust the setting values, hold to adjust the setting values quickly. ， The controller will save the settings and exit automati- cally if there’s no operation in 60 seconds, or you can hold for 2 seconds to exit settings manually. The current temperature of P2 is 74.3℉.

  • Page 21: Stop Heating Temperature Of P2(Sp2)

    The controller will save the settings and exit automati- cally if there’s no operation in 60 seconds, or you can hold for 2 seconds to exit settings manually. When the current temperature of P2 is less than or equal to the start heating temperature of P2, WORK2 will turn on the output and the heating symbol will light up.

  • Page 22: High Temperature Alarm Of P2(Ah2)

    Note: The minimum temperature difference value between ST2 and SP2 is 0.3℃/0.5℉. When both values of ST2 and SP2 are larger than or equal to 100℉, the minimum temperature difference value is 1.0℉. High Temperature Alarm of P2(AH2) Hold for 2 seconds and press once again to enter the setting menu, then select AH2.

  • Page 23: Low Temperature Alarm Of P2(Al2)

    Note: If ALM = ON, the buzzer will sound Bi-Bi-Biii when the high temperature alarm is triggered, and it will stop when the temperature returns to normal. You can also press any button to manually cancel the alarm. Low Temperature Alarm of P2(AL2) Hold for 2 seconds and press once again to...

  • Page 24: The Setting Of The P2 Calibration Value(Ca2)

    The Setting of The P2 Calibration Value(CA2) Hold for 2 seconds and press once again to enter the setting menu, then select CA2. Short press to adjust the setting values, hold to adjust the setting values quickly. ， The controller will save the settings and exit automati- cally if there's no operation in 60 seconds, or you can hold for 2 seconds to exit settings manually.

  • Page 25: Temperature Display

    Press to choose ON or OFF. The controller will save the settings and exit automati- cally if there's no operation in 60 seconds, or you can hold for 2 seconds to exit settings manually. Temperature Display The screen display when both probe1 and Probe2 are not inserted.

  • Page 26: Technical Assistance And Warranty

    If you require assistance, please write to us at support@inkbird.com. We will reply to your emails in 24 hours from Monday through Saturday. You can also visit our website www.inkbird.com to find the answers to the common technical questions.
  • Page 27 Annex 1: Setting Parameters Setting Range Default Icons Display Function Setting Temperature Unit Setting 0.0℃～45.0℃ 25.0℃ Start Heating Temperature 1 32.0℉~113.0℉ 77.0℉ 0.0℃～45.0℃ 26.0℃ Stop Heating Temperature 1 32.0℉~113.0℉ 78.0℉ High 50.0℃ -5.0℃～50.0℃ Temperature 23.0℉~122℉ 122℉ Alarm Value 1 0.0℃ -5.0℃～50.0℃...

  • Page 28: Fcc Requirement

    FCC Requirement changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired...

  • Page 29: Troubleshooting Guide

    Troubleshooting Guide Issues Causes Solutions Can not 1. Incorrect 1. In the phone settings, all permissions for the INKBIRD app are turned on. connect phone The Bluetooth and location functions of the to WIFI. settings. phone are turned on. 2. Incorrect 2.
  • Page 30 1. The heater power used is within the 250W limit. If the limit is exceeded, it may damage output settings. the IPT-2CH. Due to the low power of the will not 2. Incom- heater, it may take time to heat up, please be turn on.
  • Page 31 1. The heater power used is within the 250W limit. If the limit is exceeded, it may damage output settings. the IPT-2CH. Due to the low power of the will not 2. heater heater, it may take time to heat up, please be turn off.
  • Page 32 1. The heater power used is within the 250W limit. If the limit is exceeded, it may damage output settings. the IPT-2CH. Due to the low power of the will not 2. heater heater, it may take time to heat up, please be turn off.
  • Page 33 Shenzhen Inkbird Technology Co., Ltd. support@inkbird.com Consignor: Shenzhen Inkbird Technology Co., Ltd. Office Address: Room 1803, Guowei Building, No.68 Guowei Road, Xianhu Community, Liantang, Luohu District, Shenzhen, China Manufacturer: Shenzhen Inkbird Technology Co., Ltd. Factory Address: Room 501, Building 138, No. 71, Yiqing Road, Xianhu Community, Liantang Street, Luohu District, Shenzhen, China V8.0...
