- Page 1 All manuals and user guides at all-guides.com Ethernet Controller Setup Ver. 3...
- Page 2 All manuals and user guides at all-guides.com SETUP Equipment needed Power adapter Ethernet cable gland Access point (not provided) Ethernet cable (not provided) Ethernet controller LEDs e.g. TWPRO250STP Unboxing - controller ethernet box TWPRO1000ETHP-Bxx 1x Power adapter 1x Ethernet controller 1x Ethernet cable gland...
- Page 3 All manuals and user guides at all-guides.com SETUP Connect to thecontroller to an access point STEP 1 - Connect one side of the ethernet cable Option A - to the access point using an open port (not WAN) Note: connect WAN port to internet cable in case you want to control remotely Option B - to a network switch and...
- Page 4 All manuals and user guides at all-guides.com SETUP Connect to thecontroller to an access point STEP 2 – Connect the other side of the ethernet cable to the controller IP65 ethernet cable setup (you can skip this step if you use indoor)
- Page 5 All manuals and user guides at all-guides.com SETUP Connect the power adapter to the controller CAUTION! Keep the cap closed when the ethernet cable is not connected Close tightly to prevent water infiltration...
- Page 6 All manuals and user guides at all-guides.com SETUP Connect and switch on the strings STEP 4 – Connect the strings to the controller Note: for easier installation, we recommend to create your installation before connecting strings to the controller. In case of multiple controllers repeat steps 1 to 4 for each controller! STEP 5 –...
- Page 7 All manuals and user guides at all-guides.com ENJOY Scan the QR code to download the TwinklyApp Decorate like a boss!
- Page 8 All manuals and user guides at all-guides.com If you need any further information, please feel free to contact us: sales@pro.tw inkly.com...
