■ Main Features
Outline of product
The LV-HD420 and LD-X420 are a part of the LV Series projectors featuring a maximum brightness of 4200
lumens from its compact body. Offering two different resolutions to choose from, these DLP projectors can be used
in a variety of scenes.
1. Maximum brightness of 4200 lumens
These are single-chip DLP projectors that offer a brightness of 4200 lumens, which
is considered a high brightness in portable category projectors.
2. Two models with different resolutions – 1080p and XGA
Native resolutions for the models are: 1920 x 1080 dots for the LV-HD420 and
1024 x 768 dots for the LV-X420. The two different resolution models enable users
to choose from a variety of applications and scenes.
3. An array of interfaces
Video signals can be received from different sources such as PC and Blu-ray
players as these projectors provide a range of input terminals from mini Dsub 15 to
HDMI and RCA.
DLP Projector
LV-HD420/LV-X420
LV- HD420/X420 (1/7)
Advertisement
Related Manuals for Canon LV-HD420
Summary of Contents for Canon LV-HD420
- Page 1 ■ Main Features Outline of product The LV-HD420 and LD-X420 are a part of the LV Series projectors featuring a maximum brightness of 4200 lumens from its compact body. Offering two different resolutions to choose from, these DLP projectors can be used in a variety of scenes.
- Page 2 AC100 - 240 V 50Hz/60Hz Consumed power Standard: 410W / Quiet: 320W, Standby Low: 2.0W / Standby Off: 0.5W Picture element <LV-HD420> 0.65-type DMD device (aspect ratio 16:9) Number of pixels: 2073600 pixels (1920 dots x 1080 dots, 1080, Full HD) <LV-X420 >...
- Page 3 ■ External dimensions diagram (Unit: mm) (Note) The above diagrams are not drawn to scale. ■ Part Names 1. Lamp Cover 2. IR Receiver（Also on the rear side） 3. Lens 4. Focus Ring 5. Zoom Ring 6.Function Keys LV- HD420/X420 (3/7)
- Page 4 <Terminals> (Unit: mm) 1. AC IN Power Input 2. RJ-45 Network connection 3. Mini jack 12V output (trigger for screen operation) 4. HDMI HDMI input 5. RCA Video input 6. HDMI/MHL HDMI/MHL input 7. 2RCA Audio input(L/R) 8. Mini jack Audio input(*1) 9.
- Page 5 H is the vertical height of the image, and Hs indicates the distance between the optical axis of the lens and the bottom edge of the image. For this projector the relationship between H and Hs is fixed: LV-HD420 H:Hs=100：15 LV-X420 H:Hs=100：14 Image size and throw distance are as indicated below.
- Page 6 Yes： Compatible frequency —： Incompatible frequency Notes: Native resolution of LV-HD420 is 1920 x1080. Native resolution of LV-X420 is 1024 x 768. Resolution other than native resolution will appear when the text or line size is irregular. DVD player is used as a primary verification tool for HDTV timing, and VG828 for the second verification tool.
-
Page 7: Replacement Lamp
■ Accessories Projector LV-RC11 Power source: DC 3.0V (uses CR2025 battery) Remote Operating range: Distance of approx. 5 m from the projector; Controller angle of ±15° in any direction from directly in front of the infrared remote receiver. Carrying Case LV-SC02 Soft carrying case for the LV Series projectors Replacement...
