Kohler ENGLEFIELD SAPPHIRE Installation Manual

Kohler ENGLEFIELD SAPPHIRE Installation Manual

Round corner sliding shower
Hide thumbs Also See for ENGLEFIELD SAPPHIRE:

Advertisement

Table of Contents

INSTALLATION GUIDE
SAPPHIRE
ROUND CORNER SLIDING SHOWER
CAUTION
It is the responsibility of the INSTALLER to ensure that the
installation complies with council and or local authority bylaws
.
Instructions, drawings, and diagrams contained in this manual
present information available at the time of printing. Although
every attempt has been made to keep them up-to-date, Kohler
Company reserves the right to implement product changes
without further notice.
1089610-A02-D 03/09/2012
Page 1
Kohler Co.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENGLEFIELD SAPPHIRE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kohler ENGLEFIELD SAPPHIRE

Summary of Contents for Kohler ENGLEFIELD SAPPHIRE

  • Page 1 Instructions, drawings, and diagrams contained in this manual present information available at the time of printing. Although every attempt has been made to keep them up-to-date, Kohler Company reserves the right to implement product changes without further notice.

  • Page 2: Before You Begin

    SAPPHIRE shower door. CAUTION: Risk of injury or product damage. Tempered glass cannot be cut. CAUTION: Before commencing installation. KOHLER strongly recommends reading these installation instructions. ATTENTION: Please install this door on an ENGLEFIELD ®...
  • Page 3 872 ± 7.5mm 872 ± 7.5mm 480mm 1000 x 1000 972 ± 7.5mm 972 ± 7.5mm 500mm 1200 x 900 872 ± 7.5mm 1161 ± 7.5mm 480mm Top rail Bottom rail 25mm Elevation Plan view 1089610-A02-D 03/09/2012 Page 3 Kohler Co.

  • Page 4: Parts Identification

    ST 4.2 x 28mm Wall retainer seal Corner cover clip Return seal Bottom roller sets* Corner cover bottom right Door panel assy right Corner cover bottom left Door edge cap Magnetic seal Door panel assy left. 1089610-A02-D 03/09/2012 Page 4 Kohler Co.

  • Page 5: Door Installation

    Install each wall retainer by aligning the holes in the retainer with the wall anchors. Secure the wall retainers wth 6 x ST 4.2 x 28 mm screws provided. ST 4.2 x 28 mm 1089610-A02-D 03/09/2012 Page 5 Kohler Co.
  • Page 6 4. Install the in ll glass Press t the in ll glass to the bottom rail. Note: Make sure that the xing holes in the glass align with the holes in the bottom rail. 1089610-A02-D 03/09/2012 Page 6 Kohler Co.
  • Page 7 If higher, try pressing the top rail onto the glass in ll panels harder. 1830 mm 1830 mm If lower, insert a wedge into the gap between the 1830 mm glass in ll panels and the top rail seal. 1089610-A02-D 03/09/2012 Page 7 Kohler Co.
  • Page 8 Press t the wall retainer seals into the wall retainer. Ensure the seals are fitted with the soft edge in contact with the face of the glass, as show in the illustration on the right hand side. Soft edge of retainer seal 1089610-A02-D 03/09/2012 Page 8 Kohler Co.
  • Page 9 (clockwise to raise the door). Once done there should be no gaps between the doors, and the top edges must be level. D) Press t the door seals onto the vertical edges of both doors. 1089610-A02-D 03/09/2012 Page 9 Kohler Co.
  • Page 10 3. In and around the bottom corners where the retainers meet the bottom rail, and behind the corner cover caps. NOTE: Allow silicone to cure for 24 hours before using shower. Apply silicone along the broken line 1089610 - C May 2009 Page 10 Kohler Co.
  • Page 11 Press t the door entry seals into the channel in the top side of the bottom rail, and the underside of the top rail. Press t all four corner covers over the corner cover clips. 1089610-A02-D 03/09/2012 Page 11 Kohler Co.

  • Page 12: Installation Instructions

    INSTALLATION INSTRUCTIONS QUICK-FIT SHOWER TRAY SHOWER ® ® SlipSafe Tray Low Profile Tray 60mm sill height 70mm sill height BEFORE YOU BEGIN NOTE: Building requirements can vary, local regulations must be checked prior to installation. NOTE: Drawings in this document are not to scale. A) SHOWER TRAY &...
  • Page 13 QUICK-FIT SHOWER TRAY INSTALLATION INSTRUCTIONS Wall retainer extrusions or door must be installed prior to tiling. IMPORTANT Please refer to installation instructions provided with shower door. Fig. 2 - Wet Area Wall Board & Tiles - Method 1 WET AREA WALL BOARD (9-10 mm) GROUT TILES TILE ADHESIVE...
  • Page 14 QUICK-FIT SHOWER TRAY INSTALLATION INSTRUCTIONS B) FLOOR CONSTRUCTION TIMBER When installed on a timber floor, the floor board should be supported at not greater than 500mm centres and the cut-out waste connection kept to a minimum. CONCRETE When installed on a concrete slab floor, chases or channels left for plumbing must be completely backfilled. C) WALL CONSTRUCTION 1) Ensure that the wall framing and lining are constructed in accordance with one of the following illustrations (Fig.
  • Page 15 Install wall if applicable. Follow instructions supplied with the wall. CONTACT AND WARRANTY INFORMATION - For contact information, please refer to the Home Owner’s Guide. - For warranty and other information, please visit our website. NEW ZEALAND AUSTRALIA KOHLER NZ LTD KOHLER AUSTRALIA www.englefield.co.nz www.englefield.com...
