- Page 1 Install Guide Still Water Remote Dispenser System CR-UCW-BH and CR-UCM2SW-2 Remote Chiller with CBR Towers Register your product online: Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545 01172023...
- Page 2 CR-24FC fittings for product line hook up. When See Quick Install Guide for more install Filter system to a Crysalli CR-UCM# still installing a second CBR tower use the details. water chiller unit and a CBR-V2-SSX or...
- Page 3 CR-UCW or CR-UCM2SW-2 still 11. Power unit on: Plug the unit Refer to page 8. water Crysalli chiller. Place the into dedicated 120-volt outlet CR-UCW unit within 6’ to water 6. Chiller connections: Connect (preferably a non-GFI outlet).
- Page 4 Trunkline to tower 2” 2.5” 6” 3.375” 7.625” 15.125” 4.25” 5.1875” 8.5” Cutout 0.8125” 10.375” 0.75” 0.8125” 12” Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 5 Correctly Fitting not the fitting. With the collet held set and tightened in this position the tube can tightened down be removed. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 6 Apply the round sparkling and still water image stickers to the appropriate handles at the top of them. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD...
- Page 7 5/16- CR-ABUCM CR-TFB1 CR-WMB2 18 1” bolts to screw the unit to the bracket via the leg holes. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 8 4 seconds PSEI6012U9 fitting. (see operation instructions for more details). 3. Place the control unit nextto your Crysalli unit, ideally between the filter system and chiller. To UCW/SW Chiller unit Note: Crysalli does not provide external backflow preventers.
- Page 9 UCW Chiller chiller, utilize both PLAIN WATER outlets, by connecting the blue tube to one and white to the other rather than splicing them toghter. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 10 Elbow fitting for FPT thread Barb end CBR Towers fitting for Fisher for other or T&S faucet connections Use the red locking clips on all tube connections Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 11 Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
- Page 12 ☐ Visually check pre-filter in clear bowl on water filter system (if applicable) to determine if it needs replacing. Use only EPC5-10 replacement pre-filter cartridge. Crysalli Beverage Systems www.crysalli.com 510.732.0100 a division of WPD 1739 Sabre Street, Hayward, CA 94545...
