Summary of Contents for Nice E ACTION SI 332 AC
- Page 1 Era Inn Action E ACTION SI 332 AC E ACTION MI 332 AC E ACTION SI 620 AC E ACTION MI 632 AC E ACTION SI 1012 AC E ACTION MI 1020 AC Tubular motors EN - Instructions and warnings for installation and use...
-
Page 2: Installation Warnings
GENERAL WARNINGS: SAFETY - INSTALLATION - USE (original instructions in Italian) ATTENTION Important safety instructions. Follow all instructions as improper installation may cause serious damage ATTENTION Important safety instructions. It is important for you to comply with these instructions for your own and other people’s safety. -
Page 3: Product Description And Intended Use
• The power cable is connected to the motor via a connector; this is removable (fig. 2.2 - Assembling and installing the tubular motor 3-h) and allows the replacement of the cable (refer to the “Nice Screen” product catalogue, also available on the website www.niceforyou.com). -
Page 4: Programming And Adjustments
After completing the connections, supply power to the motor and carry out some – All the programming and adjustment operations must be carried out with the Nice movements(*) to verify if the Up and Down movements of the awning are correctly TTU programmer (Fig. - Page 5 Note - Programming must be done using the NICE TTU programmer or a generic two-button push button panel with no interlock. English – 4 English – 4...
- Page 6 A.3 - Adjusting the motor’s sensitivity to obstacles NOTES AND WARNINGS • Use this procedure to activate, adjust or deactivate the safety system that: a) detects the presence of an obstacle along the travel of the awning; b) reduces the mo- tor tension on the awning when it is stationary at the Upper limit switch “0”...
- Page 7 Assistance. Using a smartphone equipped with NFC technology and a software application produced by Nice (to be installed on your smartphone), you can configure the motors before installing them, even without the need to supply power. You can also perform a hardware and software diagnostic of the motor, even if it is damaged.
- Page 8 Note: • All technical specifications stated herein refer to an ambient temperature of 8 flashes = serious error - 6 (brake malfunction). 20° C (± 5° C). • Nice S.p.A. reserves the right to apply modifications to products 9 flashes = serious error - 7.
- Page 9 Simplified EU declaration of conformity Nice S.p.A. manufacturer of this equipment declares that it is in compliance with the Directive 2014/35/EU (LVD) and the Directive 2014/30/EU (EMC). The instruction manual and the full text of the EU Declaration of Conformity are avail- able at www.niceforyou.com;...
- Page 10 Appendix Action M Limit switch gear Drive wheel (not in- wheel (not includ- cluded). ed). Action S...
- Page 11 Cap for fixing the roller to the bracket (not included). Removing the connector if necessary 10 mm Support for fixing the motor head to the brack- et (not included). 2 screws: self-tapping without point, for plastic materials. Diameter: 4 mm; length of threaded part: = min.
- Page 12 Nice SpA Via Callalta, 1 31046 Oderzo (TV) www.niceforyou.com Italia...
