OWNER'S MANUAL
DISHWASHER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
XD2*25**
MFL72141239
Rev.00_081924
Copyright © 2024 LG Electronics. All Rights Reserved
Scan the QR code to see the manual.
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XD2 25 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG XD2 25 Series

Summary of Contents for LG XD2 25 Series

  • Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH XD2*25** www.lg.com MFL72141239 Rev.00_081924 Copyright © 2024 LG Electronics. All Rights Reserved...

  • Page 2: Table Of Contents

    Wash Cycles ......................25 Options and Extra Functions ................26 Programme Table ....................28 Information for Energy Test (AS/NZS 2007)..........30 Loading the Dishwasher .................30 Adding Cleaning Agents..................37 Refilling......................38 Useful Tips......................39 SMART FUNCTIONS LG ThinQ Application ..................40 Smart Diagnosis ....................42 MAINTENANCE Cleaning and Caring ..................44...
  • Page 3 TROUBLESHOOTING Before Calling for Service................48...

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk.

  • Page 5: Installation

    • Do not modify the power cord provided with the appliance. Please contact the LG Customer information centre to advise of its incompatibility. • This appliance should only be transported by two or more people holding the appliance securely.
  • Page 6 • Connect the ground wire to the green ground connector in the terminal box. Operation • Immediately unplug the power plug and contact an LG Electronics customer information centre if you detect a strange sound, odour, or smoke coming from the appliance.
  • Page 7 • In case of flood, disconnect the power plug and contact the LG Electronics Customer Information Centre. • Under certain conditions, hydrogen gas may be produced in a hot- water system that has not been used for two weeks or more.
  • Page 8 SAFETY INSTRUCTIONS • Do not operate the appliance unless all enclosure panels are properly in place. • Use only detergents or wetting agents recommended for use in a appliance and keep them out of the reach of children. • Do not wash and dry articles that have been soaked in explosive substances such as gasoline, solvents, solvent-based detergent.

  • Page 9: Caution

    SAFETY INSTRUCTIONS Maintenance • Never unplug the appliance by pulling on the power cable. Always grip the power plug firmly and pull straight out from the socket outlet. • Securely plug the power plug in the socket outlet after completely removing any moisture and dust.
  • Page 10 SAFETY INSTRUCTIONS Operation • Turn off the water tap and unplug the appliance if the appliance is to be left for an extended period of time, such as during vacations. • Do not place objects on the top of the appliance. •...

  • Page 11: Installation Parts And Specifications

    INSTALLATION INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View Interior View Control Panel & Door Handle Top Wash Impeller Front Cover Upper Spray Arm Lower Cover Lower Spray Arm Levelling Feet Salt Dispenser Cap...

  • Page 12: Specifications

    INSTALLATION Accessories Funnel Noise Strip Cover Felt Moisture Barrier Tape (Aluminum tape) *1 Noise strips are provided: Lower - 1 EA, Front - 1 EA, Side - 2 EA Specifications Model XD2*25** Power Supply 220 - 240 V~, 50 Hz Dimension 600 mm X 850 mm X 600 mm (Width X Height X Depth)

  • Page 13: Preparing Cabinet Opening

    INSTALLATION Preparing Cabinet Opening NOTE Choosing the Proper Location • This installation must be conducted by qualified service personnel to ensure it has been installed correctly. • Do not pull or lift the appliance using the handle; dosing so can damage the door and hinges. Open the door and grab the body frame and the top front opening of the tub to move or lift the appliance.
  • Page 14 INSTALLATION Lay down the appliance and pull on both the Remove the double-sided tape from the lower hooks at the bottom of the lower cover. and front strips. Attach the black coloured lower strip to the bottom of the lower cover. Pull on the lower cover to remove it.
  • Page 15 INSTALLATION Attaching the Strip to the Clean and dry the underside of the counter top Appliance Side Cabinet on which the tape will be attached. To reduce noise attach the strip to the appliance sides, if the opening space allows. Remove the double-side tape from the side strips.

  • Page 16: Levelling The Appliance

    INSTALLATION Levelling the Appliance Check the opening of door and repeat if necessary until the door opens and closes Checking the Level properly. Levelling the appliance prevents unnecessary leakage and poor washing. Check whether the appliance is perfectly level after installation. •...

  • Page 17: Installing The Drain Hose

    INSTALLATION Installing the Drain Hose Method 1 When the drain hose is connected to a waste If the end of the drain hose does not fit to the drain spigot, the hose must be looped up to the line, use a drain extension kit (optional) that is underside of the bench top and secured.

  • Page 18: Preparing Water And Electrical Connections

    INSTALLATION Preparing Water and • Use sealant tape or sealing compound on the tap’s thread to avoid water leaks. Electrical Connections • Make sure that the line is not kinked or sharply bent. Connecting the Hose to the Water Tap NOTE Connect the water supply hose to the water tap.

  • Page 19: Final Installation Check

    INSTALLATION Final Installation Check Error Possible Cause and Solution Code Testing the Dishwasher Water supply line kinked under dishwasher. Turn on electrical power. • Feed the drainage and supply hoses through the hole under the sink. Then gradually slide the Turn on house water supply.

  • Page 20: Operation Operation Overview

    OPERATION OPERATION Operation Overview Load the dishes in the rack. • Make certain that no dishes or utensils are in Using the Appliance the path of the spray arms. • Do not place one dish on top of another. Open the door and press the Power button. •...

  • Page 21: Before Using

    OPERATION NOTE NOTE • Never use liquid dishwashing detergent in the • The appliance can be used without dishwasher appliance. salt if not required, however, the hardness level needs to be set to H0 so that the icon does not •...

  • Page 22: Filling With Dishwasher Salt

    OPERATION adjustment levels, and the appliance is and 1 litre of water at the same time if programmed at the factory for a water hardness intending to use the water softener system. level of H2. You can check the default setting value When refilling the salt, use a funnel.

  • Page 23: Adding Rinse Aid

    OPERATION rust or damage to the appliance if the left Close the lid to lock the dispenser. Rinse aid is unwashed. dispensed automatically during the final rinse cycle. CAUTION • Wipe off any spilled rinse aid to prevent suds. NOTE •...

  • Page 24: Control Panel

    OPERATION • Setting the control too high can cause foaming, NOTE which will cause poor wash results. • The Rinse Aid Refill icon will illuminate when • If the glass is smeared or foam is present on the more rinse aid is needed. bottom, decrease the level setting.

  • Page 25: Wash Cycles

    OPERATION • The Auto cycle time may vary depending on the soil level of your load. Rinse Aid Refill Icon • This icon flashes when the rinse aid level is low. The LED automatically shuts off when the rinse aid is refilled or the level is set to 0.

  • Page 26: Options And Extra Functions

    OPERATION Express It provides the most efficient energy and water This cycle will quickly clean lightly soiled dishes. consumption for a good washing result and drying • Press and hold Turbo for 3 seconds to activate. result on a normally soiled load and as it uses very little energy.
  • Page 27 OPERATION Auto Open Dry Hi-Temp. Raises the main wash or heating rinse temperature to improve cleaning. This feature may vary depending on the model purchased. • A chime will sound to alert you of any residual The Auto Open Dry feature enhances the drying temperatures inside the appliance.

  • Page 28: Programme Table

    OPERATION Programme Table Programme Guide Wash Rinse Program Soil Level Pre-wash Main wash Rinse Heating rinse Auto All levels (50 - 55 ℃) (70 ℃) Intensive Heavy (75 ℃) (70 ℃) Delicate Light (45 ℃) (70 ℃) Refresh (75 ℃) Moderate (53 ℃) (70 ℃)

  • Page 29: Available Options

    OPERATION Available Options NOTE • The Energy Saver option is not available with the Steam, Hi-Temp. or Extra Dry option. Programm Dual Half Energy Delay Steam Hi-Temp. Extra Dry Zone Load Saver Start Auto Intensive Delicate Refresh Turbo Express Rinse Machine Clean Download...

  • Page 30: Information For Energy Test (As/Nzs 2007)

    OPERATION Information for Energy Knives Test (AS/NZS 2007) Upper Rack Appliance loaded in accordance with standardspecifications. For Model with Cutlery Rack • Model: XD2*25** • Capacity: 15 place settings • Comparability programme: Eco + Energy Saver • Rinse Aid setting: L4 •...

  • Page 31: Items Not Suitable For Dishwashers

    OPERATION • Remove large particles of food debris from plates including bones etc. before loading. Always rinse off plates when loading if they are not to be washed immediately. • Items with burnt on food should be soaked prior to loading the dishwasher. •...

  • Page 32: Loading The Lower Rack

    OPERATION Test for free movement by manually rotating the CAUTION spray arms. • Water proof or long lasting lipstick smudges on glasses may not be removed during the wash. Loading the Lower Rack Daily Use Load The lower rack is suitable for dinner plates, soup bowls, dishes, pots, pans, lids and even a grill tray.
  • Page 33 OPERATION Plates should be positioned upwards with the Test for free movement by manually rotating the plate. spray arms. The cup racks provide support for long stem glasses. Removing and Replacing Cup Racks The left and right cup racks are interchangeable and can be removed.

  • Page 34: Height Adjustable Upper Rack

    OPERATION • The rack on the left pops free at the back. There are three available positions for adjusting The rack on the right pops free at the front. the height of the upper rack to create more space. Lowering the Rack Hold the rack at the centre of each side to support its weight.

  • Page 35: Loading The Cutlery Rack

    OPERATION Possible plate size according to the • When the upper rack is in the lower position, push in the upper rack first, and the lower rack upper rack position later. • Pull out the lower rack first, and the upper rack Plate Size (mm) later.

  • Page 36: Height Adjustable Tray

    OPERATION Height Adjustable Tray The Wine Glass Rack gently holds up to 4 glasses safely. The tray on the left side can be adjusted to a high Optimized for glasses position or low position to accommodate utensils or cutlery of different sizes. Remove dishes before adjusting the tray.

  • Page 37: Adding Cleaning Agents

    OPERATION • Bowl: ~ 100 mm • The amount of detergent needed depends on the cycle, load size, and soil level of dishes. • Put detergent into the detergent compartment before starting any cycle, except the Rinse cycle. Push the button on the dispenser lid to open the cover.

  • Page 38: Refilling

    OPERATION • Use of an unsuitable detergent and rinse aid Amount of detergent may result in a risk of damage, corrosion, poor washing results, poor drying or leakage. Programme Pre-wash Main wash • Only use the detergent and rinse aid that has (onto the lid) (dispenser) been qualified with standard.

  • Page 39: Useful Tips

    OPERATION any spilled salt inside the appliance may cause rust or damage to the appliance if the left unwashed. When the Salt Refill icon illuminates, it means the salt is almost empty. If necessary, refill the salt dispenser. CAUTION • Do not add detergent or any other solution into the water softener housing other than dishwasher salt.

  • Page 40: Smart Functions

    When the cycle is complete or the appliance has problems, you have the option of receiving push Run the LG ThinQ application and sign in with notifications on a smartphone. The notifications your existing account or create an LG account are triggered even if the LG ThinQ application is to sign in.

  • Page 41: Wireless Lan Module Specifications

    Internet service provider or refer to your Run the LG ThinQ application. wireless router manual. • LG ThinQ is not responsible for any network connection problems or any faults, Select and touch the Dishwasher in the malfunctions, or errors caused by network application.

  • Page 42: Smart Diagnosis

    NOTE LG ThinQ application. • Only one wireless module applies to the product. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ application.
  • Page 43 SMART FUNCTIONS After the data transfer is complete, the diagnosis will be displayed in the application. NOTE • For best results, do not move the smartphone while the tones are being transmitted.

  • Page 44: Maintenance

    MAINTENANCE MAINTENANCE To maintain performance and prevent problems, Food residue may be stuck in the narrow gaps check the outside and inside of the appliance, inside the appliance after completion of washing. including filters and spray arms regularly. Wipe off all food residue. WARNING •...

  • Page 45: Cleaning The Filters

    MAINTENANCE white vinegar into shallow bowl and place in upper Clean the filters with a soft brush under rack. Run Auto cycle. Do not use detergent. When running water. Reassemble the filters before the cycle is finished, restart. reinstalling them. CAUTION •...
  • Page 46 MAINTENANCE Cleaning the Upper Spray Arm NOTE • When assembling, rotate it firmly until it clicks. Pull the upper rack forward. Make sure that the water jet holes are not blocked by food particles. When cleaning is necessary, remove the upper spray arm by turning the nut on the bottom of the spray arm 1/8 turn counterclockwise and pulling down.

  • Page 47: Seasonal Maintenance And Storage

    MAINTENANCE After cleaning the upper spray arm, press it up Refit the filter and gasket and make sure that it into place. Turn the nut 1/8 turn clockwise to is sitting correctly. make sure that the nut locks back into place. Refit and secure the water supply hose in reverse order.

  • Page 48: Troubleshooting

    The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If this appliance does not function properly or does not function at all, check the following before you call LG Electronics service centre. Symptoms Possible Cause &...
  • Page 49 TROUBLESHOOTING Symptoms Possible Cause & Solution Motor trouble • Call for service if the same problem occurs again. Vario motor trouble • Call for service if the same problem occurs again. Operation Symptoms Possible Cause & Solution Noise Some level of noise is normal during operation. •...
  • Page 50 TROUBLESHOOTING Symptoms Possible Cause & Solution Water remains in sump Water may remain if the power supply was lost before normal end of the after completion of course or was manually disconnected. cycle. • Re-start the course. Sprays arms do not Holes of spray arms are blocked by food particles.
  • Page 51 TROUBLESHOOTING Symptoms Possible Cause & Solution Yellow or brown film Coffee or tea stains on inside surfaces of • Eliminate the stain by using a stain removal product. appliance Yellow water remains When initially using the appliance, Yellow water may generate in the inside the dishwasher.
  • Page 52 TROUBLESHOOTING Symptoms Possible Cause & Solution Odour There is food in the bottom of the unit or in the filter. • Clean the filter and the interior according to the MAINTENANCE section of the owner’s manual. Unwashed dishes are left in the unit for a long time. •...
  • Page 53 • Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG ThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance using the Wi-Fi network.
  • Page 54 Memo...
