- Page 1 PL8R RGB LED Light User Manual Thank you for choosing COLBOR product. Please read this manual carefully before use and follow all instructions mentioned herein.
- Page 2 Caring For Your COLBOR Product · Please keep the product in a dry, clean, dust-free environment. · Keep corrosive chemicals, liquids, and heat sources away from the product to prevent mechanical damage. · Use only a soft and dry cloth for cleaning the product.
-
Page 3: Product Instructions
Product Instructions ① On/Off/Mode Button ⑥ Brightness Control Wheel ② APP Pairing Button ⑦ Display Screen ③ Cold Shoe Connection ⑧ NFC Detection Area ④ USB-C Port ⑨ 1/4-inch connection ⑤ Option & Adjustment Wheel Charge Connect the Type-C cable into the USB-C port, it supports 5V 2A input at maximum. - Page 4 Operation Instructions ① Long press for 3s 1. Power On/Off ② Short press Long press the ON/OFF/MODE BUTTON for 3s to turn it on/off. 2. PARAM Control Short press the ON/OFF/MODE BUTTON to switch among 3 modes: CCT/HSI/EFF mode. CCT Mode Wireless Connection Status Icon Battery Life...
- Page 5 HSI Mode Wireless Connection Status Icon Battery Life 360° 100% 100% Saturation Brightness ① Adjust HUE/SAT Short press the OPTION & ADJUSTMENT WHEEL to choose the option: HUE/SAT, roll up/down to adjust the value. ② Brightness Control (0%~100%) Roll the BRIGHTNESS CONTROL WHEEL up/down to adjust the value, short press to select preset brightness (0%, 25%, 50%, 75%, 100%).
- Page 6 3. Wireless Connection Scan or search in the app store to download the COLBOR STUDIO for further functions. APP Connection & Operation 1. Short press the APP pairing button to enter the wireless connecting mode. (Show the icon 2. Open the COLBOR STUDIO APP and click“Add Fixtures", and find the light to confirm adding it.
- Page 7 NFC Connection Tag your phone's NFC sensing area close to the light's NFC logo. A prompt will automatically appear to open the APP. Click it to open the APP. * If the app has not been installed, a prompt to install will appear. Click it to enter the app download page or the APP store.
- Page 8 * A light is allowed to be controlled by multiple phones simultaneously. For the real-time parameters, please refer to the phone that last controlled the light and the light itself. APP Operation Click the links for more information about COLBOR STUDIO APP User Manual. Graphic: https://www.colborlight.com/pages/cb-studio-help-...
-
Page 9: Specifications
Battery Charging Time About 3H Working Voltage 3.7V Built-in Lithium Battery Power Requirement /DC Power Supply Housing Material Dimension 115*68*16mm Net Weight 125g Operating Temperature -10-40℃ Packing List PL8R LED Light x1 Type-C Cold Shoe Warranty Charging Cable Mount x1 Card x1... -
Page 10: Warranty Period
2.Please retain your sales receipt and warranty certificate as proof of purchase. If any of these documents is missing, only sales return or chargeable service will be provided. 3.If the COLBOR product is out of the warranty coverage, the service and the parts cost will be charged. - Page 11 Guangzhou Zhiying Technology Co., Ltd Room 2401, 24 / F, South Tower, Lisheng Plaza, No. 68 Huadi Avenue, Liwan District, Guangzhou, China, 510000 support@colborlight.com www.colborlight.com...
