HARDWARE PACKAGE CONTENTS

A B
N
REF PART NO.
A 46782
B 43224
C 43084
D 43661
E 43978
F 47189
G 47810
H 44917
2
SHOWN FULL SIZE
C D
QTY DESCRIPTION
2 Hex Bolt, 5/16-18 x 3" Lg.
2 Hex Bolt, 5/16-18 x 2-1/4" Lg.
4 Hex Bolt, 5/16-18 x 1-3/4" Lg.
4 Hex Bolt, 1/4-20 x 1"
4 Curved Head Bolt, 1/4-20 x 1"
8 Nylock Nut, 1/4"
8 Nylock Nut, 5/16"
2 Palnut, 3/8"
E
I
M
REF PART NO.
I 48130
J 46867
K 48365
L 48366
M 43055
N 23353
O 44481
G
F
K
J
O
QTY DESCRIPTION
2 Hitch Spacer, 3/4"
2 Clevis Pin, 1/4" x 1-3/4"
2 Clevis Pin, 1/4" x 1-1/8"
2 Clevis Pin, 3/8" x 1/2"
7 Hairpin Cotter, 3/32"
1 Hitch Pin
2 Vinyl Cap
