Summary of Contents for DB Drive Brazilian Power A7PRO 3K.2
- Page 1 A7PRO 3K.2 A7PRO 4K.4 User Manual Installation Instructions/Owner’s Manual www.dbdrive.net DUE TO CONTINUOUS IMPROVEMENT OF THE PRODUCT THE SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
- Page 2 WORLD RECORD BREAKING TECHNOLOGY 1. AMPLIFIERS’ SPECIFICATION 1-1. AMPLIFIER Load Voltage & THD A7 PRO3K.2 A7 PRO4K.4 4ohm 14.4 volts & 1% 2 x 525 Watts 4 x 250 Watts 2ohm 14.4 volts & 1% 2 x 1050 Watts 4 x 500 Watts 1ohm 14.4 volts &...
-
Page 3: Installation
In case you install the amplifier by yourself, please read owner’s manual very carefully before your installation Please take all steps into consideration or, you can have DB Drive or DB Research’s authorized dealer to check installation and set your car audio systems. - Page 4 In case you install the amplifier by yourself, please read owner’s manual very carefully before your installation Please take all steps into consideration or, you can have DB Drive or DB Research’s authorized dealer to check installation and set your car audio systems.
-
Page 5: Speaker Connection
Remote turn on 3-4. SPEAKER CONNECTION DB Drive recommends to use minimum 12 gauge speaker connecting cables. Run 12 gauge speaker connecting cables from your speakers to amplifier’s mounting location. Keep speaker cables away from the power cables and amplifier’s input cables. Use grommets anywhere the cables have to pass through the holes in the metal frame or sheet metal. -
Page 6: Troubleshooting
A7 PRO4K.4 AMPLIFIER SPEAKER CONNECTION DIAGRAM 2 8 ~ 1 ohms 8 ~ 1 ohms 8 ~ 1 ohms 8 ~ 1 ohms 8 ~ 1 ohms 8 ~ 1 ohms A7 PRO4K.4 AMPLIFIER SPEAKER CONNECTION DIAGRAM 3 4. TROUBLE SHOOTING 8 ~ 2 ohms NO SOUND ( NO OUTPUT ) 1) Please check all connections, cables’...
