DMX9724XDS
DAX8000XDS
MONITOR WITH RECEIVER
Quick Start Guide
Hi-Res Audio logo and Hi-Res Audio
Wireless logo are used under license
from Japan Audio Society.
B5K-1192-10 (X)
Advertisement
Table of Contents
Related Manuals for Kenwood DMX9724XDS
Summary of Contents for Kenwood DMX9724XDS
- Page 1 DMX9724XDS DAX8000XDS MONITOR WITH RECEIVER Quick Start Guide • The user manual for these products can be found on the following website. <https://www.kenwood.com/cs/ce/im_edition/im409/> Hi-Res Audio logo and Hi-Res Audio Wireless logo are used under license from Japan Audio Society. © 2025 JVCKENWOOD Corporation...
- Page 2 Important Notice on Software EULA Software License on This Product Software License Agreement The software embedded in this product JVCKENWOOD Corporation (hereinafter called comprises a number of independent software “Licensor”) holds either the copyright to the components, each of which is copyrighted by embedded software or the right to sublicense it.
- Page 3 Article 3 (Terms of License) Article 8 (Cancellation of the Agreement) 1. In assigning this product, User may not retain Licensor reserves the right to cancel this the original copy of the embedded Licensed agreement forthwith and claim compensation Software (including associated literature, from User for the damages caused by such updates and upgrades) and any duplicates cancellation when User:...
-
Page 4: Before Use
Precautions on using this unit • When you purchase optional accessories, check with your KENWOOD dealer to make sure that they work with your model and in your area. • You can select a language to display menus, Support for this unit audio file tags, etc. -
Page 5: Note For Specifications
For best results while pairing with your disposed into fire or a hot oven, recharged, KENWOOD receiver, please be sure to close any shorted, mechanically crushed or cut of the unused applications. -
Page 6: Getting Started
OEM Settings menus, and more. (Requires installation of an iDatalink Maestro in a compatible vehicle). [Vehicle Features] This function requires a commercial adaptor. Consult your KENWOOD dealer for details. [DEMO] Set the demonstration mode. Default is “ON”. The unit is turned on. [System Configuration] Configure the digital sound output settings. - Page 7 Assign each position to the view camera To set up the camera connected to the selected input terminal. assignment settings Front/Left/Right/Dashboard Camera/[None] ③ Mirroring setting * DMX9724XDS Switch the mirroring setting. Press the HOME button. [ON]/[OFF] (Default) DAX8000XDS Touch at the top of the screen.
- Page 8 Getting Started NOTE • The screen shot above is for the [FRONT VIEW CAMERA / DASH CAM] setting screen. It may be different from the ones for [3rd VIEW CAMERA] and [VIDEO IN]. • The Dashboard Camera can be selected when it is connected.
-
Page 9: Basic Operations
Functions of the Buttons on the • Motion Front Panel ⑦ VOICE • Switches the voice recognition function on/ DMX9724XDS off. • When neither Apple CarPlay, Android Auto, nor a Bluetooth Hands-Free phone is connected, pressing and holding displays Bluetooth pairing waiting dialog. -
Page 10: Home Screen Descriptions
Displays the source selection screen. ③ Displays the SETUP Menu screen. ④ Short-cut playback source icons. Popup menu DMX9724XDS Press the [MENU/ATT] button. Popup menu appears. Touch to display the popup menu. ① The contents of the menu are as follows. -
Page 11: Source Selection Screen Description
Displays the SETUP Menu screen. • Increases the volume. Ñ Select the playback source • Turns off the screen and audio. Interrupts DMX9724XDS from incoming hands-free calls, rear Press the HOME button. camera views and so on are functional, DAX8000XDS though. -
Page 12: Digital Radio Basic Operation
Basic Operations • Switches to the Apple CarPlay screen from the connected iPhone. • Switches to the Android Auto screen from the connected Android™ smartphone. • Displays the Hands-Free screen. When neither Apple CarPlay, Android Auto, nor a Bluetooth Hands-Free phone is connected, displays Bluetooth pairing waiting dialog. -
Page 13: Operation Keys
Basic Operations ① Operation keys • [1] : Displays the Service List screen. • [E] [F] : Tunes in a ensemble, service, and component. The seek mode switching can be ③ changed. (see Seek mode). ② Preset list • Touching [ ]/[ ] allows you to change the display size. -
Page 14: Bluetooth Control
NOTE registers the smartphone as a Bluetooth device. • If an Apple CarPlay device is currently connected, DMX9724XDS the Apple CarPlay device will be disconnected. • When neither Apple CarPlay, Android Auto, nor a Press the HOME button. -
Page 15: Using The Hands-Free Unit
: Call using the phonebook • : Call using the preset number Ñ Make a call • : Call by entering a phone number DMX9724XDS Select the smartphone/cell- Press the HOME button. phone to use DAX8000XDS When you connect two smartphones/cell-phones Touch at the top of the screen. -
Page 16: Receive A Call
Bluetooth Control • Characters with no corresponding name NOTE will not appear. • When shifting the gear to the reverse (R) position • A first character with an accent character and monitoring the picture from the rear view such as “ü” can be searched for with a non- camera, this screen does not appear even if a call accent character “u”... -
Page 17: Apple Carplay Operation
APPS APPS NOTE Apple CarPlay Operation • Depending on the iPhone connector, use a Apple CarPlay is a smarter, safer way to use your genuine Apple Lightning-USB cable or a USB-IF iPhone in the car. Apple CarPlay takes the things certified USB-C®... - Page 18 APPS For details about Android Auto, visit https:// DMX9724XDS www.android.com/auto/ and https:// Press the HOME button. support.google.com/androidauto. DAX8000XDS Touch at the top of the screen. Compatible Android smartphones Touch HOME on the popup menu. Compatible Android phone and compatible HOME screen appears.
-
Page 19: Before Installation
Connection/Installation Connection/Installation • If your car’s ignition does not have an ACC Before Installation position, connect the ignition wires to a power source that can be turned on and off with the Before installation of this unit, please note the ignition key. -
Page 20: Supplied Accessories For Installation
Connection/Installation • Reception may drop if there are metal objects Ñ Supplied accessories for near the Bluetooth/Wi-Fi antenna. installation DMX9724XDS ① ×1 ② ×1 (1 m) ③ Bluetooth/Wi-Fi antenna unit ×1 (3 m) DAX8000XDS ④ ×4 (M5 x 8 mm) ⑤... -
Page 21: Installing The Accessories
(accessory ⑥ ), and stick the antenna to the metal plate (accessory ⑦ ). ⑥ ㉑ ×1 ⑦ *1 DMX9724XDS only *2 DAX8000XDS only Ñ Installation procedure NOTE 1. To prevent a short circuit, remove the key • Use the supplied GPS antenna. Using the GPS antenna other than the supplied one may cause a from the ignition and disconnect the ¤... -
Page 22: Installation Overview
⑳ ㉑ Fix a cable with a commercial item of tape. Ñ Installation the Digital Radio antenna (DMX9724XDS only) Antenna cable # CAUTION (3.5 m) • This film antenna is exclusively for use inside Determining the antenna the vehicle. - Page 23 Connection/Installation 2. Clean the windscreen with the supplied When installing the antenna on the left side cleaner (accessory ⑲ ). Ceramic line (black part) ⑲ 150 mm ⑳ 30 mm – Wait until the glass surface is completely dry Earth sheet* before pasting.
- Page 24 Connection/Installation ⑳ ㉑ Earth sheet Match the protrusion with the triangle mark Lead terminal of Lead contact of the film antenna the amplifier unit (metal part) – When installing the antenna on the left side Earth sheet ⑳ ㉑ 7. Remove the film covering the earth sheet and attach the earth sheet to the metal part of the vehicle.
- Page 25 Connection/Installation Installing the Big Screen model DMX9724XDS Ñ Confirm the installing position of the display unit Vehicles cannot be installed It may be possible to install if it can avoid the following by adjustment for slider position and display height.
-
Page 26: Installing The Main Unit
Connection/Installation Ñ Positioning the slider in forward Install the car bracket to the main unit. Remove the two screws from the top of the main unit. ④ ⑤ Screw ④ ⑤ Main unit Car bracket Main unit Connect the wiring harness wires and Remove the four screws from the bottom peripheral equipment. -
Page 27: Left Position
Connection/Installation Ñ Installing the display unit and Positioning the arm bracket (accessory ⑫ ). adjusting the height When installing the arm bracket in the left or right position, move the display cable so that Remove the rear cover from the display it aligns with the groove in the arm bracket. -
Page 28: Removing The Display Cable
Connection/Installation Adjust the display height according to the Raise the display manually. screw hole position. Ñ Removing the display cable # CAUTION • To prevent injuries to your hands and damage to the display cable, cover the metal parts with protective tape before working. - Page 29 Connection/Installation Installation overview Main unit *1 (Installed vertically) ⑧ ⑯ Installed Installed horizontally vertically ±5° ±5° Display cable *2 Pitch 0° – 40° ±20° Roll ±5° ±5° Main unit *1 Front side of the vehicle (Installed horizontally) Top side *1 Depending on how the main unit is oriented, [Installation Orientation] may require Left side configuring.
-
Page 30: Connecting The Unit
Connection/Installation Connecting the unit Ñ Connecting wires to terminals White Speaker impedance: 4-8 Ω Fuse (15A) Other cable : Not used. To front left speaker White/Black Gray To front right speaker Gray/Black Green ① Connect to the vehicle’s To rear left speaker parking brake detection Green/Black switch harness. - Page 31 Connection/Installation Ñ Ñ 3-way speaker system setup Connecting the external amplifiers and external AV White To mid range left device speaker White/Black Gray To digital input amplifier To mid range right speaker Gray/Black Video output (Yellow) Green To tweeter left Video input (Yellow) *2 speaker Green/Black...
- Page 32 ② USB Type-C Cable or USB-C to to vehicle’s steering remote harness. (1.0 m) Lightning Cable *2 *3 Contact your KENWOOD dealer for details. HDMI Type D terminal USB terminal *1 ⑧ Accessory ⑥ : GPS Antenna Use the supplied GPS antenna. Using the GPS antenna other than the supplied one may cause a drop in positioning accuracy.
-
Page 33: Connecting The Camera
Connection/Installation *4 Optional accessory Ñ Connecting the camera Ñ Connecting an Android™ Left side view camera and Right side view camera *2 smartphone Front view camera *4 *6 Android smartphone *2 Video input (Yellow) ② (1.0 m) USB Type-A Cable *3 3rd view camera input (Yellow) ⑮... -
Page 34: Trademarks And Licenses
Wireless use of Android Auto requires a Ñ Trademarks and licenses compatible Android 11.0+ phone and • The Bluetooth® word mark and logos are compatible active data plan. registered trademarks owned by Bluetooth SIG, Check g.co/androidauto/requirements for Inc. and any use of such marks by compatibility. - Page 35 • THIS PRODUCT IS LICENSED UNDER THE VC-1 USE, DATA, OR PROFITS; OR BUSINESS PATENT PORTFOLIO LICENSE FOR THE INTERRUPTION) HOWEVER CAUSED AND ON PERSONAL AND NON-COMMERCIAL USE OF A ANY THEORY OF LIABILITY, WHETHER IN CONSUMER TO ( i ) ENCODE VIDEO IN CONTRACT, STRICT LIABILITY, OR TORT COMPLIANCE WITH THE VC-1 STANDARD (INCLUDING NEGLIGENCE OR OTHERWISE)
- Page 36 – Redistributions of source code must retain For Australia the above copyright notice, this list of If it is suspected a button/coin battery has been conditions and the following disclaimer. swallowed or otherwise placed inside any part of – Redistributions in binary form must the body, a person should contact the Australian reproduce the above copyright notice, this Poisons Information Centre on 13 11 26...
