- Page 1 5MP FLOODLIGHT CAMERA USER MANUAL ZY-E2 Sales Email: service@iegeek.com https://www.iegeek.com Official website:...
-
Page 3: Warranty
VALIDATE YOUR WARRANTY WITHIN DAYS AND GET A YEAR EXTENDED WARRANTY ON YOUR IEGEEK SECURITY PRODUCTS. YEARS WARRANTY Email:service@iegeek.com... - Page 4 Scan the QR code to get a multilingual PDF manual. Scannen Sie den QR-Code, um ein mehrsprachiges PDF-Handbuch zu erhalten. Scansiona il codice QR per ottenere un manuale PDF multilingue. Escanee el código QR para obtener un manual en PDF multilingüe. Scannez le code QR pour obtenir un manuel PDF multilingue.
- Page 5 Activate Your Warranty & Get Exclusive Services (service@ 1. Please contact us via our official email iegeek.com) to obtain exclusive customer services if you have any questions. 2. Scan the QR code below and extend the free returns to 18 months. Register within 30 days after receiving the camera to ensure your purchasing is 100% covered.
-
Page 7: Table Of Contents
CONTENT TECHNICAL SUPPORT ..........1 WHAT’S IN THE BOX ........... 2 PRODUCT DESCRIPTION ..........4 INSTALLATION AND WIRING ........5 PRECAUTIONS BEFORE INSTALLATION ............6 AMERICAN VERSION INSTALLATION STEPS ..........10 EUROPEAN VERSION INSTALLATION STEPS ..........14 INSTALLATION ANGLE ..................... 18 PRECAUTIONS AFTER INSTALLATION ............. -
Page 9: Technical Support
TECHNICAL SUPPORT If you need help, please contact ieGeek before returning your product. Most http://www. questions can be answered through our online support center at iegeek.com or our after-sale mailbox at service@iegeek.com. Please read this manual thoroughly before using this wireless security camera. -
Page 10: What's In The Box
WHAT’S IN THE BOX American Version Floodlight Mounting Plate Installation Camera Hook Central Central Wire Nuts Screw Screw Cap Manual Plate Screws... - Page 11 European Version Floodlight Junction Installation Camera Hook Central Central Wire Nuts Screw Screw Cap Manual Plate Screws Note: In order to stream video from Floodlight Camera, you need to make sure the Wi-Fi signal strength is strong at the location you want to install Floodlight Camera.
-
Page 12: Product Description
PRODUCT DESCRIPTION Light Reset button Lens SD card slot Status light American Version European Version Ground... -
Page 13: Installation And Wiring
Power AC 100~240V Solid red light on: the camera network is abnormal Blinking red light: awaiting WiFi connecting Status light Solid blue light on: camera running correctly Blinking blue light: currently connecting Microphone Captures sounds for your video SD card slot Supports local micro SD Card storage (Max.128G) Press and hold the ‘RESET’... -
Page 14: Precautions Before Installation
Tools Needed: Step Ladder Slotted Screwdriver PRECAUTIONS BEFORE INSTALLATION • Step 1 Shut down the circuit breaker in your house. Swich ON/OFF the lights to make sure the electricity in your house is properly shut off. WARNING: Risk of electrucal shock! Electricity is dangerous. - Page 15 Step 2 Two Installation Methods: User can hang Floodlight Camera upside down or install it vertically on the wall. Select the installation method that best suits the position of your junction box. Eave Mount: For upside down installation, turn the camera down to the end when it’s placed vertically, then turn the camera 180°in clockwise direction.
- Page 16 Remember, do hire a professional electrician if you’re uncomfortable working with electrical wiring. Note: If the camera falls off during installation, please don't worry, the camera can be installed back. If you don't know how to install it, please contact us service@iegeek.com...
- Page 17 Wall Mount: For install vertically installation, hang the camera on the junction box with the hook provided then you can free your hands for wiring. American Version European Version To avoid risk of shock, injury or death, always be cautious when working with electricity.
-
Page 18: American Version Installation Steps
AMERICAN VERSION INSTALLATION STEPS • Step 1 Install the mounting plate to the junction box Remove the old Floodlight from the junction box and install the mounting plate to the junction box. The junction box and existing electrical wires are required to Floodlight Camera installation. - Page 19 To avoid risk of shock, injury or death, always be cautious when working with electricity. Remember, do hire a professional electrician if you’re uncomfortable working with electrical wiring. Step 3 Connect neutral and hot wires Use wire nuts to connect Floodlight Camera wires to the rest of the wires from junction box.
- Page 20 To avoid risk of shock, injury or death, always be cautious when working with electricity. Remember, do hire a professional electrician if you’re uncomfortable working with electrical wiring.
- Page 21 Step 4 Insert the central screw 1. Insert the central screw through the center of Floodlight Camera and screw it tightly. 2. Use the central screw cap to cover the central screw to prevent the central screw from rusting.
-
Page 22: European Version Installation Steps
EUROPEAN VERSION INSTALLATION STEPS • Step 1 Remove the waterproof plug and thread 1. Remove the waterproof plug in the junction Box 2. Find the wire hold and thread Waterproof plug Wire hole Note: If you don’t have existing wires outdoors, contact a licensed electrician to run the wires. - Page 23 Step 3 Connect electrical wires to the junction box Unscrew the bolt with a flat-head screwdriver. Connect the Neutral (“N” blue) /Ground (green/green and yellow) / Live(“L” brown) wire to the Neutral / Ground/Live wire connector in the junction box respectively. Secure the wires tightly to prevent wires from falling.
- Page 24 Step 5 Connect wires 1. Connect Ground wire from the Floodlight Camera to the Ground wire from the wire connector in the junction box. 2. Connect the Live / Neutral wire form the Floodlight Camera to the Live / Neutral wire from the wire connector in the junction box respectively.
- Page 25 Step 6 Insert the central screw 1. Insert the central screw through the center of Floodlight Camera and screw it tightly. 2. Use the central screw cap to cover the central screw to prevent the central screw from rusting.
-
Page 26: Installation Angle
INSTALLATION ANGLE • After installation is complete. You can turn the camera knobs on Floodlight Camera to adjust the camera to your desired angle. 15-30° 15-30 degrees is the best angle, the greater the angle, the smaller the PIR detection distance •... -
Page 27: App Download And Camera Settings
APP DOWNLOAD AND CAMERA SETTINGS Step 1 Download ‘ieGeek cam ’ APP Search “ieGeek cam” in App store or google play, or scan below QR Code to download and install on smart phone.(It also compatible with' CloudEdge APP, but there will be some differences as the app is updated, so if you have any... - Page 28 NOTE: Please OPEN 2 permissions below when first setting up the App. 1. Allow ieGeek cam to access mobile cellular data and wireless LAN, or it will be failed to add IP camera. 2. Allow ieGeek cam to receive pushed message, or the cellphone will not receive alarm push when motion detection or audible alarm is triggered.
- Page 29 3. Select 2.4Ghz or 5G WiFi SSID and input password, tap “Next” 4. Select“QR Code Configuration” align the QR code with the camera lens in a distance of 15-25cm until the QR code is recognized. After hearing the sound “Bugu”, tap “ Hear Tone”. 5.
-
Page 30: Function Introduction
FUNCTION INTRODUCTION Parameter settings (alarm settings, image/time/sound Voice intercom (press and hold settings, light schedule, device to talk) share, Installation Guide, check new version, etc.) Real-time video screen Manually capture video clips Turn on/off the microphone Turn on/off the alarm Picture Clarity setting Turn on/off the LED light Full-screen display... -
Page 31: Device Sharing
How others access the Floodlight Camera? Realize this function through ‘Device Share’. 1. Invite your friends to download and install ‘cloudEdge or ieGeek CAM’ APP and log in. 2. Click ‘Device Share’ icon to watch operation video, and follow the steps to finish share device. -
Page 32: Faqs
WIFI signal. It is recommended to move the router to a closer place or add a WIFI amplifier to improve the WIFI performance. 4. Delete the floodlight camera from your Iegeek Cam account and add it again after resetting the device. - Page 33 Q5: What should I do if the phone cannot receive the alert notification? 1. Turn on the push permission of the "Iegeek Cam" APP in the phone system. 2. Ensure that the device's motion detection is turned on successfully.
- Page 34 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference a residential installation.
