- Page 1 All manuals and user guides at all-guides.com Operation Manual Mode demploi High power CD player with FM/AM tuner Lecteur CD de grande puissance avec syntoniseur FM/AM DEH-1500 DEH-15...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com Contents Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, put them away in a safe place for future reference. - Page 3 All manuals and user guides at all-guides.com Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your equipment offers.
-
Page 4: Before You Start
800-421-1404 The serial number is located on the top of this CANADA unit. For your own security and convenience, be Pioneer Electronics of Canada, Inc. sure to record this number on the enclosed war- CUSTOMER SATISFACTION DEPARTMENT ranty card. 300 Allstate Parkway... -
Page 5: Product Registration
HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Section Before You Start Product registration Protecting your unit from theft Visit us at the following site: The front panel can be detached from the head unit to discourage theft. Important 1 Register your product. We will keep the details of your purchase on file to help you refer to ! Never use force or grip the display and the this information in the event of an insurance... -
Page 6: WhatS What
HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Section Whats What Head unit 8 LOCAL/BSM button Press to turn local function on or off. 1 CLOCK button Press and hold to turn BSM function on or Press to change to the clock display. off. -
Page 7: Power On/Off
HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Section Power ON/OFF Turning the unit on % Press SOURCE to turn the unit on. When you select a source the unit is turned Selecting a source You can select a source you want to listen to. To switch to the built-in CD player, load a disc in this unit (refer to page 10). -
Page 8: Tuner
HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Section Tuner Listening to the radio # If you press and hold c or d you can skip broadcasting stations. Seek tuning starts as soon as you release the buttons. Note When the frequency selected is being broadcast in stereo the stereo (5) indicator will light. -
Page 9: Tuning In Strong Signals
HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Section Tuner Tuning in strong signals Local seek tuning lets you tune in only those radio stations with sufficiently strong signals for good reception. Press LOCAL/BSM to turn local seek tuning on. LOC appears in the display. -
Page 10: Built-In Cd Player
HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Section Built-in CD Player Playing a CD Notes ! The built-in CD player plays one, standard, 12- cm or 8-cm (single) CD at a time. Do not use an adapter when playing 8-cm CDs. ! Do not insert anything other than a CD into the CD loading slot. -
Page 11: Pausing Cd Playback
HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Section Built-in CD Player Press 5 to turn repeat play off. The track currently playing will continue to play and then play the next track. Note If you perform track search or fast forward/re- verse, repeat play is automatically cancelled. -
Page 12: Audio Adjustments
HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Section Audio Adjustments Introduction of audio # If the balance setting has been previously ad- justed, BAL will be displayed. adjustments Press a or b to adjust front/rear speak- er balance. Each press of a or b moves the front/rear speaker balance towards the front or the rear. -
Page 13: Adjusting Equalizer Curves
HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Section Audio Adjustments ! CUSTOM is an adjusted equalizer curve Note that you create. If you make adjustments when a curve other than ! When EQ FLAT is selected no supplement CUSTOM is selected, the newly adjusted curve or correction is made to the sound. -
Page 14: Adjusting Loudness
HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Section Audio Adjustments Note Precaution If you make adjustments when a curve other than When the F.I.E. function is deactivated, the rear CUSTOM is selected, the newly adjusted curve speakers output sound of all frequencies, not just will replace the previous curve. - Page 15 HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Section Audio Adjustments Press AUDIO to select SLA. Press AUDIO until SLA appears in the display. Press a or b to adjust the source vo- lume. Each press of a or b increases or decreases the source volume.
-
Page 16: Other Functions
HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Section Other Functions Setting the clock Use these instructions to set the clock. Press SOURCE and hold until the unit turns off. Press AUDIO repeatedly until clock ap- pears in the display. Press c or d to select the segment of the clock display you wish to set. -
Page 17: Additional Information
! Do not attach labels, write on or apply che- blem. If the error cannot be corrected, contact micals to the surface of the discs. your dealer or your nearest Pioneer Service ! To clean dirt from a CD, wipe the disc with Center. - Page 18 HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Appendix Additional Information ! This unit conforms to the track skip func- tion of the CD-R/CD-RW disc. The tracks containing the track skip information are skipped automatically. ! If you insert a CD-RW disc into this unit, time to playback will be longer than when you insert a conventional CD or CD-R disc.
-
Page 19: Specifications
HHHHHHHHHHHHHH All manuals and user guides at all-guides.com Appendix Additional Information Specifications High ........+11 dB (100 Hz), +11 dB (10 kHz) General (volume: 30 dB) Power source ......14.4 V DC (10.8 15.1 V al- lowable) CD player Grounding system .... - Page 20 300 Allstate Parkway, Markham, Ontario L3R OP2, Canada Copyright © 2002 by Pioneer Corporation. TEL: (905) 479-4411 All rights reserved. PIONEER ELECTRONICS DE MEXICO, S.A. de C.V. Publication de Pioneer Corporation. San Lorenzo 1009 3er. Piso Desp. 302 Copyright © 2002 Pioneer Corporation.
- Page 21 All manuals and user guides at all-guides.com DEH-1500 DEH-15 This product conforms to CEMA cord colors. Le code de couleur des câbles utilisé pour ce produit est conforme à CEMA. Los colores de los cables este producto se conforman con el código de colores CEMA. Printed in China Imprimé...
- Page 22 All manuals and user guides at all-guides.com Connecting the Units Note: • This unit is for vehicles with a 12-volt battery and • When this product’s source is switched ON, a con- negative grounding. Before installing it in a recre- trol signal is output through the blue/white lead.
- Page 23 All manuals and user guides at all-guides.com <ENGLISH> Power amp (sold separately) This Product Rear output Fuse Connecting cords with RCA pin plugs (sold separately) Antenna jack Blue/white To system control terminal of the power amp or Auto-antenna relay control terminal (max.
- Page 24 All manuals and user guides at all-guides.com Installation Note: • Before finally installing the unit, connect the • If installation angle exceeds 60° from horizontal, wiring temporarily, making sure it is all connected the unit might not give its optimum performance. up properly, and the unit and the system work (Fig.
- Page 25 All manuals and user guides at all-guides.com Removing the Unit (Fig. 5) (Fig. 6) Frame I nsert the release pin into the hole in the bottom of the frame and pull out to remove the frame. (When reattaching the frame, point the side with a groove downwards and attach it.) Fig.
- Page 26 All manuals and user guides at all-guides.com DIN Rear-mount Installation using the screw holes on the side of the unit 1. Remove the frame. (Fig. 7) Frame Insert the release pin into the hole in the bottom of the frame and pull out to remove the frame.
- Page 27 All manuals and user guides at all-guides.com <ENGLISH> About the fixing screws for the front panel If you do not operate the Detaching and Replacing the Front Panel Function, use the sup- plied fixing screws and fix the front panel to this unit. Fixing screw Fig.
- Page 28 All manuals and user guides at all-guides.com...
