Service Manual
Self-Contained Cuber
Model
IM-200BAB
hoshizakiamerica.com
Number: M076-1004
Issued:5-23-2025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IM-200BAB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hoshizaki IM-200BAB

Summary of Contents for Hoshizaki IM-200BAB

  • Page 1 Service Manual Self-Contained Cuber Model IM-200BAB Number: M076-1004 hoshizakiamerica.com Issued:5-23-2025...
  • Page 2 WARNING america america NOTE:...

  • Page 3: Table Of Contents

    IMPORTANT This manual should be read carefully before the appliance is serviced. Read the warnings and guidelines contained in this manual carefully as they provide essential information for the continued safe use, service, and maintenance of the appliance. Retain this manual for any further reference that may be necessary. CONTENTS Important Safety Information ....................

  • Page 4: Important Safety Information

    Important Safety Information WARNING Indicates a hazardous situation which could result in death or serious injury. NOTICE Indicates a situation which could result in damage to the appliance or property. IMPORTANT Indicates important information about the installation, use, and care of the appliance. WARNING precautions including the following: •...
  • Page 5 WARNING, continued NOTICE...

  • Page 6: Construction And Water/Refrigeration Circuit Diagram

    I. Construction and Water/Refrigeration Circuit Diagram A. Construction 1. Air-Cooled Model (BAB)

  • Page 8: Water/Refrigeration Circuit Diagram

    B. Water/Refrigeration Circuit Diagram 1. Air-Cooled Model (BAB)

  • Page 9: Sequence Of Operation And Service Diagnosis

    II. Sequence of Operation and Service Diagnosis A. Sequence of Operation Flow Chart "IM" Control Board 1. 30-Sec. 3. Freeze Cycle 2. Harvest Cycle Cycle Startup Steps Cycle Startup Water Tank Closed (Actuator Motor PS) Comp Comp Comp Shutdown and Restart Sequence Flow Chart 1.

  • Page 10: Sequence Of Operation

    B. Sequence of Operation 1. Startup Cycle 2. Harvest Cycle Initial Harvest Initial Harvest after Bin Control Normal Harvest after Power On Initiated Restart Note Setting All WT WT>48°F (9°C) WT>48°F (9°C) 3. Freeze Cycle Initial Freeze Initial Freeze after Bin Control Normal Freeze after Power On Initiated Restart...

  • Page 11: Shutdown

    temp. (absolute value) × time (min.) = (absolute value of CB Setting 2) × (CB Setting 3) temp. (absolute value) × time (min.) = 382.5 4. Shutdown Comp WT–...

  • Page 12: Service Diagnosis Table

    C. Service Diagnosis Table No Ice Production - Possible Cause...
  • Page 13 Low Ice Production - Possible Cause Long Harvest Cycle Long Freeze Cycle Slab Does Not Break Into Separate Cubes - Possible Cause Cubes Drop Separately - Possible Cause Imperfect Ice Production - Possible Cause Large-Hole Cubes - Possible Cause (Also see III.H.1. Dimple Diameter")
  • Page 14 Large-Hole Cubes - Possible Cause (Also see III.H.1. Dimple Diameter") Cloudy Cubes - Possible Cause...

  • Page 15: Bin Control Check And Cleaning

    D. Bin Control Check and Cleaning 1. Bin Control Check Fig. 1...

  • Page 16: Bin Control Cleaning

    2. Bin Control Cleaning WARNING CHOKING HAZARD:...

  • Page 17: Evaporator Thermistor Check

    E. Evaporator Thermistor Check Comp...

  • Page 18: Controls And Adjustments

    III. Controls and Adjustments A. Control Switch B. Control Board NOTICE...

  • Page 19: Control Board Layout

    1. Control Board Layout • CN16 Connector • CN11 Connector • CN13 Connector • CN10 Connector • CN9 Connector • CN4 Connector • RESET Button • CN1 Connector • SERVICE 1 Button • SERVICE 2 Button • CN2 Connector • CN5 Connector •...

  • Page 20: Control Buttons

    C. Control Buttons 1. RESET Button 2. SERVICE 1 and SERVICE 2 Buttons NOTICE! Do not decrease dimple size below 3/16" (5 mm). Fig. 2...

  • Page 21: Control Board Settings

    D. Control Board Settings NOTICE Control Board (CB) Setting Menu IM-200BAB Category No. Item Range Default DO NOT ADJUST DO NOT ADJUST...
  • Page 22 Control Board (CB) Setting Menu IM-200BAB Category No. Item Range Default...
  • Page 23 Control Board (CB) Setting Menu IM-200BAB Category No. Item Range Default DO NOT ADJUST DO NOT ADJUST DO NOT ADJUST DO NOT ADJUST DO NOT ADJUST DO NOT ADJUST...
  • Page 24 Control Board (CB) Setting Menu IM-200BAB Category No. Item Range Default...

  • Page 25: Control Board Information Display

    E. Control Board Information Display Control Board Information Display History Cleared by Pressing and Holding SERVICE 1 and SERVICE 2 Buttons Simultaneously for 5 Sec. when Item Value No. Item Description is Displayed?

  • Page 26: Control Board Model Code Setting

    Control Board Information Display History Cleared by Pressing and Holding SERVICE 1 and SERVICE 2 Buttons Simultaneously for 5 Sec. when Item Value No. Item Description is Displayed? F. Control Board Model Code Setting 1. Control Board Replacement WARNING...

  • Page 27: Checking Or Changing The Control Board Model Code

    2. Checking or Changing the Control Board Model Code G. Error Codes...
  • Page 28 Error Codes Error Problem Corrective Action/Reset Details Code...

  • Page 29: Quick Adjustments

    Error Codes Error Problem Corrective Action/Reset Details Code H. Quick Adjustments 1. Dimple Diameter NOTICE! Do not decrease the dimple diameter below 3/16" (5 mm). a) To increase dimple diameter: b) To decrease dimple diameter: NOTICE! Do not decrease dimple size below 3/16"...
  • Page 30 Normal Position Drain Position Fig. 3...

  • Page 31: Refrigeration Circuit And Component Service Information

    IV. Refrigeration Circuit and Component Service Information WARNING • • • CHOKING HAZARD: • A. Refrigeration Circuit Service Information WARNING NOTICE 1. Refrigerant Recovery...
  • Page 32 2. Brazing WARNING NOTICE 3. Evacuation and Recharge (R-404A) IMPORTANT...

  • Page 33: Component Service Information

    NOTICE! To prevent compressor damage, use a throttling valve or liquid dispensing device to add the remaining liquid charge through the low-side access valve with the appliance running. B. Component Service Information NOTICE Component Notes...

  • Page 34: Maintenance

    V. Maintenance WARNING • • • • CHOKING HAZARD: Maintenance Schedule Frequency Area Task...

  • Page 35: Preparing The Appliance For Periods Of Non-Use

    VI. Preparing the Appliance for Periods of Non-Use NOTICE 1. Remove the water from the icemaker water supply line: 2-inch (5-cm) air gap Floor Fig. 4 Drain...

  • Page 36: Disposal

    2. Drain the water tank: VII. Disposal IMPORTANT...

  • Page 37: Technical Information

    VIII. Technical Information 1. IM-200BAB AC SUPPLY VOLTAGE 115/60/1 AMPERAGE 7.5 A ( 5 Min. Freeze AT 104°F / WT 80°F) MINIMUM CIRCUIT AMPACITY 15 A MAXIMUM FUSE SIZE 15 A APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (°F) PER 24 HR.

  • Page 38: Performance Data

    1. IM-200BAB APPROXIMATE ICE WATER TEMP. (ºF/ºC) AMBIENT TEMP. PRODUCTION PER 24 HR. (ºF/ºC) 50/10 70/21 90/32 70/21 80/27 90/32 lbs./day kg./day 100/38 APPROXIMATE ELECTRIC 70/21 CONSUMPTION 80/27 90/32 watts 100/38 APPROXIMATE WATER 70/21 0.14 0.14 0.13 CONSUMPTION PER 24 HR.

  • Page 39: Wiring Diagram

    C. Wiring Diagram 1. IM-200BAB...
