- Page 1 QV Operator's Manual Models: QVSSOH QVSSOV QVSSOHSP QVSSOVSP QV900HSP Push and Sell-Propelled QV Quiet vacuums 27831517EN_B...
-
Page 2: Table Of Contents
Table of Contents: California Proposition 65............. 3 Identifying Your Unit............3 QV Decals................3 100443................4 831265................4 80133776................4 80133777................5 810656................5 831259................5 831258................6 831270................6 5110549................6 80133770................6 5110550................7 Features and Controls ............7 Nozzle Height Adjustment.......... -
Page 3: California Proposition 65
California Proposition 65 ENGINE REFERENCE DATA Engine Make: Engine Model: WARNING This product can expose you to chemicals including Engine Type/ gasoline engine exhaust, which is known to the State of Specifications: California to cause cancer and carbon monoxide, which Engine Code/Serial is known to the State of California to cause birth defects Number:... - Page 4 80133776 80133777 810656 831259 (push units) OR 831258 (self-propelled units) 831270 (Self-propelled units only) 5110549 80133770 5110550 100443 831265 Read Manual Read and understand the Operator’s Manual before using this unit. Know the location and function of all controls. Eye Protection Damage to the eyes hazard.
- Page 5 Breathing Protection Spark Plug Dust inhalation hazard: Always wear personal protective Before repairing/maintaining the machine, shut off the engine, equipment when operating. wait for the rotating parts to stop completely and disconnect the spark plug wire. Training Required 810656 Do not operate this machine unless you are trained. Consult technical literature before performing technical repairs or maintenance.
- Page 6 831258 Self-propelled units only. See the Drive Direction Shifter section. 5110549 Belt Drive Warning: Dismemberment hazard. Keep hands away from belts and pulleys. Do not open or remove safety shields/ guards while engine is running See Nozzle Height Adjustment section. Blade Warning Debris bag buckle instructions. Unbuckle the four debris bag clips, and the bag will drop.
-
Page 7: Features And Controls
Features and Controls Warning: Risk of cutting fingers, hand, or foot. Hands and Feet Distance Keep hands and feet a safe distance from hazard. 5110550 Thrown Objects Warning: Thrown objects hazard. Do not use without a chute or debris bag. This unit is capable of throwing objects and debris. -
Page 8: Nozzle Height Adjustment
Nozzle Height Adjustment Run the unit at the lowest RPM required to pick up debris. Running at high RPM speeds will not hurt the unit, but will produce additional dust and noise. Drive Controls Self-propelled units only: Squeeze both levers at the same time to drive straight. -
Page 9: Initial Setup
Initial Setup Install the Front Nozzle Install the Upper Handle DANGER The impeller blades are sharp! Wear heavy-duty gloves during nozzle installation. Avoid contact with the impeller. 1. Install the front nozzle (A, Figure 9). Thread the bolt (B) through the housing, then through the nozzle plate. 1. -
Page 10: Starting The Unit
Debris Bag Care CAUTION Check engine oil and gasoline levels, and refill or refuel if CAUTION necessary. Do not place the debris bag on or near a hot surface, such as the engine. DANGER Run engine at half throttle for first 30 minutes of operation to Evaluate the area to be operated. -
Page 11: Replacing The Drive Belt
7. Self-propelled units only: Slide the belt back into the groove on the impeller pulley, and walk the belt back onto the drive pulley. Retighten the bearing bolts if necessary. 8. Reinstall the nozzle assembly. Replacing the Drive Belt CAUTION Impeller is sharp! Wear heavy-duty gloves during maintenance. -
Page 12: Troubleshooting
2. Remove the debris bag. 3. Adjust the drive cable barrel length. To adjust the barrel length, move the barrel nut (A, Figure 13) up or down each drive cable. To increase cable tension, move the barrel nut downwards towards the transmission. To decrease cable tension, move the barrel nut up towards the drive controls. - Page 13 Problem Cause Solution Engine will not start. Engine switch is in OFF Check engine switch. position. Check throttle position. Throttle in OFF position. Check engine Choke Engine is not in full lever. Choke position. Refuel the engine with Engine is out of fresh gasoline.
-
Page 14: Specifications
Specifications QV Dimensions Length 63" (160 cm) Width 33" (83.8 cm) Height 51" (129.5 cm) Maximum Operating Slope 20° Model Weight QV550H 175 lbs (79.4 kg) QV550V 182.5 lbs (83 kg) QV550HSP 226 lbs (102.5 kg) QV550VSP 234 lbs (106 kg) QV900HSP 248 lbs (112.5 kg) Engine Specifications...
