SAFETY INSTRUCTIONS Intended Use The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. Please check the packaging and appliance on arrival to make sure everything is intact to ensure safe operation. If you find any damage, please contact the retailer or dealer.
Page 3
READ AND SAVE THESE INSTRUCTIONS CAUTION Read Rules for Safe Operation and Instructions Carefully. ● This appliance can be used by children aged from 8 ● years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 4
WARNING If the supply cord is damaged, it must be replaced by ● manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. To protect against the risk of electrical shock, do not ● immerse the unit, cord or plug in water or other liquid.
PRODUCT OVERVIEW Part Name Grille lock Blade Body lock nut Rear grille Fastening screw Remote control Blade Lower pole Chassis Front grille Chassis screw NOTE Pictures in the manual are for reference only, and the product depends on real objects in the packing box.
PRODUCT INSTALLATION Assembly Instructions NOTE Before installation, first remove 7-shape screws from the pole, remove the Spinner and Plastic nut from the motor shaft, and then install. 1 Chassis installation Align the lower pole and the chassis, and then fasten securely with chassis screws. Clockwise 2 Pole installation 2.1 Pull out and fix the internal pole (column) after adjusting the height by way of...
Page 8
3 Rear grille installation 3.1 Please take out the grille lock nut and blade lock nut from the motor shaft first. Operation essentials: First fix the motor shaft by hand and then loosen the blade lock nut clockwise. Then unscrew the lock nut of the grille counterclockwise. Tighten Loosen 3.2 Hang the rear grille on the motor;...
Page 9
4 Blade installation Fix the blade on the motor shaft with the blade lock nut. Press the blade Turn counterclockwise inwards firmly Convex to blade concave Tighten Fix the blade Rotate the blade lock nut with the left hand counterclockwise with the right hand...
Page 10
5 Installation of Front Grill 5.1 From top to bottom align the clips of the front grill with the uppermost mesh of the rear grill. After the alignment is correct, look from back to front according to the diagram. Mesh Clip Mesh Clip...
OPERATION INSTRUCTIONS Button description Button Button name Function description • Press in the standby state to enter power-on state. On/Standby • Press in the power-on state to enter standby state. • In the power-on state, press this button to cycle through normal → Wind mode natural →...
Description of lights Icon Name Display status Low speed Lights up when the fan is turned on and the speed is in the low level Lights up when the fan is turned on and the speed is in the medium Medium speed level High speed...
Description of remote control buttons • Point the remote controller at the receptor on body of the fan and press the desired button. The remote controller will work at distances of up to roughly 5 meters and the angle of 30 degree included between right and left from the receptor. •...
Batteries Installation Battery not included in the packaging 1 Slide the battery compartment cover. Fig 1 2 Insert the batteries, and make sure that the batteries are placed as shown in the Fig 2. Fig 2 3 Slide back the battery cover. Fig 3 NOTE Use alkaline batteries of type “AAA”.
CLEANING AND MAINTENANCE • Cut off the power and wait for two minutes before cleaning. • After cleaning and maintenance, wait until it is fully dry before using it or storing it. • It is forbidden to directly rinse the body with water. Please wipe the surface lightly with a soft cloth containing neutral detergent and then dry it.
TROUBLESHOOTING Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the table below carefully in order to save your time and money that may cost for calling to the service center.
Low Voltage Directive: 14 / 35 / EU ErP Directive 09 / 125 / EC CE Marking: 93 / 68 / EEC RoHS Directive: 11 / 65 / EU & 15 / 863 / EU The detailed declaration of conformity can be found at www.morris.gr...
