- Page 1 EX-500C HDMI™ Extender 1080p with Follow us on Youtube and Facebook Bi-directional IR up to 150m U SER M ANUAL www.orei.com...
-
Page 2: Table Of Contents
Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions Application Example FAQs & Troubleshooting Thank you for purchasing this product For optimum performance and safety, please read these instructions care- fully before connecting, operating or adjusting this product. Please keep this manual for future reference. -
Page 3: Registration Page
OREI Live Technical Support Hours US team (US/Canada/Mexico): Monday-Friday, 9 a.m. - 5 p.m. Central Time Support Email - info@orei.com | Support Number - 877-290-5530 Chat Live on www.orei.com Send us an instant message now. Our Technical Support Team will re- spond momentarily. -
Page 4: Introduction
Introduction The EX-500C HDMI Extender can extend media signals up to 150m/492ft over CAT6/7 cable at 1080p@60Hz. It is HDMI 1.3 & HDCP 1.4 compliant, offering a 4.95Gbps video bandwidth. The Transmitter includes an HDMI Output for a local display connection. Bi-directional IR control makes it easy to control the connected devices from either location. -
Page 5: Features
4. Extend media signal up to 150m/492ft over a CAT 6/7 cable 5. HDMI loop out at the Transmitter to connect a local display 6. Bi-directional IR control 7. PCM2.0 audio support 8. Compact and rugged design Package Contents EX-500C Transmitter 1pcs EX-500C Receiver 1pcs IR Blaster Cable (1.5m) 1pcs IR Receiver Cable (1.5m) -
Page 6: Specifications
Specifications Technical HDMI Compliance HDMI 1.3 HDCP Compliance HDCP 1.4 Video Bandwidth 4.95Gbps Video Resolution Up to 1080p@60Hz, 1920x1200@60Hz Color Space RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 Color Depth 8-bit Audio Formats PCM 2.0 IR Level 5Vp-p IR Frequency Wideband 20K-60KHz Transmission 150m/492ft for 1080p@60Hz over CAT6/6a cable Distance... - Page 7 Specifications Connection Input: 1× HDMI [Type A, 19-pin female] Output: 1× HDMI [Type A, 19-pin female] Transmitter 1× CAT [RJ45] Control: 1× IR IN [3.5mm audio jack] 1× IR OUT [3.5mm audio jack] Input: 1× CAT [RJ45] Output: 1× HDMI [Type A, 19-pin female] Receiver Control: 1×...
-
Page 8: Operation Controls And Functions
Operation Controls and Functions Transmitter Panel CAT OUT IR IN IR OUT DC 5V Name Function Description Connect a CAT 6/7 cable. The other end connects to the CAT OUT Receiver IR IN Connect the IR Receiver cable IR OUT Connect the IR Blaster cable Connect a media device such as DVD player, Streaming device, etc. - Page 9 Operation Controls and Functions Name Function Description Connect a CAT 6/7 cable. The other end connects to the Trans- CAT IN mitter IR OUT Connect the IR Blaster cable IR IN Connect the IR Receiver cable Connect a display device such as TV, Monitor, Projector, etc. Power LED The Green LED will light up when Receiver is powered on.
-
Page 10: Application Example
Application Example CAT OUT IR IN IR OUT DC 5V Transmitter Power Supply Blu-ray Player IR Blaster Monitor CAT6/6a IR Receiver Power Supply Receiver DC 5V IR IN IR OUT CAT IN The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. -
Page 11: Faqs & Troubleshooting
Receiver. They cannot be connected to a network switch. Still have some questions? Please feel free to contact us at: info@orei.com. OR Fill out the form on the ‘Contact Us’ page on the website. Our team will be more than happy to help you. - Page 12 HDMI™ Extender 1080p with Bi-directional IR up to 150m EX-500C www.orei.com © 2024...
