Page 1: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS PRODUCT FEATURES IMPORTANT SAFETY INSTRUCTIONS PRODUCT OVERVIEW Control Panel Overview Parts Accessories INSTALLATION Before Installing the Range Installing the Range Providing Adequate Gas Supply Connecting the Range to Gas Electrical Connections Sealing the Openings Assembling the Surface Burners Checking Ignition of the Surface Burners Leveling the Range... -
Page 2: Product Features
PRODUCT FEATURES PRODUCT FEATURES Multiple Gas Burner Sizes Choose a burner to fit the size of the cookware. Cooking multiple items at once is possible by using different burners at the same time. Safe and Convenient Gas Range Provides safety and convenience for cooking. ®... -
Page 3: Important Safety Instructions
Always contact your service agent or manufacturer about problems that you do not understand. Download this owner's manual at: http://www.lg.com This is the safety alert symbol. This symbol alerts you to potential hazards that can result in property damage and/or serious bodily harm or death. -
Page 4: Important Safety Notice
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of the range tipping over, the range must be secured by properly installing the anti-tip device. To check that the anti-tip bracket is properly installed: Remove any items on the cooktop. Grasp the top rear edge of the range back guard and carefully attempt to tilt it forward. Verify that the anti-tip device is engaged. - Page 5 IMPORTANT SAFETY INSTRUCTIONS WARNING Large scratches or impacts to glass doors can lead to broken or shattered glass. Stepping, leaning or sitting on the doors or drawers of this range can result in serious injuries and also cause damage to the range. Do not allow children to climb or play around the range.
-
Page 6: Installation Safety Precautions
IMPORTANT SAFETY INSTRUCTIONS INSTALLATION SAFETY PRECAUTIONS Have the installer show you the location of the range gas shut-off valve and how to shut it off if necessary. WARNING Make sure your range is properly installed and grounded by a qualified installer, according to the installation instructions. -
Page 7: Surface Burners
IMPORTANT SAFETY INSTRUCTIONS WARNING To shut off the gas supply to the range, close the range gas shutoff valve by turning it clockwise. Pressure regulator Lever open (in use) Remove this label Adapter( "-14 NPT) Range gas shut-off valve " Adapter Installer: Inform the consumer of the location of the gas shut-off valve. - Page 8 IMPORTANT SAFETY INSTRUCTIONS CAUTION Be sure that all surface controls are set in the Off position prior to supplying gas to the range. Never leave the surface burners unattended at high flame settings. Boilovers may cause smoke and greasy spillovers that may ignite. Always turn the knobs to the Lite position when igniting the top burners and make sure the burners have ignited.
-
Page 9: Self-Cleaning Oven
10 IMPORTANT SAFETY INSTRUCTIONS BROILER Always use a broiler pan and a grid for excess fat and grease drainage. This will help to reduce splatter, smoke, and flare-ups. WARNING When using the broiler, the temperature inside the oven will be extremely high. Take caution to avoid possible burns by: Keeping the door closed when broiling (refer to Broil section of the manual) Always wearing oven mitts when inserting or removing food items... - Page 10 IMPORTANT SAFETY INSTRUCTIONS WARNING Do not line oven walls or bottom with aluminum foil or allow them to contact exposed heating elements in the oven. Doing so could create a fire hazard or cause damage to the range. Do not use the oven for storage. Items stored in the oven can catch on fire. Keep the oven free from grease buildup.
-
Page 11: Control Panel Overview
OPERATION Control Panel Overview Model LRGN6323* NOTE For best results, press buttons in the center, even when activating a button's secondary function. The buttons may not work properly if pressed too far from the center. 1 Features 4 Start Button 5 Clear Off / Control Lock 2 Oven Controls 3 Number Buttons or +/- Buttons... -
Page 12: Product Overview
Optional accessories are not included with the unit, these accessories are available for purchase at www.lg.com web page. Contact LG Customer Service at (LG U.S.) 1-800-243-0000 or (LG Canada) 1-888-542-2623, if any accessories are missing. For your safety and for extended product life, only use authorized components. -
Page 13: Installation
INSTALLATION 14 INSTALLATION Before Installing the Range Make sure the range is properly installed and grounded by a qualified installer, according to the installation instructions. Any adjustment and service should be performed only by qualified gas range installers or service technicians. -
Page 14: Installing The Range
15 INSTALLATION Installing the Range Choosing the Proper Location Do not locate your range where it may be subject to Unpacking and Moving the Range strong drafts. Any openings in the floor or wall behind the range should be sealed. Make sure the openings CAUTION around the base of the range that supply fresh air for combustion and ventilation are not blocked by... -
Page 15: Dimensions And Clearances
INSTALLATION 16 Dimensions and Clearances Provide proper clearance between the range and adjacent combustible surfaces. These dimensions must be met for safe use of your range. The location of the electrical outlet and pipe opening (see Gas Pipe and Electrical Outlet Locations, page 14) may be adjusted to meet specific requirements. -
Page 16: Providing Adequate Gas Supply
17 INSTALLATION Providing Adequate Gas Installing the Anti-tip Device Supply Anti-tip Wall plate bracket The range is designed to operate at a pressure of Screw must 5" of water column on natural gas or 10" of water enter wood or concrete column on LP. -
Page 17: Connecting The Range To Gas
INSTALLATION 18 Connecting the Range to Gas When all connections have been made, be sure all range controls are in the OFF position and the Shut off the range gas supply valve before pressure regulator valve is open before turning removing the old range and leave it off until the on the main gas supply valve. -
Page 18: Electrical Connections
19 INSTALLATION Electrical Connections Do not use an adapter plug. Disconnecting of the power cord places undue strain on the adapter and leads to eventual failure of the adapter ground Electrical Requirements terminal. 120 Volt, 60 Hz, properly grounded dedicated circuit Installation must conform with local codes or, in the protected by a 15 or 20 Amp circuit breaker, or slow absence of local codes, with the National Fuel Gas... -
Page 19: Assembling The Surface Burners
INSTALLATION 20 Assembling the Surface Quality of Flames Burners The combustion quality of the burner flames needs to be confirmed visually. CAUTION A Yellow flames - Call for service. Do not operate the burners without all parts in place. B Yellow tips on outer cones - This is normal for LP gas. -
Page 20: Leveling The Range
21 INSTALLATION Leveling the Range Checking Operation of Bake / Broil Burners Level the range by adjusting the leveling legs. To check ignition of the Bake burner, follow the steps Extending the legs slightly may also make it easier to below insert the rear leg into the anti-tip bracket. -
Page 21: Removing/Assembling Ovendoor Handle
INSTALLATION 22 Removing/Assembling Oven Removing Oven Door Handle Door Handle Loosen the set screws located on the lower side of the handle with a 3/32 in. Allen wrench Before Removing/Assembling the and remove the handle. Oven Door Handle • Tools Needed - 3/32"...
