- Page 1 Array Series Operation Manual Rev. 1.0 - 2025 Array Series PCCbox - Series Self Powered Loudspeakers Keep these important operating instructions. Check www.tecnare.com for updates.
- Page 3 General Information PCCbox - Array Series - Operation Manual Ver.: 1.0_EN 03/2025 ©EXEL ACOUSTICS SL; all rights reserved The accuracy of the information within this manual has been thoroughly verified at the time of publication. Nonetheless, no assurance is provided regarding its correctness. Exel Acoustics SL accepts no responsibility for any errors or inaccuracies that may appear in this manual or the products and software described in it.
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Before using our product, be sure to carefully read the manual and safe Instructions. Keep this document with the device at all times. 1. Read these instructions 3. Hearing damage warning: 1.9. Prolonged exposure to sound pressure levels (SPL) 2. -
Page 5: Symbols Used
SYMBOLS USED CAUTION: This symbol indicates a potential risk of electric shock or harm to persons and equip- ment. Instructions accompanied by this symbol must be strictly observed. CAUTION: This symbol highlights essential operational procedures that must be carefully followed to ensure proper equipment function and prevent performance issues. -
Page 6: Declaración De Conformidad
DECLARACIÓN DE CONFORMIDAD DECLARATION OF CONFORMITY EXEL ACOUSTICS SL CL Montes de Toledo, 33. Pol. Ind. Señorío de Illescas. 45200 – Illescas (Toledo), España (Spain). RII_AEE/WEEE: 9178; ENV/2023/000014126 Declara que los productos de la familia ARRAY PCCbox-Series y sus respectivas opciones, cumple con las Di- rectivas: Declare under our sole responsibility that the Array PCCbox-Series family of products, comply with relating Direc- tives:... -
Page 7: Fcc Supplier's Declaration Of Conformity (Sdoc)
Attention FCC SUPPLIER’S DECLARATION OF CONFORMITY (SDoC) We, Exel Acoustics SL of CL Montes de Toledo 33, P.I. Monte Boyal, 45200, Illescas, Toledo, Spain, declare under our sole responsibility that the PCC-NET Technology range of products complies with Part 15 of the FCC Rules. Products covered by this declaration have model numbers of the form PCCbox-MPXX where “XX”... - Page 8 Array PCCbox Series www.tecnare.com...
-
Page 9: Table Of Contents
Array PCCbox Series Table of Contents IMPORTANT SAFE INSTRUCIONS _____________________________________________________________ 4 SYMBOLS USED ___________________________________________________________________________ 5 DECLARACIÓN DE CONFORMIDAD ___________________________________________________________ 6 DECLARATION OF CONFORMITY _____________________________________________________________ 6 FCC SUPPLIER’S DECLARATION OF CONFORMITY (SDoC) ________________________________________ 7 1. INTRODUCTION _________________________________________________________________________ 10 ® 1.1. Welcome to Tecnare ______________________________________________________________ 10 1.2. -
Page 10: Introduction
® ® Thank you for choosing the Tecnare Array PCCbox Series – a premium “Made in Spain” professional audio solution from Exel Acoustics SL. To maximise the performance and longevity of your PCCbox system, please read this manual carefully before installation or operation. -
Page 11: Overview The Array-Pccbox Series
1.2. Overview the Array-PCCbox Series ® The Tecnare Array PCCbox Series represents the pinnacle of Spanish-engineered, self-powered sound reinforcement, combining full-range curvilinear arrays and high-output subwoofers into a seamless, scalable ecosystem. Designed for professionals who demand tour-grade reliability and plug-and-play sophistication, this series comprises: •... -
Page 12: Mp4 Rear Panel
Operation Manual Array PCCbox Series 2.1. MP4 REAR PANEL All Array PCCbox Series enclosures (CLa21, CLa21Plus, SW-18VR) feature the unified MP14 Power Module amplifier, designed for professional touring and installation use. LDC Screen. The colour LCD interface provides access to all speaker operating modes, DSP parameters and net- working settings. -
Page 13: Dsp Overview
Operation Manual Array PCCbox Series 3. DSP OVERVIEW The PCCbox Series features a sophisticated onboard DSP system powered by an Analog Devices processor, giving you full control over your sound. The user has access to eight parametric EQs for precise tonal shaping, up to 600 milliseconds of delay for perfect timing alignment, and a suite of monitoring tools –... -
Page 14: Power Connectors
Operation Manual Array PCCbox Series CAUTION: Earth/Ground Connection Safety: The earth/ground conductor is essential for safe operation and must never be disconnected. The PCCbox Series features an intelligent universal power supply with active Power Factor Correction (PFC), automatically adapting to mains voltages from 100V to 240V AC worldwide. This advanced design ensures efficient operation across different electrical infrastructures while protecting your investment. -
Page 15: Power Cable Assembly
Operation Manual Array PCCbox Series CAUTION: Before plugging in, always inspect your PCCbox’s AC inlet for secure fitting and any signs of damage like cracks or corrosion. 4.2. Power Cable Assembly Each PCCbox includes one Neutrik powerCON TRUE1 input connector empowers you to create tailored power cables that perfectly match your installation requirements. -
Page 16: Powering On Pccbox
Operation Manual Array PCCbox Series NOTE: RCCB Sensitivity: Some residual current circuit breakers (RCCBs) may nuisance-trip due to high-frequency noise between line and neutral conductors, or capacitance imbalances in cabling. For PCCbox systems: • Specify HFI-resistant RCCBs (e.g., Type B or B+) •... -
Page 17: Amplification And Audio Connectivity
Operation Manual Array PCCbox Series 5. AMPLIFICATION AND AUDIO CONNECTIVITY Your PCCbox features dual balanced 3-pin XLR connections for professional audio integration. The line-level input accepts signals up to +21dBu and has an input impedance of 20kΩ impedance, compatible with external audio equip- ment such as mixing consoles and processors. -
Page 18: Amplifier Cooling System
Operation Manual Array PCCbox Series For example: Consider a mixing console with a 100Ω output impedance driving a daisy-chain of PCCbox loudspeakers. To main- tain the recommended 10:1 impedance ratio, the combined input impedance of all connected PCCbox units should total at least 1kΩ. -
Page 19: Network Configuration For Pccbox Devices
Operation Manual Array PCCbox Series The PCCbox series simplifies network configuration through intelligent automatic detection of subnet parameters. In most cases, the system will self-configure appropriately without user intervention. Should any IP conflicts arise, the PCC-Net interface will provide clear notifications and guidance for resolution. - Page 20 Operation Manual Array PCCbox Series Implementation: • Connect each MP14 directly to a central Gigabit switch • Use Cat6 cables for runs exceeding 15 metres • Enable QoS prioritisation for PCC-Net traffic www.tecnare.com...
-
Page 21: Loudspeaker Preset
Operation Manual Array PCCbox Series 7. LOUDSPEAKER PRESET Your PCCbox Series loudspeakers include six optimised factory presets, professionally tuned by Tecnare engi- neers for various applications. These embedded presets deliver instant performance for common scenarios while maintaining system protection. Additionally, two user presets allow custom configurations: •... -
Page 22: Sw-18Vr Operating Modes
Operation Manual Array PCCbox Series By maintaining the system’s full bandwidth capabilities while compensating for array interactions, this mode en- sures consistent tonal balance across all listening positions. The preset is equally effective in both flown and ground- stacked configurations where precise impact point alignment is required. -
Page 23: Calibration: Array Eq Filters
Operation Manual Array PCCbox Series • Two or three subwoofers create directional bass control • Rear attenuation reduces stage levels by 8-12dB • Phase-optimised filtering maintains frontal energy These presets require specific cabinet orientations - refer to Section XX for array positioning guidelines and deploy- ment examples to maximise cardioid effectiveness. -
Page 24: Long Distance Compensation (Ldc)
Operation Manual Array PCCbox Series 8.2. LONG DISTANCE COMPENSATION (LDC) The Long Distance Compensation (LDC) filter combines FIR-based EQ processing with per-cabinet gain ad- justment to counteract high-frequency air absorption effects in Line Source deployments. This advanced processing ensures spectral consistency across all audience zones, regardless of throw distance. - Page 25 Operation Manual Array PCCbox Series The LDC’s linear-phase FIR filters require buffer delays to maintain frequency response linearity. This latency be- comes destructive when mixed with uncompensated signals. Consequences of Non-Compliance • Audible comb filtering (most severe 2–8kHz) • 15–25% reduction in system output potential NOTE: This requirement applies regardless of throw distance - even short-throw cabinets must engage LDC if the array uses it.
-
Page 26: Lcd Screen Operation
Operation Manual Array PCCbox Series 9. LCD SCREEN OPERATION The rear-panel LCD screen provides direct access to critical loudspeaker parameters, including operating modes (presets) and network configuration. Navigation and parameter adjustments are performed using the rotary encoder. To operate the interface, rotate the encoder to browse through menus and parameters. When the desired setting is highlighted or framed with a green rectangle, press the encoder to activate edit mode. -
Page 27: Dsp Menu
Operation Manual Array PCCbox Series 9.2. DSP Menu Preset Menu The Preset submenu allows the selection and loading of optimised DSP configurations for different use cases. Navigate by rotating the encoder to browse through the available preset options; the currently highlighted selection is shown at the centre of the display. -
Page 28: Setting Menu
Operation Manual Array PCCbox Series All monitoring data transmits continuously via the network connection while the system remains powered. The LCD display refreshes values at 1-second intervals, with priority given to critical protection alerts when present. Monitoring functions operate independently of audio processing and do not affect system performance. - Page 29 Operation Manual Array PCCbox Series System Reset This function restores all system parameters to their original factory de- faults, including user settings, DSP configurations, network preferences, and stored presets. This action is irreversible and will permanently erase all customized configurations.
-
Page 30: Care And Maintenance
Operation Manual Array PCCbox Series 10. Care and Maintenance To ensure long-term reliability and performance of your PCCbox Self-Powered Loudspeaker, adhere to the follow- ing care guidelines: Environmental Protection • Moisture Avoidance: Do not expose the loudspeakers to rain or excessive humidity. If used outdoors, en- sure they are adequately covered or sheltered during inclement weather. - Page 31 Operation Manual Array PCCbox Series www.tecnare.com...
- Page 32 Array PCCbox Series ©2025 Tecnare Sound Systems. All rights reserved. Array Series Operation manual The contents of this manual are furnished for informational purposes only, are subject to change without notice, and should not be construed as a commitment by Exel Acoustics SL. Exel Acoustics assumes no responsibility or liability for any errors or in- accuracies that may appear in this manual.
- Page 33 Exel Acoustics SL - Tecnare P.I. Señorío de Illescas CL Montes de Toledo, 33 45200 - Illescas (Toledo) SPAIN Operation Manual - Rev.: 1.0 / 2025 www.tecnare.com Copyright © 2025 EXEL ACOUSTICS SL. All Right Reserved...
