Alula RE261 Manual

Resolution Compatibles
Indoor Motion Sensor
commercial battery-powered wall mount sensor with an 85
degree detection range.
Features
• 85° detection range with 78 distinct detection zones
• Range up to 40 feet
• Selectable pulse count 2 or 4
• Designed for commercial applications
• 5 year warranty
Enroll
all variants by entering their serial numbers into the
security panel. Alternatively, the sensor can be enrolled in
one of the following ways:
DSC®, Qolsys® and Interlogix® variants are enrolled by
placing the panel into enrollment mode, and then pulling
the battery tab or tampering the device.
Honeywell® and 2GIG™ variants are enrolled by placing
the panel into wireless enrollment mode and either
removing the battery tab while holding the tamper, or by
tripping the device three times. These sensors must be
enrolled as a "Loop 1" sensor.
Install
by screwing two #5 screws through the unit's mounting
knockouts. Use 2 of the 3 mounting knockouts in the
center of the unit's back to mount on a flat wall. Use 2 of
the 4 corner knockouts to mount the unit in the corner
of a room. Mount the sensor 5ft to 8 ft (1.5m-2.4m) high.
Screw the #8 screw through the wall tamper knockout into
the wall, ensuring that the wall tamper screw is attached to
something solid. Tighten all screws until snug. Enroll the
sensor using the instructions above. Close the cover and
conduct a walk test. After testing, take the unit out of walk
test mode and close the cover again. Finally, finish threading
the white #4 screw until it is snug.
Mounting Tips
• Avoid direct sunlight
• Avoid facing directly to AC or heating vents
• Avoid vapor or high humidity
• Avoid curtains, screens, etc. from blocking detection
• Do not install outdoors
• Mounting height 5ft-8ft (1.5m-2.4m)
Use your panel's installation guide to verify proper system setup.
Indoor Motion Sensor
alarms when motion is sensed. It is a
