■ Specifications and Test Methods
No Item
1 Rated Voltage Shown in Rated value.
2 Appearance No defects or abnormalities.
3 Dimension Within the specified dimensions.
4 Voltage proof No defects or abnormalities.
C≦0.047µF:More than 10000MΩ
5 Insulation Resistance(I.R.)
C＞0.047µF:More than 500Ω·F
C:Nominal Capacitance
6 Capacitance Shown in Rated value.
7 Q or Dissipation Factor (D.F.) 30pF and over:Q≧1000
30pF and below:Q≧400+20C
C:Nominal Capacitance(pF)
8 Temperature No bias Nominal values of the
Characteristics temperature coefficient is
of Capacitance shown in Rated value.
But,the Capacitance Change R6
under 20℃ is shown
in Table A.
Capacitance Drift *
Within +/-0.2% or +/-0.05pF
(Whichever is larger.)
*Not apply to 1X/25V
50% of
the rated
voltage
9 Adhesive Strength No removal of the terminations or other defect
of Termination should occur.
Specification
Temperature High Dielectric
Compensating Type Constant Type
W.V.:100Vdc :0.025max.(C<0.068µF)
W.V.:50/35/25Vdc :0.025max.
W.V.:16/10Vdc :0.035max.
W.V.:6.3/4Vdc :0.05max.(C<3.3µF)
B1,B3 : Within +/-10%
(-25°C to +85°C)
R1,R7 : Within +/-15%
(-55°C to +125°C)
: Within +/-15%
(-55°C to +85°C)
C7 : Within +/-22%
(-55°C to +125°C)
C8 : Within +/-22%
(-55°C to +105°C)
L8 : Within +/-15%
(-55°C to +125°C)
: Within +15/-40%
(+125°C to +150°C)
- B1 : Within +10/-30%
R1 : Within +15/-40%
The rated voltage is defined as the maximum voltage
which may be applied continuously to the capacitor.
When AC voltage is superimposed on DC voltage,
P-P O-P
V or V , whichever is larger, should be maintained
within the rated voltage range.
Visual inspection.
Using calipers. (GRM02 size is based on Microscope)
Measurement Point
Test Voltage
Applied Time
Charge/discharge current : 50mA max.
Measurement Point : Between the terminations
Measurement Voltage : DC Rated Voltage
Charging Time
Charge/discharge current : 50mA max.
Measurement Temperature : Room Temperature
Measurement Temperature : Room Temperature
(1)Temperature Compensating Type
Capacitance
C≦1000pF
:0.05max.(C≧0.068µF)
C＞1000pF
(2)High Dielectric Constant Type
Capacitance
C≦10μF
:0.1max. (C≧3.3µF)
C＞10μF
The capacitance change should be measured after 5 min
at each specified temp. stage.
In case of applying voltage, the capacitance change should be
measured after 1 min with applying voltage in equilibration of
each temp. stage.
Capacitance value as a reference is the value in step 3.
(1)Temperature Compensating Type
The capacitance drift is calculated by dividing the differences
between the maximum and minimum measured values in the
step 1,3 and 5 by the cap. value in step 3.
Step
1
2
3
4 Max. Operating Temp.+/-3
5
(2)High Dielectric Constant Type
Step
1
2 Min.Operating Temp.+/-3
3
4 Max.Operating Temp.+/-3
5
6 Min.Operating Temp.+/-3
7
8 Max.Operating Temp.+/-3
· Initial measurement for high dielectric constant type
Perform a heat treatment at 150+0/-10°C for 1h and then
let sit for 24+/-2h at room temperature, then measure.
Solder the capacitor on the test substrate shown in Fig.3.
GRM02
GRM03
GRM15/GRM18
GRM21/GRM31/GRM32
Holding Time
Applied Direction : In parallel with the test substrate and vertical with
Test Method
(Ref. Standard:JIS C 5101, IEC60384）
: Between the terminations
: 300% of the rated voltage
(Temperature compensating type)
250% of the rated voltage
(High dielectric constant type)
: 1s to 5 s
: 2 min
Frequency Voltage
1.0+/-0.1MHz 0.5 to 5.0Vrms
1.0+/-0.1kHz 1.0+/-0.2Vrms
Frequency Voltage
1.0+/-0.1kHz 1.0+/-0.2Vrms
120+/-24Hz 0.5+/-0.1Vrms
Temperature(C)
Reference Temp.+/-2
Min. Operating Temp.+/-3
Reference Temp.+/-2
Reference Temp.+/-2
Applying Voltage(VDC)
Temperature(C)
Reference Temp.+/-2
No bias
Reference Temp.+/-2
Reference Temp.+/-2
50% of
the rated voltage
Reference Temp.+/-2
(For B1,R1)
Type Applied Force(N)
1
2
5
10
: 10+/-1s
the capacitor side.
