Sealey WD50QLS Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear
instruction protective
manual gloves
1. SAFETY
1.1. GENERAL SAFETY
The user shall work in accordance with the instruction handbook.
9
Always lower, centre and use safety tyre holder before attempting to move trolley.
9
It is necessary that the operator can watch the lifting device and the load during all movements.
9
Only use the lifter trolley on firm, level, unobstructed surfaces which are capable of supporting the lifter trolley and wheel.
9
WARNING! It is not allowed to work under the raised load until it is secured by suitable means. If more than 400N of effort is generated in
‰
lifting, the efforts shall be lowered by an additional person.
WARNING! Make sure there are safe working procedures in place when removing wheel in high wind/ bad weather conditions.
‰
DO NOT use wheel removal/lifter trolley on ships.
8
DO NOT use with tandem and duplex wheel and tyre combinations.
8
DO NOT use with tyres that are wider than 12" (304mm).
8
DO NOT use the lifter trolley to lift persons.
8
DO NOT overload the lifter trolley - maximum capacity is 50kg.
8
DO NOT ride on the lifter trolley.
8
DO NOT have direct contact between lifter trolley and with foodstuffs.
8
DO NOT use on tarmacadam. The lifter trolley must only be used on a concrete level surface with no obstructions.
8
WD50QLS is fitted with locking castors, these are for use at the operator's discretion and when the trolley is left unattended.
9
Replace or repair damaged parts. Use only recommended parts. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Use a qualified person to lubricate and maintain the lifter trolley.
9
WARNING! Failure to comply with these instructions may result in loss of load, damage to trolley or other property and/or personal
‰
injury.
WARNING! The warnings, cautions and instructions discussed in this manual cannot cover all possible conditions and situations that
‰
may occur. It must be understood that common sense and caution are factors which cannot be built into this product, but must be
applied by the operator.
WARNING! The Lifter trolley is only designed to lift wheels. Lifting other items can seriously danger life and property.
‰
1.2. HANDLING OF LOADS
DO NOT lift or lower a load with the lifter trolley until the operator and all other personnel are clear of the load.
8
DO NOT lift a load until it is secured using the safety chain.
8
DO NOT leave a suspended load unattended.
8
1.3. PROTECTIVE MEASURES
1.3.1. Make sure protective measures are in place, always use protective footwear, and protective gloves.
1.4. LIMITATIONS OF OPERATION IN SEVERE CONDITIONS
1.4.1. Ensure that lifting trolley is not used outdoors in bad weather, and high winds.
WARNING! The operator shall be provided with all necessary information about training and about pumping and translating forces.
‰
1.5. PERMISSIBLE ENVIRONMENTAL CONDITIONS (Temp/Moisture/Vibration)
1.5.1. Use lifter trolley in a Dry, clean and stable environment, not on a uneven, damaged floor.
1.6. WARNING LABELS NEED TO STAY AS ORIGINALLY SUPPLIED
1.6.1. Contact Sealey Service for replacement Warning labels should they get damaged or destroyed.
2. INTRODUCTION
Lifting mechanism reaches height up to 1078mm. Raised using an impact gun reducing time and effort needed to raise the roller arms
to the wheel. Solid steel construction, with friction mounted roller arms. Front and lockable rear castors for easy manoeuvrability and
stability. Supplied with safety bar to prevent wheel from tipping forward.
3. SPECIFICATION
Model No:
Applicable Standards:
Maximum Lifting Capacity:
© Jack Sealey Limited
WHEEL REMOVAL/LIFTER TROLLEY 50KG QUICK
LIFT
MODEL NO:
Wear
protective
footwear
WD50QLS
EN ISO 12100:2010
EN 1494:2000+A1:2008
50kg
Original Language Version
WD50QLS
Maximum Lifting Height:
Minimum Lifting Height:
Nett Weight:
Roller Length:
Width Between Rollers:
Maximum width of tyre
1078mm
93mm
48kg
240mm
500mm
304mm
WD50QLS Issue 2 30/01/25
