INDOOR UNIT
INDOOR UNIT
TECHNICAL &
SERVICE MANUAL
Models
MSZ-GX06NL
MSZ-GX09NL
MSZ-GX12NL
MSZ-GX15NL
MSZ-GX18NL
MSZ-GX24NL
MSZ-GX30NL
MSZ-GX36NL
MSY-GX09NL
-
U1
MSY-GX12NL
-
U1
MSY-GX15NL
-
U1
MSY-GX18NL
-
U1
MSY-GX24NL
-
U1
MSY-GX30NL
-
U1
MSY-GX36NL
-
U1
Outdoor unit technical & service manual
-
MUZ-GX•NL/NLHZ, MUY-GX•NL Series (OBD951)
U1
MXZ-D•NL/NLHZ Series (OBD949)
Outdoor unit service manual
MUZ-GX•NL/NLHZ, MUY-GX•NL Series (OBH951)
MXZ-D•NL/NLHZ Series (OBH949)
Indoor unit service manual
MSZ-GX•NL, MSY-GX•NL Series (OBH950)
CONTENTS
1. TECHNICAL CHANGES ······························3
USING REFRIGERANT R454B ·····················4
3. PART NAMES AND FUNCTIONS ················ 10
4. SPECIFICATION······································· 12
5. OUTLINES AND DIMENSIONS ··················· 15
6. WIRING DIAGRAM ··································· 17
7. REFRIGERANT SYSTEM DIAGRAM ··········· 19
8. SERVICE FUNCTIONS ······························ 20
9. MICROPROCESSOR CONTROL ················· 24
10. TROUBLESHOOTING ······························· 33
11. DISASSEMBLY INSTRUCTIONS ················· 50
13. NOISE CRITERION CURVES ······················ 63
Revision A:
• MSZ-GX06/09/12/15NL -
U1
MSY-GX09/12/15NL -
have
U1
been added.
OBD950 is void.
No. OBD950
REVISED EDITION-A
-
U1
-
U1
-
U1
-
U1
-
U1
-
U1
-
U1
and
