Owner's Manual
DVI over Cat5 Extenders
and Extender/Splitters
Este manual está disponible en español en la página de Eaton:
Tripplite.Eaton.com/support
Ce manuel est disponible en français sur le site Web de Eaton :
Tripplite.Eaton.com/support
PRODUCT
REGISTRATION
Register your product today for a
chance to win an ISOBAR
protector in our monthly drawing!
Tripplite.Eaton.com/warranty
Extender Kit
Models:
B140-101
B140-1P1-WP-1
B140-101X
B140-1A1-WP
Local Unit
Models:
B140-002
B140-004
Remote Unit
Models:
B140-1P0
B140-1A0
B140-1A0-WP-1
B140-110
surge
®
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRIPP LITE B140-101 and is the answer not in the manual?

Questions and answers

Related Manuals for Eaton TRIPP LITE B140-101

Summary of Contents for Eaton TRIPP LITE B140-101

  • Page 1 B140-1A0 B140-1A0-WP-1 B140-110 Este manual está disponible en español en la página de Eaton: Tripplite.Eaton.com/support Ce manuel est disponible en français sur le site Web de Eaton : Tripplite.Eaton.com/support PRODUCT REGISTRATION Register your product today for a chance to win an ISOBAR surge ®...

  • Page 2: Table Of Contents

    Table of Contents Package Contents ....................3 Product Features ....................3 Mounting (Optional) ....................8 Standard Extender Kit Installation ..............9 Extender Kit with Remote/Repeater Installation .........11 (B140-101X and B140-1A1-WP extender kits only) Standard Extender/Splitter Installation ............14 Extender/Splitter with Remote/Repeater Installation ........17 (B140-1A0 and B140-1A0-WP-1 remote receiver units only) Extender/Splitter Daisy-Chain Installation ............20 Extender/Splitter Daisy-Chain with Remote/Repeater Installation ..22...

  • Page 3: Package Contents

    Package Contents Local Unit (L), Remote Unit (R), or Both (B) B B B B L L R R R R External Power Supplies (0, 1, or 2) 0 0 1 2 1 1 1 1 0 1 Mounting Hardware X X X Wallplate Screws Screwdriver for Equalization Adjustment...
  • Page 4 Product Features B140-1P1-WP-1 • DVI over Cat5 Passive Extender Wallplate Kit • Extend a 1024 x 768 (60 Hz) signal up to 75 ft. (23 m) from the source, or a 1920 x 1080 (60 Hz) signal up to 50 ft. (15 m) from the source •...
  • Page 5 Product Features B140-002 • 2-Port DVI over Cat5 Extender/Splitter Local Transmitter Unit (Box-style) • Splits a DVI-D single link signal into two separate signals • Works with remote/repeater and receiver units to extend a DVI-D single link signal beyond the 16 ft. (5 m) distance limitation •...
  • Page 6 Product Features B140-1A0 • DVI over Cat5 Active Extender Remote Receiver Unit (Box-style) • Works with B140-002 and B140-004 extender/splitters to extend a 1024 x 768 (60 Hz) signal up to 200 ft. (60 m) from the source, or a 1920 x 1080 (60 Hz) signal up to 150 ft.
  • Page 7 Product Features B140-110 • DVI over Cat5 Extender Remote/Repeater Unit (Box-style) • Extends and expands your DVI over Cat5 installation, allowing you to locate multiple monitors at different points in a chain of up to 700 ft. (213 m) • Extends a 1024 x 768 (60 Hz) signal up to 175 ft. (50 m), or a 1920 x 1080 (60 Hz) signal up to 125 ft.

  • Page 8: Mounting (Optional)

    Mounting (Optional) The B140-101X, B140-002, B140-004, B140-1A0 and B140-110 come with mounting hardware that allows them to be mounted in a variety of ways. The following images show the different mounting methods. Note: The B140-004 can also be mounted to a B132-004-RB 1U Rack-Mount Bracket. Up to 3 B140-004 local units can be connected to a B132-004-RB.

  • Page 9: Standard Extender Kit Installation

    Standard Extender Kit Installation (B140-101, B140-1P1-WP-1, B140-101X, B140-1A1-WP) Notes: 1. The diagram below shows a B140-101X installation. Installation will be the same for the B140-1A1-WP. Installation will be similar for the B140-101 and B140-1P1-WP-1, except they will not require external power. 2.
  • Page 10 Standard Extender Kit Installation B140-1A1-WP only: Connect the external power supply to the local unit and plug it into a Trip Lite Surge Protector, Power Distribution Unit (PDU), or Uninterruptable Power Supply (UPS). The green Power LED will illuminate. Connect the RJ45 ports on the local and remote units using Cat5e/6 cable.

  • Page 11: Extender Kit With Remote/Repeater Installation

    Extender Kit with Remote/Repeater Installation (B140-101X and B140-1A1-WP extender kits only) Notes: 1. Test to make sure the entire installation works properly before pulling cables through ceilings/walls. 2. To achieve maximum distance and performance, use 24 AWG solid wire Cat5e/6 cable.
  • Page 12 Extender Kit with Remote/Repeater Installation (B140-101X and B140-1A1-WP extender kits only) Connect a monitor to the DVI OUTPUT port on the remote/repeater unit using a P561-Series DVI-D Single Link Cable. Connect the external power supply to the remote/repeater unit and plug it into a Surge Protector, PDU or UPS.
  • Page 13 Extender Kit with Remote/Repeater Installation (B140-101X and B140-1A1-WP extender kits only) Connect the external power supply to the remote receiver unit and plug it into a Surge Protector, PDU or UPS. The green RJ45 LED on the B140-101X remote receiver, or the green Power LED on the B140-1A1-WP remote wallplate, illuminates to indicate the unit is receiving power from the external power supply.

  • Page 14: Standard Extender/Splitter Installation

    Standard Extender/Splitter Installation Notes: 1. The diagram below shows a B140-004 installation. Installation will be the same when using a B140-002, except the B140-002 has fewer RJ45 ports and no local monitor port. 2. Test to make sure that the entire installation works properly before pulling cables through ceilings/walls.
  • Page 15 Standard Extender/Splitter Installation Make sure the DVI source is powered OFF. Connect the DVI source to the DVI port on the B140-002 or B140-004 labeled INPUT using a P561-Series DVI-D Single- Link Cable. Optional for B140-004: Connect a DVI monitor to the DVI port on the B140-004 marked LOCAL using a P561-Series DVI-D Single-Link Cable.
  • Page 16 Standard Extender/Splitter Installation Turn on the power to the DVI source. The orange RJ45 LEDs illuminate on the B140-002, B140-004 and B140-1A0, and the orange LED illuminates on the B140-1A0-WP-1 to indicate the unit is receiving a signal from the source. The image should now be displayed on the connected monitors.

  • Page 17: Extender/Splitter With Remote/Repeater Installation

    Extender/Splitter with Remote/Repeater Installation (B140-1A0 and B140-1A0-WP-1 remote receiver units only) Notes: 1. Test to make sure the entire installation works properly before pulling cables through ceilings/walls. 2. To achieve maximum distance and performance, use 24 AWG solid wire Cat5e/6 cable.
  • Page 18 Extender/Splitter with Remote/Repeater Installation (B140-1A0 and B140-1A0-WP-1 remote receiver units only) Optional for B140-004: Connect a local monitor to the DVI OUTPUT port using a P561-Series DVI-D Single Link Cable. Connect the external power supply to the local unit and plug it into a Surge Protector, PDU or UPS.
  • Page 19 Extender/Splitter with Remote/Repeater Installation (B140-1A0 and B140-1A0-WP-1 remote receiver units only) Using Cat5e/6 cable, connect the RJ45 OUTPUT port on the last remote/repeater unit to the RJ45 INPUT port on a B140-1A0 or B140-1A0-WP-1 remote receiver unit. Connect a monitor to the DVI OUTPUT port on the remote receiver unit using a P561-Series DVI-D Single Link Cable.

  • Page 20: Extender/Splitter Daisy-Chain Installation

    Extender/Splitter Daisy-Chain Installation (B140-004 only) Notes: 1. Test to make sure that the entire installation works properly before pulling cables through ceilings/walls. 2. To achieve maximum distance and performance, use 24 AWG solid wire Cat5e/6 cable. Using stranded wire cable, or cable with a gauge (AWG) size higher than 24 AWG will result in lesser performance and shorter extension distance.
  • Page 21 Extender/Splitter Daisy-Chain Installation Make sure the DVI source is powered OFF. Connect the DVI source to the DVI port on the B140-004 labeled INPUT using a P561-Series DVI-D Single Link Cable. Connect the external power supply to the B140-004 local unit and plug it into a Surge Protector, PDU or UPS.

  • Page 22: Extender/Splitter Daisy-Chain With Remote/Repeater Installation

    Extender/Splitter Daisy-Chain Installation Connect the B140-1P0 DVI-D Single Link Connector to the monitor or connect the B140-1A0 or B140-1A0-WP-1 to the monitor using a P561-Series DVI-D Single Link Cable. The green RJ45 LED on the B140-1P0 illuminates to indicate the unit is receiving power from the monitor.
  • Page 23 Extender/Splitter Daisy-Chain with Remote/ Repeater Installation (B140-004 extender/splitter, and B140-1A0 and B140-1A0-WP remote receivers only) Up to 175 ft. (50 m) at 1024 x 768 (60 Hz) Up to 175 ft. (50 m) at 1024 x 768 (60 Hz) Up to 125 ft. (38 m) at 1920 x 1080 (60 Hz) Up to 125 ft.
  • Page 24 Extender/Splitter Daisy-Chain with Remote/ Repeater Installation (B140-004 extender/splitter, and B140-1A0 and B140-1A0-WP remote receivers only) Make sure the DVI source is powered OFF. Connect the DVI source to the INPUT port on the B140-004 using a P561-Series DVI-D Single Link Cable. Connect the LOCAL port on the B140-004 to the INPUT port on a second B140-004 using the included 1 ft.
  • Page 25 Extender/Splitter Daisy-Chain with Remote/ Repeater Installation (B140-004 extender/splitter, and B140-1A0 and B140-1A0-WP remote receivers only) Using Cat5e/6 cable, connect the RJ45 OUTPUT port on the first remote/repeater unit to the RJ45 INPUT port on a second remote/ repeater unit. Connect a monitor to the DVI OUTPUT port on the remote/repeater unit that you just added using a P561-Series DVI-D Single Link Cable.
  • Page 26 Extender/Splitter Daisy-Chain with Remote/ Repeater Installation (B140-004 extender/splitter, and B140-1A0 and B140-1A0-WP remote receivers only) Turn on the power to the DVI source. The orange RJ45 LEDs on the local transmitter, remote/repeater and B140-1A0 illuminate to indicate a signal is being received from the source. The orange LED on the B140-1A0-WP-1 illuminates to indicate a signal is being received from the source.

  • Page 27: Warranty And Product Registration

    Visit Tripplite.Eaton.com/warranty today to register your new product. You’ll be automatically entered into a drawing for a chance to win a FREE Eaton Tripp Lite series product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
  • Page 28 Eaton 1000 Eaton Boulevard Cleveland, OH 44122 United States Eaton.com © 2025 Eaton Eaton is a registered All Rights Reserved trademark. Publication No. 24-09-127 / 93-3094_RevD All trademarks are property January 2025 of their respective owners.
