CORE HEALTH & FITNESS
8FC FREE CLIMBER
OWNER'S
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8FC and is the answer not in the manual?

Questions and answers

Related Manuals for Stairmaster 8FC

Summary of Contents for Stairmaster 8FC

  • Page 1 CORE HEALTH & FITNESS 8FC FREE CLIMBER OWNER'S MANUAL...

  • Page 2: Table Of Contents

    ASSEMBLY PROCEDURE ..............7 FIRST TIME SETUP ..............11 OPERATION LED CONSOLES ........................12 MAINTENANCE MODE ..............14 MAINTENANCE ........................18 REPLACEMENT PARTS ........................19 9-5450-XXXXP0 - 8FC ..............19 700-0549-XX - DISPLAY LED, BCS ............. 23 SUPPORT & SERVICE ........................24 Page 2...

  • Page 3: Important Safety Instructions

    Keep the air openings free of limit of: lint, hair, and the like. • 8FC - 350 lbs. / 158 kg 7. Do not carry this appliance by supply cord or 3. Statement of Purpose: A stepper lets users use cord as a handle.
  • Page 4 5. To step on, hold handrails firmly, place one foot securely on a step, then bring the other foot up while stabilizing yourself. To step off, reduce speed to a stop, hold the handrails, and step down one foot at a time onto the floor. 6.

  • Page 5: Important Label Locations

    LABEL VOLTAGE 12 VDC 5.5A LABEL, GENERAL DECAL, CR-BLK, 8-FC, LWR, LT, DECAL, CR-BLK, 8-FC, LWR, RT, WARNING, E-BTS STAIRMASTER STAIRMASTER Shipping Weight (Boxed): 255 lbs (116 kg) Shipping Dimensions: 46.1in x 29.9in x 44.5in (117cm x 76cm x 113cm) Page 5...

  • Page 6: Assembly

    • 7/16” Deep Socket PARTS INCLUDED IN THE BOX: Description 711-4242-XX SUBASM, NECK, 8FC 711-4264-XX ASSY, TOP SHROUD, 8FC 711-4256-XX ASSY, RIGHT SIDE, FINAL, SHROUD, 8FC 020-4468-XX BOOT, RIGHT, 8FC 740-7907-XX BASE FRAME, STEPPER SC916 711-4272-XX ASSY, HANDRAIL W/ GRIP, RT, 8-FC 711-4266...

  • Page 7: Assembly Procedure

    ASSEMBLY PROCEDURE 711-3414-XX Use a #2 phillips screwdriver to remove the upper screws 110-0542 and 711-4264-XX 110-3544 lower screws UF65108061E securing the top shroud 711-4264-XX and 110-3542 side shrouds 711-3412-XX & 711-3414-XX to the frame, then remove the shrouds. Remove the rear leveling feet 140-3495 and nuts 110-3480 from the frame.
  • Page 8 711-4271-XX Use a torque wrench with a 7/16” deep socket to secure the left handrail to the frame using two (2) 1/4” flat washers, 1/4” split lock washers, and 1/4” x1 1/2” hex head screws. (See Fig. 9) 711-3368-XX TORQUE TO 10 ft-lbs (14 Nm) Install the left leveling foot.
  • Page 9 Fig. 12 15. Unpackage the console and firmly pull the rear console cover off the bottom. 16. Place the front of the console against the console weldment, angled forward. Make sure the bottom plastic of the console is below the wireless phone charger lip. Page 9...
  • Page 10 17. Drape all wires from the base out the back of the mast weldment prior to installing the console. 18. Secure console to frame weldment with four screws 110-4447 as shown in Fig. 14. TORQUE TO 7.4-11 ft-lbs (10-15 Nm) If installing a PVS kit or 800/900 MHz controller, please refer to the documentation that ships with the...

  • Page 11: First Time Setup

    “model” is shown, then press the enter key select the model sub menu. Use the Level keys to choose “8FC”, then press enter to save the selection. Fig. 16 CONNECT WIFI Option 1 (Recommended): Alter facility SSID to match information built into LED display.

  • Page 12: Operation Led Consoles

    Self-Powered Product: StarTrac Electronic Bikes and Ellipticals as well as StairMaster FreeClimbers with LED console are often used in facilities in a self-powered state. The wireless charging tray is designed to charge mobile phones on these self-powered products. Some limitations may apply.

  • Page 13: Display Measurements

    Display Measurements Message Window The top display window includes several measures: TIME Current total workout time DISTANCE Total distance traveled in mile or HEART RATE Current HR in beats per minute, if available CALORIES Current total calories Progress Window & Track Shows a graphic representation of elevation Pace (TR only) during a program.

  • Page 14: Maintenance Mode

    MAINTENANCE MODE Maintenance Mode allows access to service and diagnostic information, as well as provides the ability to adjust certain program default parameters. To enter Maintenance Mode: 1. Press and hold the 1, 2 on the left keypad and the 8 key on the right keypad together.

  • Page 15: Manually Updating Firmware

    A complete list of the items that you may display and change in Maintenance Mode: Highest Highest Item Lowest Value Default Notes Item Lowest Value Default Notes Value Value 5K LOOP SYSTEM IHR PROG CHR PROG DISP V0.3.1 (1) FIT TEST 00.09 (02) V2.3.5 FIREFGHT...

  • Page 16: Fcc Warning

    FCC INFORMATION & INDUSTRY CANADA WARNING FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Text Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

  • Page 17: Ic Radiation Exposure Statement

    (ii) for devices with detachable antenna(s), the maximum antenna gain permitted for devices in the bands 5250- 5350 MHz and 5470-5725 MHz shall be such that the equipment still complies with the e.i.r.p. limit; pour les dispositifs munis d’antennes amovibles, le gain maximal d’antenne permis pour les dispositifs utilisant les bandes de 5 250 à...

  • Page 18: Maintenance

    Inspect the frame for any rust, bubbling, or paint chips during the daily cleaning. The salt in perspiration can damage the unpainted surfaces. Repair the damaged area with a touch-up paint kit purchased from StairMaster® (see Support & Service for order information).

  • Page 19: Replacement Parts

    711-3162 ASSY, LCB, STEPPER 020-4468-XX BOOT, RIGHT, 8FC 711-3240 CABLE, EMI, ALT AND LCB, E-ST (SC916) 020-4469-XX BOOT, RIGHT, NECK TO CONSOLE 8FC 711-3242 LOAD RESISTORS, LCB, SM+ST+TC 020-6555 PLATE, HR, UNIVERSAL, TOP 711-3249 ASSY, SPEED SENSOR, CL, RoHS 020-6556...
  • Page 20 SM22075 SM22070 SM22165 220-0403 220-0338 220-0336 110-3076 120-0495 120-3023 220-0340 220-0337 220-0339 210-0234 711-3249 711-3240 SM22029 711-4266 SM27585 SM22191 711-3331 SM22097 170-0739 SM13170 711-3255 Fig. 22 Alternator Fig. 23 Cables and Hardware Kit SM13152 SM13069 711-4242-XX 711-3408 SM22347 720-5318 110-4449 110-4448 130-1791 SM13048...
  • Page 21 SM24643 SM27585 130-1801 120-0410 711-4271-XX 711-4272-XX 110-0506 711-3397-XX SM24640 110-0575 120-0420 110-1530 110-3480 140-3495 Fig. 26 Feet & Wheels Fig. 27 Handrails 56-0298 711-3411 580-0275 711-3162 740-7182 110-3272 711-3242 120-3259 UF65108061E 110-3246 711-3411 Fig. 28 Fig. 29 Load Resistors Page 21...
  • Page 22 110-3148 110-3675 110-3147 020-6555 220-0340 020-6556 711-4242-XX 110-0506 110-3630 120-0480 020-4453 020-4466 110-4480 110-1870 Fig. 30 Mast Shroud Fig. 31 Mast 731-4889 711-3401-XX 140-3538 140-3536 SM20188 055-0090 055-0094 711-3400-XX 120-3329 120-3284 711-3434 110-3509 711-3416-XX 120-3336 711-3417-XX 140-3530 120-3335 110-3571 120-3334 SM13052 740-7183 SM13053...

  • Page 23: 700-0549-Xx - Display Led, Bcs

    020-4468-XX 020-4469-XX 711-4256-XX 740-7182 050-2215 110-3544 440-0278 711-4255-XX 711-4264-XX 740-8521-XX 050-6005 050-6004 711-4273-XX 711-3414-XX 711-3412-XX 711-3255 110-3542 050-2233 110-3573 220-0339 140-3588 220-0337 56-0298 Fig. 34 Plug Receptacle and Noise Filter Fig. 35 Shrouds 700-0549-XX - DISPLAY LED, BCS Part Number Description Part Number Description...

  • Page 24: Support & Service

    SUPPORT & SERVICE CORE CONNECT Core Connect is your portal to all things service! Whether you need to order parts or register your warranty, Core Connect is the most effective way to get what you need fast and keep your facility operating smoothly. OFFERS 24-HOUR SELF SERVICE ACCESS TO: •...
  • Page 25 THIS PAGE INTENTIONALLY BLANK Page 25...
  • Page 26 THIS PAGE INTENTIONALLY BLANK Page 26...
  • Page 27 THIS PAGE INTENTIONALLY BLANK Page 27...
  • Page 28 PART NUMBER 620-9132, REV C All rights reserved. Star Trac, the Star Trac logo and StairMaster are registered trademarks of Core Health & Fitness, LLC. Schwinn and Nautilus are registered trademarks of Nautilus Inc. used under license to Core Health & Fitness LLC. Throwdown is a registered trademark of Throwdown Industries, LLC.
