End Panels for Low-Profile Roof Frames
©2008 ClearSpan™
All Rights Reserved. Reproduction
is prohibited without permission.
Revision date: 05.20.09
ClearSpan
Photo may show a different but similar end panel.
™
STK#
DESCRIPTION
108231W
12' W (Plain or Zippered End)
108232W
18' W (Plain or Zippered End)
108233W
24' W (Plain or Zippered End)
108234W
30' W (Plain or Zippered End)
CLEARSPAN
CARPORTS
™
1
Advertisement
Related Manuals for ClearSpan 108231W
Summary of Contents for ClearSpan 108231W
- Page 1 ClearSpan ™ End Panels for Low-Profile Roof Frames Photo may show a different but similar end panel. STK# DESCRIPTION 108231W 12' W (Plain or Zippered End) ©2008 ClearSpan™ All Rights Reserved. Reproduction 108232W 18' W (Plain or Zippered End) is prohibited without permission.
-
Page 2: Safety Precautions
BEGIN TO ATTACH YOUR END PANEL. all additional documentation included with the shipment before you begin. Thank you for purchasing this ClearSpan™ end panel. When properly assembled and maintained, this product will 3. Gather the tools, bracing, ladders (and lifts), and provide years of reliable service. - Page 3 CLEARSPAN CARPORTS ™ IMPORTANT NOTICE: PLEASE READ! The information presented within these pages describe Space below is reserved for customer notes. a typical end panel installation. The panel and frame throughout this manual may differ from the actual components. The basic steps present within this document describe how most end panels are installed.
- Page 4 CLEARSPAN CARPORTS ™ Low Profile Roof Frame End Panels Contact your sales representative to purchase necessary connecting and installation hardware. End wall framing is also available and is recommended for end panel installation. OVERVIEW This section is an overview of the process for attaching your end panel.
- Page 5 CLEARSPAN FABRIC STRUCTURES ™ END CONDUIT ASSEMBLY Gather the parts (additional purchase required): • Pipe 1.315'' x 75'' swaged (#131S075) • Pipe 1.315'' x 73.5'' plain (#131P0735) • Duct tape and Tek screws Complete the following steps: 1. Locate the end conduit pipes. End conduit consists of 75" pipes and one (1) 73.5" pipe.
- Page 6 CLEARSPAN FABRIC STRUCTURES ™ ATTACH END CONDUIT Using two (2) QH1330 angled brackets, secure one (1) angled bracket to each end of the end conduit and secure the conduit to the end frame. See diagrams below. Shelter shown may show a different length and application.
- Page 7 CLEARSPAN FABRIC STRUCTURES ™ Shelter shown may show a different length and ATTACH END PANEL support structure. Gather the parts: • End panel assembly • Customer-supplied fasteners • Measuring tape and scissors NOTE: If in doubt, consult the advice of a...
