Model/Modelo/Modèle
P99190LF
Series/Series/Seria
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
You may need/Usted puede necesitar/Articles dont vous pouvez avoir besoin:
For easy installation of your Peerless
faucet you will need:
・To READ ALL the instructions completely before
beginning.
・To READ ALL warnings, care and maintenance
information.
・To purchase the correct water supply hook-up.
Para instalación fácil de su llave Peerless
usted necesitará:
・LEER TODAS las instrucciones completamente
antes de empezar.
・LEER TODAS los avisos, cuidados, e información
de mantenimiento.
・Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet Peerless
facilement, vous devez:
・LIRE TOUTES les instructions avant de débuter.
・LIRE TOUE LES les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien.
・Acheter le bon nécessaire de raccordement.
www.peerlessfaucet.com
TWO HANDLE WIDESPREAD
88785
LAVATORY FAUCET
LLAVE DE LAVAMANOS
EXTENDIDAS DE DOS MANIJAS
R O B I N E T À E N T R A X E L O N G À
DEUX POIGNÉES POUR LAVABO
88785
1
3/32"
(2.38 mm)
8/04/2016 Rev. A
Advertisement
Related Manuals for Peerless Faucet P99190LF
Summary of Contents for Peerless Faucet P99190LF
- Page 1 LAVATORY FAUCET LLAVE DE LAVAMANOS EXTENDIDAS DE DOS MANIJAS Model/Modelo/Modèle P99190LF R O B I N E T À E N T R A X E L O N G À Series/Series/Seria DEUX POIGNÉES POUR LAVABO Write purchased model number here.
- Page 2 Place spout (1) with gasket (2) through mounting hole in sink. Secure SHUT OFF WATER SUPPLIES. Remove old faucet. Slide hot and spout with gasket and bracket (3) and nut (4). Note: If sink is uneven, cold end valves (1) with gaskets (2) through sink mounting holes. use silicone under the gasket.
- Page 3 1/2" (13 mm) IPS Install Pop-Up Assembly CONNECT TO WATER SUPPLIES. (HOOK-UPS NOT PROVIDED). Apply silicone to underside of flange (1). Remove stopper (1) and flange (2). Turn on hot and cold water supplies and flush water Insert body (2) into sink. Screw flange onto Screw nut (3) all the way down.
- Page 4 *Install stems (1) correctly for proper Maintenance handle rotation: SHUT OFF WATER SUPPLIES FLUSH SYSTEM/CHECK FOR LEAKS. NOTE: Remove handles by hand turning Note: Remove aerator (1) and turn faucet handles (2) to the full on mixed handle base counterclockwise. 1.The stops (4) must point to the position.
- Page 5 ▲ Specify Finish Especifíque el Acabado Précisez le Fini RP20547 Retention Screws RP71220 ▲ Note: These screws must be installed into the hole Handle Assemblies in the top of the stem unit assemblies (1) when using Conjunto de manija handles mounted from the sides. Montage de la manette Tornillos de Retención Nota: Cuando usa manijas instaladas desde los...
- Page 6 This warranty excludes all industrial, commercial, and business usage (including but not limited to use in multi-family housing), whose purchasers Peerless Faucet Company will replace, FREE OF CHARGE, during the warranty period, are hereby extended a five-year limited warranty from the date of purchase,...
