AUDAC NWP Series Hardware Manual

Network input panel - 2 x xlr + 3.5 mm jack + bt (4 ch)
Hide thumbs Also See for NWP Series:

Advertisement

Table of Contents

Table of contents
Bluetooth Settings
Pre-Gain, Gain & Automatic Gain Control (AGC)
WaveDynamics™
WaveTune™
Volume
Mixer
Device Settings
Bluetooth Settings
All NWP series have Bluetooth functionality which can be activated in various ways: by holding the button on
the front panel, pressing the "Pair New Device" button in Bluetooth settings, by programming NCP105 and
with a widget in a custom dashboard.
The following screenshot shows the Bluetooth settings menu which can be reached by clicking on the gear icon
next to the channel label. Bluetooth In Left (BIL) and Bluetooth In Right (BIR) channels are in stereo mode by
default and share the same DSP aspects.
HARDWARE FEATURE MANUAL
Network input panel - 2 x XLR +
3.5 mm jack + BT (4 CH)
NWP320

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NWP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AUDAC NWP Series

Summary of Contents for AUDAC NWP Series

  • Page 1 Device Settings Bluetooth Settings All NWP series have Bluetooth functionality which can be activated in various ways: by holding the button on the front panel, pressing the “Pair New Device” button in Bluetooth settings, by programming NCP105 and with a widget in a custom dashboard.
  • Page 2 Parameter Name Parameter Range Parameter Definition This is the name visible for the client devices that want to Device/Bluetooth Not Available connect via Bluetooth. The device name is also the device's Name full name, which can be also changed in the device settings. Not Available MAC address of the device Name and MAC address of the connected device...
  • Page 3 Programming NCP105 NCP105 buttons can be programmed to enable or disable the pairing function of the wall panel. The pairing function is available as a button and can be found under inputs > Bluetooth for the buttons. Parameter Name Parameter Range Parameter Definition Desired Value Not Available...

  • Page 4: Automatic Gain Control (Agc)

    Gain is available for all input channels with a range of -35 and 35 dB for the LUNA series. It is also possible to adjust the input gain automatically. Note: NWP series have -15 and 15dB of gain range. Parameter Name...
  • Page 5 Parameter Name Parameter Range Parameter Definition The Target parameter specifies a signal's target level before entering the Matrix. Continuously, the signal matching the Target (A) -20 - 6 dB level specified by the target parameter will be attempted to adjust. The Max Gain parameter specifies the maximum gain adjustment which can be achieved between the input level and the target level.
  • Page 6 0dB. Training Video You can click on the video or scan the code to watch the training video of this DSP feature. Note: The video content may be changed or updated in time.
  • Page 7 WaveDynamics™ WaveDynamics™ is an audio control and processing technology implemented in AUDAC products. Thanks to the powerful DSP processors built into our products it can deliver effortless control over the most advanced acoustic configurations. Training Video You can click on the video or scan the code to watch the training video of this DSP feature.
  • Page 8 Parameter Name Parameter Range Parameter Definition Opens a list of factory and custom presets which can be Preset List Selection imported, exported or edited in WaveDynamics Apply Preset Not Available Recalls the selected preset to the output channel. Show Table Enable/Disable Opens a table showing the filters that can be applied Type...
  • Page 10 Volume Sets the attenuation of the input source in the Input Block and the mixer output in the Zone Block. Note: Volume in Zone Block has the identical functionality as the master volume of the mixer. Parameter Name Parameter Range Parameter Definition Volume -90 –...
  • Page 11 Note: Volume in Zone Block has the identical functionality as the master volume of the mixer. Note: In the network input and output wall panel NWP series, the mixer function is available in the Output Block, yet has no Scene feature.

  • Page 12: Device Settings

    Indicates the build number of the installed firmware version. The available firmware version can be installed here. The latest and previous versions are both available. Using the latest AUDAC Touch version and firmware is highly recommended to get the most out of your Atellio family devices. Update Firmware...
  • Page 13 Parameter Name Parameter Range Parameter Definition DHCP Enable/Disable Switch between dynamic or static IP Not Available MAC address of the device The IP address of the device can be set here when DHCP is Not Available disabled (e.g. 192.168.20.170) Mask Not Available The subnet mask can be set here (e.g.
  • Page 14 "oceania.pool.ntp.org" "north-america.pool.ntp.org" "south-america.pool.ntp.org" "africa.pool.ntp.org" Target Device Settings (Only for NPM200) Up to 20 devices can be set as target devices for paging and voice file announcements for a single NPM200. Please refer to "Target Devices Settings" for a detailed explanation.
  • Page 15 Button Sensitivity (Only for NCP105) Parameter Name Parameter Range Parameter Definition The sensitivity of programmable buttons can be set Button Sensitivity 0-100 individually. Physical Button Functions (Only for the NWP series)
  • Page 16 Enable or disable the factory reset function using the push Factory Reset Enable/Disable rotary button on the NWP series devices. Pin Code Setting (LUNA series and NPM200) Pin code protection is available for the LUNA series with version 1.4.0 for configuration display. The pin code is 0000 by default.
