INDOOR/OUTDOOR ICE MACHINE
MODELS:
BIM62ADA
DBIM64CSS
BIM63OS
DBIM65CSS
User Manual
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Serial Nos. (on lower left corner of
Felix Storch, Inc.
rear wall of door) here:
ISO 9001:2015 registered company
770 Garrison Avenue
_____________________________
Bronx, NY 10474
www.summitappliance.com
Advertisement
Table of Contents
Related Manuals for Summit DREAMBILT BIM62ADA
Summary of Contents for Summit DREAMBILT BIM62ADA
- Page 1 INDOOR/OUTDOOR ICE MACHINE MODELS: BIM62ADA DBIM64CSS BIM63OS DBIM65CSS User Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Write Serial Nos. (on lower left corner of Felix Storch, Inc. rear wall of door) here: ISO 9001:2015 registered company 770 Garrison Avenue _____________________________ Bronx, NY 10474...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Appliance Safety Important Safeguards Disposal Location of Parts Installation Instructions 8-17 Before Using Your Appliance Installation of Your Appliance Electrical Connection Extension Cord Adjusting the Kick-plate Installing the Stainless Steel Handle Reversing the Door Swing of Your Appliance 11-12 Full Overlay Panel Installation Instructions 13-15... -
Page 3: Appliance Safety
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 Warning: Risk of Fire / Flammable Materials. • This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a) which is environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the greenhouse effect. Care must be taken during transportation and setting up of the appliance so that no parts of the cooling system are damaged.
- Page 5 CAUTION: Use this appliance only for its intended purpose. • This equipment is intended for the storage and display of packaged products only. • To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed. Choose a well-ventilated area with temperatures above 50°F (10°C) and below 110°F (43°C).
-
Page 6: Disposal
DISPOSAL Dispose of your appliance packaging properly. Ensure that any plastic wrappings, bags, etc., are disposed of safely and kept out of the reach of babies and young children. Danger of suffocation! Refrigeration equipment must be properly disposed of in a professional and appropriate way, in accordance with the current local regulations and laws which protect the environment. -
Page 7: Location Of Parts
LOCATION OF PARTS Models BIM63OS / DBIM65CSS Handle Control Panel Water Shutters Ice Scoop Door Water Trough Water Inlet Drain Outlet Ventilation Grille Adjustable Legs Models BIM62ADA / DBIM64CSS Handle Control Panel Water Shutters Ice Scoop Door Water Trough Water Inlet Ventilation Grille Drain Outlet Adjustable Legs... -
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS Before Using your Appliance Remove the exterior and interior packing. • CAUTION: After unpacking you MUST allow this appliance to stand upright for at least 2 hours to allow the lubricant and refrigerant to drain back into the compressor and stabilize. -
Page 9: Electrical Connection
NOTE: It is recommended that you do not install the appliance near an oven, radiator, or other heating sources. Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption. Do not install in a location where the temperature will fall below 50°F (10°C). -
Page 10: Extension Cord
equipped with a three-prong plug which mates with standard three-prong wall outlets to minimize the possibility of electrical shock. Do not under any circumstances cut or remove the third (grounded) prong from the power cord supplied. For personal safety, this appliance must be properly grounded. Any questions concerning power and/or grounding should be directed toward a certified electrician or an authorized service center. -
Page 11: Installing The Stainless Steel Handle
NOTE: All parts removed must be saved to allow the door swing to be reversed. NOTE: Some variations of these items may only be reversible in Summit facilities before being shipped. Consult our website for more information. - Page 12 4. Screw the alternative left top hinge (6), included in the fittings, on the left hand side of cabinet. (Fig. 3) 5. Relocate the door to the designated position. Then screw the bottom hinge assembly on the left designated position and tighten it after the door is leveled. BIM62ADA / DBIM64CSS Models WARNING...
-
Page 13: Full Overlay Panel Installation Instructions
Full Overlay Panel Installation Instructions for Models BIM62ADA / DBIM64CSS These models are designed for field-installed overlay panel. The overlay panel covers the stainless steel to give a built-in appearance. The overlay panel and appropriate hardware are not included with the unit and the end user needs to prepare them themselves. Please follow the instructions below for installation: Door Panel Preparation Prepare the overlay panel to the dimensions shown below. -
Page 14: Door Panel Installation
Door Panel Installation NOTE: This design will leave a 3mm gap between the panel and the unit door. If you do not want the 3mm gap, you will have the option to route the wood according to the bracket’s dimensions. Then proceed to install the bracket following the instructions below. Installing the Handle on the Overlay Panel If reusing the handle that came with the unit: 1. - Page 15 5. We recommend you leave the factory-installed protective film to protect the door and prevent scratching while installing the panel. 6. Open the unit’s door all the way. Then, carefully slide the bracketed wooden panel onto the unit’s door (4). 7.
-
Page 16: Water Supply And Drain Requirements
Water Supply and Drain Requirements Prepare water supply line and drain before installation of your ice machine. Installation requires a ¼" ID copper cold water line and compression fitting (not supplied). The ice machine is supplied with an automatic drain pump system. The drain method requires routing to an open site drain. -
Page 17: Water Supply And Drain Line Sizing/Connections
WATER SUPPLY AND DRAIN LINE SIZING/CONNECTIONS CAUTION Plumbing must conform to state and local codes. Location Water Water Pressure Ice Machine Tubing Size Up to Ice Temperature Fitting Machine Fitting Ice Making 41°F(5°C) Min. 20 psig (138 kPA) Min. 1/4” (.64 cm) ID 1/4"... -
Page 18: Operating Your Appliance
OPERATING YOUR APPLIANCE The ice machine is factory-operated and adjusted before shipment. Normally, new installation does not require any adjustment. Turn on the water tap, then plug the machine or touch the POWER key to turn on. The ice machine will start working automatically. -
Page 19: Sequence Of Operation
harvest cycle. Touching the MODE key once will initiate an ice making cycle. The display will show “ ”. Touching the MODE key again will initiate a harvest cycle. The display will show “ ”. Delay Start Touching the DELAY START key will initiate a delay cycle. The ice machine will not run until the delay time expires. -
Page 20: Ice Cube Size Selection
5. Automatic Shut-Off The level of ice in the storage bin controls the ice machine shut-off. When the bin is full, ice will contact the bin thermistor holder. The bin thermistor cools, which stops the ice machine. The ice machine remains off until ice no longer contacts the bin thermistor holder and the thermistor warms up. -
Page 21: Operating Noise
Operating Noises The unit is cooled by a compressor (refrigeration aggregate). The compressor pumps coolant through the cooling system, producing operating noise. Even when the compressor cuts out, noises caused by changes in temperature and pressure are unavoidable. Operating noise will be most audible immediately after the compressor cuts in. -
Page 22: Care And Maintenance
CARE AND MAINTENANCE WARNING To avoid possible injury due to electric shock, disconnect the power cord or turn off power at the circuit breaker panel or fuse box and shut off the water line before cleaning the appliance. Clean only the parts of the appliance listed in this manual. Clean them only in the manner specified. -
Page 23: Cleaning The Interior
Cleaning the Interior The ice storage bin should be sanitized occasionally. Clean the water trough before the ice machine is used first time and reused after prolonged shutdown. It is usually convenient to sanitize the trough after the ice making system has been cleaned, and the ice storage bin is empty. 1. -
Page 24: Full Cleaning/Sanitizing Procedure
10. Press and hold the POWER key for 5 seconds to switch off the unit to finish the above process. Then press the POWER key to switch on the unit and press the ICE key, the machine will return to the regular ice making mode. Discard the first batch of ice. WARNING ... -
Page 25: Removal Of Parts For Cleaning/Sanitizing
13. Press and hold the POWER key for 5 seconds to switch off the unit to finish the above process. Then press the POWER key to switch on the unit and press the ICE key, the machine will return to the regular ice making mode. Discard the first batch of ice. Removal of Parts for Cleaning/Sanitizing WARNING ... -
Page 26: Preventing Stainless Steel Rust
Gently lift the overflow tube (4) inside the water trough and clean it. Make sure to replace the overflow tube in the correct position after cleaning, otherwise, draining will not stop, with the product rendered unable to make ice. Gently pull to remove the filter screen (5) inside the water trough and clean it. Top and Evaporator Cover WARNING ... -
Page 27: Power Failure
Clean with polish lines. Some stainless steels have visible polishing lines or “grain”. When visible lines are present, always scrub in a motion parallel to the lines. When the grain cannot be seen, polish in a consistent straight pattern and not in a circular motion. Use alkaline, alkaline chlorinated or non-chloride containing cleaners. -
Page 28: Moving Your Appliance
Moving Your Appliance Unplug the power plug from the electrical outlet. Disconnect the water line. Remove the ice from the bin and drain off the water. Than fix all moving parts. Raise the adjustable legs up to the base to avoid damage. Tape the door shut. -
Page 29: Troubleshooting
TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM POSSIBLE CAUSE REMEDY • Appliance is not connected to a power •... - Page 30 storage bin • The drain hose is kinked or improperly • Check the drain hose to be sure placed higher than the floor of the ice water can be drained out unhindered. storage bin. • The appliance is not properly level. •...
- Page 31 NOTES CALIFORNIA CARB/SNAP DISCLOSURE This product uses eco-friendly hydrocarbon refrigerant and fully complies with California CARB regulations. However, we are required by California Law to provide the following disclosure statement in every product sold in California. "This equipment is prohibited from use in California with any refrigerants on the 'List of Prohibited Substances' for that specific end-use, in accordance with California Code of Regulations, title 17, section 95374.
-
Page 32: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
