- Page 1 MODELS REFRIGERANT System Indoor Outdoor HSNRT25B HINRT25MB HONRT25B HSNRT35B HINRT35MB HONRT35B HSNRT50B HINRT50MB HONRT50B HSNRT70B HINRT70MB HONRT70B HSNRT80B HINRT80MB HONRT80B T Series Split Type Wall Mounted Air Conditioner Operation Manual...
- Page 2 This appliance must be installed, maintained and removed only by an Authorised Person. For continued safety of this appliance it must be installed and maintained in accordance with the manufacturer’s instructions. REFRIGERANT Rinnai Split AC T Series OM – Issue 3...
-
Page 3: Table Of Contents
Service Maintenance Schedule - Non Ducted Air Conditioning Systems ��������������������������������������������������������� 16 General Maintenance ��������������������������������������������������������������������������������������������������������������������������������������� 17 Cleaning the Air Filter ��������������������������������������������������������������������������������������������������������������������������������������� 17 Save a Service Call ������������������������������������������������������������������������������������������������������������������������������������������ 18 When to Call for Service ����������������������������������������������������������������������������������������������������������������������������������� 18 Warranty Contacts Rinnai Split AC T Series OM – Issue 3... -
Page 4: Warnings And Important Information
Read the OPERATING INSTRUCTIONS carefully before operation. Service personnel are required to carefully read the OPERATING INSTRUCTIONS and INSTALLATION MANUAL before operation. Further information is available in the OPERATING INSTRUCTIONS, INSTALLATION MANUAL, and the like. Rinnai Split AC T Series OM – Issue 3... -
Page 5: Operation
The table below indicates the temperature ranges the air conditioner can be operated within. MODE Cool Mode Heat Mode Dry Mode Room Temperature > 17°C < 27°C > 17°C Outdoor Temperature -15°C ~ 52°C -15°C ~ 24°C -15°C ~ 52°C Rinnai Split AC T Series OM – Issue 3... -
Page 6: Air Conditioner Basics
The remote control may operate other electronic devices if pointed towards them. Make sure to point the remote control towards the signal receiver of the air conditioner. NOTE For proper operation, use a soft cloth to clean the signal transmitter LED and the receiver window. Rinnai Split AC T Series OM – Issue 3... -
Page 7: Remote Control Layout
18� SPOT SWING button Sets a fixed direction for air flow horizontally. SPOT SWING 19� ECO button Sets appliance to the most efficient operation. 20� Wireless Transmitter LED 21� LCD screen Advanced Displays settings and operation modes� Operation 22� Blank buttons Buttons Not used� Rinnai Split AC T Series OM – Issue 3... -
Page 8: Basic Operation
The fan speed can be adjusted manually or set to automatic� 1� Press the "FAN" button until the desired fan speed is shown on the LCD AUTO screen (displayed below the temperature display), the available fan speeds SPEED SPEED are AUTO / low (2 bars) / medium (4 bars) / high (6 bars). Medium Select "AUTO" if you wish the fan speed to be adjusted automatically by the High Auto appliance� Rinnai Split AC T Series OM – Issue 3... -
Page 9: Adjusting Vertical Air Flow
When cycling, "SWING ↔ " and the swing icon are shown on the LCD screen� DO NOT attempt to adjust the air deflector vanes manually as this can result in damage to the louvre movement mechanisms. CAUTION Rinnai Split AC T Series OM – Issue 3... -
Page 10: Advanced Operation
2� Press the "MODE" button until "FAN" is shown on the LCD screen. 3� Press the "SPEED" button until the desired speed is shown on the LCD screen Medium (the available fan speeds are low (2 bars) / medium (4 bars) / high (6 bars). High In this mode, Swing operations for air direction can still be adjusted, however the AUTO setting for the fan speed is not available. NOTE Rinnai Split AC T Series OM – Issue 3... -
Page 11: Turbo
Attempting to alter the fan speed during Quiet mode operation will cancel this mode and return the appliance to manual operation. NOTE HEALTH (WI-FI) When pressed 8 times in quick succession, this button activates and or resets the Wi-Fi module of the appliance. The appliance will respond with a double beep to confirm Wi-Fi activation or reset. For further details refer to the Wi-Fi Operation Manual, a copy of the manual may be downloaded from the Rinnai web site: http://www.rinnai.com.au/cooling/ SLEEP MODE 1� Press the "ON/OFF" button to turn on appliance� COOL COOL 2�... -
Page 12: Delay On Timer
"ROOM °C" button once� 3� "ROOM" & “iFEEL” are shown on the LCD screen and the temperature digits display the current room temperature at remote control location� Pressing the “ROOM” button again, to deactivate this function� The temperature digits display the current set temperature� Rinnai Split AC T Series OM – Issue 3... -
Page 13: Large Temperature Display
CAUTION ECONOMY (COOLING ONLY) COOL In this mode the appliance automatically sets the operation to achieve the most economical cooling of the room� SPEED SWING LRSWING POWERCON iFEEL Rinnai Split AC T Series OM – Issue 3... -
Page 14: Cleaning Operation
Return the cover to the closed position� 4� To turn off, repeat steps 1 through 3. POWER INTERRUPTION AUTOMATIC RESTART Should a power outage occur while the appliance is operating, when the power is restored the system will restart automatically using the same settings as those that were set before the power outage. After power restoration, the automatic restart cycle will take approximately 5 minutes. DO NOT adjust setting during the restart cycle period. NOTE Rinnai Split AC T Series OM – Issue 3... -
Page 15: Care & Maintenance
________________________________________________________________ ________________________________________________________________ CUSTOMER CARE PROGRAM Please ensure you register your product warranty on line at rinnai.com.au. The Rinnai Customer Care Program is designed to help you get the most out of your new system. Service and maintenance in accordance with the Service Maintenance Schedules on page 16 is essential in ensuring the prolonged useful life of your system, and help ensure it operates at optimum efficiency. We may ... -
Page 16: Service Maintenance Schedule - Non Ducted Air Conditioning Systems
CARE & MAINTENANCE SERVICE MAINTENANCE SCHEDULE - NON DUCTED AIR CONDITIONING SYSTEMS Your Rinnai Air Conditioning System should be maintained annually after the date of installation by a qualified licensed technician in accordance with the Schedule below. Failure to do so during the product warranty period may void your warranty. This periodic service and maintenance will prolong the useful life of the unit, and help keep it running safely and at optimum efficiency. Date of Installation / / Installed By: Service Year Service Date / / / / / / / / / / / / Service Company / Technician Ambient Temperature at CDU (°C) ELECTRICAL Wiring, Electrical connections Fan Motors Capacitors (if applic) Printed circuit boards MAJOR COMPONENTS Outdoor unit clearances Outdoor unit condensate tray Outdoor unit condensate drain Outdoor unit fixing Indoor unit condensate tray Indoor unit condensate drain / pump... -
Page 17: General Maintenance
Failure to clean the filters regularly can cause condensation to form and drip from the indoor unit when operated in cooling mode during humid conditions. NOTE If you need more filters, please contact Rinnai. Rinnai Split AC T Series OM – Issue 3... -
Page 18: Save A Service Call
Remote control does not operate the Check for interference or obstructions that may be blocking the indoor unit� remote control signals, if interference or obstructions are not responsible then contact Rinnai� The air conditioner stops running� Check power supply or contact Rinnai. If a power failure has occurred. Turn off the air conditioner when a power failure occurs. When the power is restored, wait 3 minutes, ... -
Page 19: Warranty
WARRANTY TERMS OF WARRANTY – AUSTRALIA Rinnai Australia Pty� Ltd� ABN 74 005 138 769, 82-88 Mills Road, Braeside, Victoria, 3195� DEFINITIONS The terms listed below shall have the following meanings: “Authorised Service Representative” means an independent service contractor authorised by Rinnai or Rinnai service personnel� “Rinnai” means Rinnai Australia Pty Ltd (ABN 74 005 138 769) and any related company�... - Page 20 2�7 Rinnai will reimburse any reasonable costs associated with making a legitimate warranty claim against Rinnai which are not otherwise specified above. 2�8 The Warranty of the Product requires that, in addition to all other conditions, the Purchaser conducts regular and/or preventative maintenance as may be specified by the Operating/Installation Instructions or otherwise directed by Rinnai and required by the level of usage and the usage environment, including the use of correct and uncontaminated refrigerants and lubricants. Refrigeration, plumbing and electrical works must be undertaken by licensed personnel. 2�9 Where a Product or failed component is replaced under warranty, the time remaining on the original Product warranty period will continue to apply and the replacement product or part will be subject to the original ...
-
Page 21: Conditions Of Warranty
Warranty; and d) provides, in support of the claim made under this Warranty, a proof of date of completion of installation� 3�2 This document (and any statutory consumer guarantees) represents the only Warranty given by Rinnai in respect of the Product. No other person or organisation is authorised to offer any alternative warranty on ... -
Page 22: Travel, Transport & Access Costs
WARRANTY TRAVEL, TRANSPORT & ACCESS COSTS 6�1 The Purchaser must pay freight charges, in-transit insurance expenses and travelling costs for repairs/ replacements under this Warranty, that are required to be performed 50km from the nearest Rinnai branch or Authorised Service Representative� 6�2 Subject to clause 6.3, Rinnai will pay freight charges, in-transit insurance expenses and travelling costs for repairs/replacements that are required to be performed less than 50km from the nearest Rinnai branch or Authorised Service Representative, subject to the following: a) Rinnai will arrange for such repairs/replacements and make any payment directly to the third party to provide the freight, in-transit insurance or travel services; or b) if Rinnai considers appropriate, it will authorise the Purchaser in writing to pay for the relevant freight ... - Page 23 Ducted Gas Heaters, Refrigerated Air-Conditioning and Associated Appliances Warranty summary DEFINITIONS The terms listed below shall have the following meanings: “Authorised Service Agent” means an independent service contractor authorised by Rinnai or Rinnai service personnel� “Rinnai” means Rinnai New Zealand Ltd (Company Registration Number 94694) and any related company. “Certificate(s) of Compliance” means certificate(s) issued by licensed personnel (including plumbers, refrigeration mechanics, electricians or other relevant tradespeople) to certify that any prescribed works comply ...
-
Page 24: Warranty Terms And Conditions
After Market Spare Parts 1 Year 2�2 All Rinnai appliances meet or exceed the safety standards required by New Zealand gas and electrical regulations. The company is constantly improving its products and as such, specifications are subject to change or variation without notice. 2�3 For the purposes of the Consumer Guarantees Act 1993, Rinnai only guarantees the availability of repair facilities and spare parts for the express warranty period recorded in the table above. -
Page 25: Warranty Exclusions
Noise caused by minor contraction, movement or expansion of certain parts. g) Cost of building work to access parts that need repair or replacement, or the costs of building repairs afterwards. h) Subjective issues such as noise or smell that Rinnai have investigated (or a Rinnai service agent has investigated) and are established to be within normal operating parameters. PURCHASE DETAILS 5�1 Please keep these details in a safe place for future reference. ATTACH YOUR PROOF OF PURCHASE HERE:... - Page 26 NOTES Rinnai Split AC T Series OM – Issue 3...
- Page 27 NOTES Rinnai Split AC T Series OM – Issue 3...
-
Page 28: Contacts
Monday to Friday, 8.00 am to 5.00 pm EST. *Cost of a local call may be higher from a mobile phone. (National calls from public phones in Australia are free.) For further information visit www.rinnai.com.au or email enquiry@rinnai.com.au innai New Zealand Ltd...
