B650 EAGLE AX
B650 EAGLE
B650 UD AC
B650 UD AX
User's Manual
Rev. 1101
GIGABYTE will reduce paper use in order to ful ll the responsibilities of a global citizen.
Also, to reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.
For more product details, please visit GIGABYTE's website.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B650 EAGLE and is the answer not in the manual?

Questions and answers

Related Manuals for Gigabyte B650 EAGLE

Summary of Contents for Gigabyte B650 EAGLE

  • Page 1 User's Manual Rev. 1101 GIGABYTE will reduce paper use in order to ful ll the responsibilities of a global citizen. Also, to reduce the impacts on global warming, the packaging materials of this product are recyclable and reusable. GIGABYTE works with you to protect the environment.
  • Page 2 Information in this manual is protected by copyright laws and is the property of GIGABYTE. Changes to the speci cations and features in this manual may be made by GIGABYTE without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without GIGABYTE's prior written permission.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Product Introduction ..................4 Motherboard Layout ..................4 Box Contents ....................6 Chapter 2 Hardware Installation ..................7 Installation Precautions ..................7 Product Speci cations ..................8 Installing the CPU and CPU Cooler ............... 12 Installing the Memory ..................15 Installing an Expansion Card .................

  • Page 4: Chapter 1 Product Introduction

    ® PCIEX16 GbE LAN Chipset PCIEX1_1 CODEC M_BIOS PCIEX1_2 ® Super I/O PCIEX1_3 USB 2.0 Hub CLR_CMOS F_AUDIO QFLED SPI_TPM ARGB_V2_3 ARGB_V2_1 SYS_FAN2 F_USB3 F_USB1 ESPI_DB QFLASH_PLUS F_USB2 F_PANEL Temperature sensor j Only for B650 EAGLE AX. - 4 -...
  • Page 5 SYS_FAN1 LED_C CPU_OPT CPU_FAN ATX_12V DP_HDMI KB_MS_USB SOCKET AM5 USB 2.0 Hub USB20 M2_WIFI U32C U32G2 USB_LAN AUDIO Realtek ® PCIEX16 GbE LAN Chipset PCIEX1_1 CODEC M_BIOS PCIEX1_2 ® Super I/O PCIEX1_3 USB 2.0 Hub CLR_CMOS F_AUDIO QFLED SPI_TPM ARGB_V2_3 SYS_FAN2 F_USB3 F_USB1...

  • Page 6: Box Contents

    Box Contents 5 B650 EAGLE AX, B650 EAGLE, B650 UD AC, or B650 UD AX motherboard 5 User's Manual 5 Two antennas jlm 5 I/O Shield lm 5 Two SATA cables 5 M.2 screw j Only for B650 EAGLE AX.

  • Page 7: Chapter 2 Hardware Installation

    Chapter 2 Hardware Installation Installation Precautions The motherboard contains numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user's manual and follow these procedures: • Prior to installation, make sure the chassis is suitable for the motherboard. •...

  • Page 8: 2-2 Product Speci Cations

    Š AMD Ryzen 7000 Series Processors/ ™ AMD Ryzen 8000 Series Processors ™ (Go to GIGABYTE's website for the latest CPU support list.) Chipset AMD B650 Š Memory Support for DDR5 5200/4800/4400 MT/s memory modules Š 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) Š...
  • Page 9 Wireless Realtek Wi-Fi 6 RTL8851BE Š ® Communication WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands BLUETOOTH 5.3 Module m Support for 11ax 80MHz wireless (Actual data rate may vary depending on environment and equipment.) Expansion Slots Š...
  • Page 10 * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install. (Note) Actual support may vary by CPU. j Only for B650 EAGLE AX. k Only for B650 EAGLE. l Only for B650 UD AC. m Only for B650 UD AX.
  • Page 11 ATX Form Factor; 30.5cm x 24.4cm Form Factor Š * GIGABYTE reserves the right to make any changes to the product speci cations and product-related information without prior notice. & Please visit the SERVICE/SUPPORT\Utility page on GIGABYTE's website to download the latest version of apps.

  • Page 12: Installing The Cpu And Cpu Cooler

    Read the following guidelines before you begin to install the CPU: • Make sure that the motherboard supports the CPU. (Go to GIGABYTE's website for the latest CPU support list.) • Always turn off the computer and unplug the power cord from the power outlet before installing the CPU to prevent hardware damage.

  • Page 13: Installing The Cpu

    B. Installing the CPU Follow the steps below to correctly install the CPU into the motherboard CPU socket. j G ently press the CPU socket lever handle down and away from the socket. k C ompletely lift up the CPU socket lock- ing lever.

  • Page 14: Installing The Cpu Cooler

    C. Installing the CPU Cooler Be sure to install the CPU cooler after installing the CPU. (Actual installation process may differ depending the CPU cooler to be used. Refer to the user's manual for your CPU cooler.) Apply an even and thin layer of thermal grease on the surface of the installed CPU.

  • Page 15: Installing The Memory

    Read the following guidelines before you begin to install the memory: • Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used. (Go to GIGABYTE's website for the latest supported memory speeds and memory modules.) •...

  • Page 16: Installing An Expansion Card

    Installing an Expansion Card Read the following guidelines before you begin to install an expansion card: • Make sure the motherboard supports the expansion card. Carefully read the manual that came with your expansion card. • Always turn off the computer and unplug the power cord from the power outlet before installing an expansion card to prevent hardware damage.

  • Page 17: Back Panel Connectors

    USB ash drive into this port rst. (Note 1) Actual support may vary by CPU. (Note 2) To enable the Q-Flash Plus function, please navigate to the "Unique Features" page of GIGABYTE's website for more information. j Only for B650 EAGLE AX.
  • Page 18 You can change the functionality of an audio jack using the audio software. To con gure 7.1-channel audio, access the audio software for audio settings. & Please visit GIGABYTE's website for details on con guring the audio software. https://www.gigabyte.com/WebPage/697/realtek897-audio.html • When removing the cable connected to a back panel connector, rst remove the cable from your device and then remove it from the motherboard.

  • Page 19: Onboard Button And Leds

    BIOS ashing is complete. QFLED QFLASH_PLUS To enable the Q-Flash Plus function, please navigate to the "Unique Features" page of GIGABYTE's website for more information. Status LEDs jk The status LEDs show whether the CPU, memory, graphics card, and operating system are working properly after system power-on.

  • Page 20: Internal Connectors

    • After installing the device and before turning on the computer, make sure the device cable has been securely attached to the connector on the motherboard. j Only for B650 EAGLE AX. k Only for B650 EAGLE. - 20 -...
  • Page 21 1/2) ATX_12V/ATX (2x4 12V Power Connector and 2x12 Main Power Connector) With the use of the power connector, the power supply can supply enough stable power to all the components on the motherboard. Before connecting the power connector, rst make sure the power supply is turned off and The power connector possesses a foolproof design.
  • Page 22 For optimum heat dissipation, it is recommended that a system fan be installed inside the chassis. The header also provides speed control for a water cooling pump. Please navigate to the "BIOS Setup" page of GIGABYTE's website and search for "Smart Fan 6" for more information. Pin No. De nition...
  • Page 23 LED strip. For how to turn on/off the lights of the LED strip, please navigate to the "Unique Features" page of GIGABYTE's website. Before installing or removing the devices, be sure to turn off the devices and your computer. Unplug the power cord from the power outlet to prevent damage to the devices.
  • Page 24 1.5Gb/s standard. Each SATA connector supports a single SATA device. The SATA connectors support RAID 0, RAID 1, and RAID 10. Please navigate to the "Con guring a RAID Set" page of GIGABYTE's website for instructions on con guring a RAID array.
  • Page 25 M.2 PCIe SSDs. Please note that an M.2 PCIe SSD cannot be used to create a RAID set with a SATA hard drive. Please navigate to the "Con guring a RAID Set" page of GIGABYTE's website for instructions on con guring a RAID array.
  • Page 26 Connects to the power switch on the chassis front panel. You may con gure the way to turn off your system using the power switch (please navigate to the "BIOS Setup" page of GIGABYTE's website and search for "Soft-Off by PWR-BTTN" for more information).
  • Page 27 12) F_AUDIO (Front Panel Audio Header) The front panel audio header supports High De nition audio (HD). You may connect your chassis front panel audio module to this header. Make sure the wire assignments of the module connector match the pin assignments of the motherboard header.
  • Page 28 14) F_U32 (USB 3.2 Gen 1 Header) The header conforms to USB 3.2 Gen 1 and USB 2.0 speci cation and can provide two USB ports. For purchasing the optional 3.5" front panel that provides two USB 3.2 Gen 1 ports, please contact the local dealer.
  • Page 29 You may connect an SPI TPM (Trusted Platform Module) to this header. Pin No. De nition Data Output Power (1.8V) No Pin Data Input Chip Select j Only for B650 EAGLE AX. k Only for B650 EAGLE. - 29 -...
  • Page 30 CMOS values. • After system restart, go to BIOS Setup to load factory defaults (select Load Optimized Defaults) or manually con gure the BIOS settings (please navigate to the "BIOS Setup" page of GIGABYTE's website for more information). - 30 -...

  • Page 31: Chapter 3 Bios Setup

    If this occurs, try to clear the CMOS values and reset the board to default values. • Refer to the introductions of the battery/clear CMOS jumper in Chapter 2 or navigate to the "BIOS Setup" page of GIGABYTE's website and search for "Load Optimized Defaults" for how to clear the CMOS values.
  • Page 32 Startup Screen: The following startup Logo screen will appear when the computer boots. Function Keys Function Keys: <DEL>: BIOS SETUP\Q-FLASH Press the <Delete> key to enter BIOS Setup or to access the Q-Flash utility in BIOS Setup. <F12>: BOOT MENU Boot Menu allows you to set the rst boot device without entering BIOS Setup.

  • Page 33: Chapter 4 Installing The Operating System And Drivers

    Step 1: Go to GIGABYTE's website, browse to the motherboard model's web page, download the AMD RAID Preinstall Driver le on the Support\Download\SATA RAID/AHCI page, unzip the le and copy the les to your USB thumb drive.

  • Page 34: Drivers Installation

    After you install the operating system, a dialog box will appear on the bottom-right corner of the desktop asking if you want to download and install the drivers and GIGABYTE applications via GIGABYTE Control Center (GCC). Click Install to proceed with the installation. (In BIOS Setup, make sure Settings\IO Ports\Gigabyte Utilities Downloader Con guration\Gigabyte Utilities Downloader is set to Enabled.)

  • Page 35: Chapter 5 Appendix

    • A USB thumb drive. An M.2 PCIe SSD cannot be used to set up a RAID set with a SATA hard drive. & Please visit GIGABYTE's website for details on con guring a RAID array. https://www.gigabyte.com/WebPage/918/amd600-raid.html - 35 -...

  • Page 36: Regulatory Notices

    47 CFR § 2.1077 Compliance Information Product Name: Motherboard Trade Name: GIGABYTE Model Number: B650 EAGLE AX/B650 EAGLE/B650 UD AC/B650 UD AX Responsible Party – U.S. Contact Information: G.B.T. Inc. Address: 17358 Railroad street, City Of Industry, CA91748 Tel.: 1-626-854-9338 Internet contact information: https://www.gigabyte.com...
  • Page 37 European Union (EU) Community Waste Electrical & Electronic Urządzenie jest zgodne z następującymi dyrektywami: Dyrektywa Equipment (WEEE) Directive Statement GIGABYTE will ful ll the national laws as interpreted from the 2012/19/ kompatybilności elektromagnetycznej 2014/30/UE, Dyrektywa EU WEEE (Waste Electrical and Electronic Equipment) (recast) directive.
  • Page 38 To identify your Motherboard version or revision number, look for "REV: X.X" printed on the PCB on the top left corner of the Motherboard. For example, "REV:1.0" means the revision of the motherboard is 1.0. Motherboard revision no.: Wireless module manufacturer, model name: Realtek Semiconductor Corp. RTL8852CE B650 EAGLE AX rev. 1.0 Corporation AX210NGW B650 EAGLE AX rev. 1.1 ® Intel B650 UD AC rev.
  • Page 39 Approvals for wireless module RTL8851BE: Approvals for wireless module AX210NGW: - 39 -...

  • Page 40: Contact Us

    Contact Us GIGA-BYTE TECHNOLOGY CO., LTD. Address: No.6, Baoqiang Rd., Xindian Dist., New Taipei City 231 TEL: +886-2-8912-4000, FAX: +886-2-8912-4005 Tech. and Non-Tech. Support (Sales/Marketing) : https://esupport.gigabyte.com WEB address (English): https://www.gigabyte.com WEB address (Chinese): https://www.gigabyte.com/tw • GIGABYTE eSupport To submit a technical or non-technical (Sales/Marketing) question, please link to: https://esupport.gigabyte.com...
