OM-296176C
2024-02
Auto-
Darkening
Weld-Mask™
With ClearLight™
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Auto-Darkening Weld-Mask and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Miller Auto-Darkening Weld-Mask

Summary of Contents for Miller Auto-Darkening Weld-Mask

  • Page 1 OM-296176C 2024-02 Auto- Darkening Weld-Mask™ With ClearLight™ OWNER’S MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION 1 – SAFETY PRECAUTIONS – READ BEFORE USING......1 Symbol Usage ............. 1 Arc Welding Hazards .

  • Page 3: Section 1 - Safety Precautions - Read Before Using

    SECTION 1 – SAFETY PRECAUTIONS – READ BEFORE USING Protect yourself and others from injury—read, follow, and save these important safety precautions and operating instructions. 1-1. Symbol Usage DANGER! – Indicates a hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 4: Noise Can Damage Hearing

    � Wear body protection made from leather or flame-resistant clothing (FRC). Body protection in- cludes oil-free clothing such as leather gloves, heavy shirt, cuffless trousers, high shoes, and a cap. � Before welding, adjust the auto-darkening lens sensitivity setting to meet the application. �...

  • Page 5: Lens Shade Selection Table

    � Read and understand the Safety Data Sheets (SDSs) and the manufacturer’s instructions for adhesives, coatings, cleaners, consumables, coolants, degreasers, fluxes, and metals. � Work in a confined space only if it is well ventilated, or while wearing an air-supplied respirator. Always have a trained watchperson nearby.

  • Page 6: California Proposition 65 Warnings

    1-4. California Proposition 65 Warnings WARNING – Cancer and Reproductive Harm — www.P65Warnings.ca.gov. 1-5. Principal Safety Standards Safety in Welding, Cutting, and Allied Processes, American Welding Society standard ANSI Standard Z49.1. Website: www.aws.org. Safe Practice For Occupational And Educational Eye And Face Protection, ANSI Standard Z87.1, from American National Standards Institute.

  • Page 7: Section 2 - Consignes De Sécurité - Lire Avant Utilisation

    SECTION 2 – CONSIGNES DE SÉCURITÉ - LIRE AVANT UTILISATION Pour écarter les risques de blessure pour vous-même et pour autrui — lire, appliquer et ranger en lieu sûr ces consignes relatives aux précautions de sécurité et au mode opératoire. 2-1.
  • Page 8 � Porter des lunettes de sécurité approuvées avec écrans latéraux sous votre casque. Celles-ci ne sont pas requises avec des de lunettes de soudage à coques à opacité autoréglée; ces dernières sont conformes aux exigences de protection de la vue de la norme ANSI Z87.1. �...

  • Page 9: Tableau De Sélection Du Vignettage

    LES FUMÉES ET LES GAZ peuvent être dangereux. Le soudage génère des fumées et des gaz. Leur inhalation peut être dange- reux pour votre santé. � Eloigner votre tête des fumées. Ne pas respirer les fumées. � À l’intérieur, ventiler la zone et/ou utiliser une ventilation forcée au niveau de l’arc pour l’éva- cuation des fumées et des gaz de soudage.

  • Page 10: Proposition Californienne 65 Avertissements

    Classe de N° de classe Taille d'électrode Courant d'arc protection Procédé de protection in. (mm) en ampères suggérée minimum (Comfort)* 40–60 60–80 80–300 300–400 400–800 Moins de 20 6–8 20–100 Soudage à l'arc plasma (PAW) 100–400 400–800 Référence: ANSI Z49.1:2021 *Commencer par une classe de protection trop foncée pour voir la zone de soudage.

  • Page 11: Section 3 - Specifications

    SECTION 3 – SPECIFICATIONS Applications Arc Welding, Grinding Viewing Field 4.39 in (28.3225 CM Operating Modes Two: Welding and Grinding Reaction Time 0.0000666 sec (1/15,000) Darkened State: Shade No. 9–13 Available Shades Light State: No. 3.0 All Shades Provide Goggles can be used for grinding in light state (passive Continuous UV And mode) only when used with customer-supplied face shield.

  • Page 12: Section 4 - Operation

    SECTION 4 – OPERATION 4-1. Auto-Darkening Goggle Components The auto-darkening goggles provide Before using the auto-darkening eye protection only. Use additional goggles, remove the protective cov- personal protection equipment (arc ers from the inside of the auto-dark- shield, face shield, balaclava, hard ening lenses.

  • Page 13: Power / Grind Button And Low Battery Led

    4-2. Power / Grind Button and Low Battery LED 1 Power / Grind Button Lens turns off automatically if not used for 30 minutes. 2 Shade Indicator LEDs Do not use the weld-mask if the lens does Use button to turn lens on and off. To turn on not function as described.

  • Page 14: Variable Shade Control

    4-3. Variable Shade Control Shade Adjustment 1 Delay Control Button 2 Sensitivity Control Button � Turn lens on. 3 Shade Control Button � Press Shade Control button to select desired shade. Shade selection is indi- Press the Shade Control button to adjust the cated by numbered LEDs on control lens shade in the darkened state.

  • Page 15: Sensitivity Control

    4-4. Sensitivity Control 1 Sensitivity Control Button Use Sensitivity control to make the lens more respon- sive to different light levels in various welding processes. Use a mid-range or 30-50% sensitivity setting for most applications. It may be nec- essary to adjust weld-mask sensitivity to accommodate different lighting conditions or if lens is flashing on and off.

  • Page 16: Section 5 - Installing Replacement Parts

    SECTION 5 – INSTALLING REPLACEMENT PARTS 5-1. Replacing Lens Cover Never use the auto- darkening lens with- out the lens cover properly installed. Welding spatter will damage auto- darkening lens and void the warranty. 1 Goggles 2 Shield 3 Release Tab 4 Frame Slot 5 Protection Film 6 Cover Lens...

  • Page 17: Inserting Optical Lens Frame

    5-2. Inserting Optical Lens Frame 1 Slot 2 Tab 3 Optical Lens Frame Insert customer supplied cor- rective lens in frame. Install lens frame tab in slot on sili- cone skirt as shown. Press optical lens frame into groove around perimeter of auto- darkening lens frame.

  • Page 18: Replacing Anti-Fog Lens

    5-4. Replacing Anti-Fog Lens 1 Old Anti-Fog Lens 2 Inner Lens Step 1. Use tab to pull exist- ing anti-fog lens and clean the inner lens. 3 New Anti-Fog Lens 4 Protective Film (Red Tab) Step 2. Carefully peel the pro- tective film with red tab from the rear side of the new anti- fog lens.

  • Page 19: Replacing Battery

    5-5. Replacing Battery 1 Battery Cover 2 Batteries Loosen screw securing bat- tools/ tery cover. Remove cover. Press (click) battery holder to release batteries. Remove batteries Replace with CR2032 lithium batteries required) equivalent � Be sure Positive (+) side of the batteries faces up. rubbergloves weldgloves earmuffs...

  • Page 20: Section 6 - Maintenance And Troubleshooting

    SECTION 6 – MAINTENANCE AND TROUBLESHOOTING 6-1. Maintenance NOTICE – Do not use solvents or abrasive cleaning detergents to clean the weld-mask. Do not immerse the lens assembly in water. NOTICE – Keep weld-mask dry; do not expose weld-mask to rain or snow. Keep weld-mask away from fire and other sources of heat.

  • Page 21: Troubleshooting

    6-2. Troubleshooting Trouble Remedy Auto lens not On – LEDs Press and hold On-Off button until all five Shade indicator LEDs do not flash momentarily blink (about two seconds). when the On-Off button Check batteries and verify they are in good condition and installed is pressed.

  • Page 22: Section 7 - Parts List

    SECTION 7 – PARTS LIST Figure . Auto-Darkening Weld-Mask with ClearLight Item No. Part No. Description 296265 Face Guard ADF Goggle CL 268270 Warning ADF Goggle−Large 295918 Lens Cover, ADF Goggle, WM CL 295921 Eye Skirt, Silicone, WM CL 280273...

  • Page 23: Section 8 - Limited Warranty

    Miller. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANT- ABILITY AND FITNESS.
  • Page 24 For product information, Owner’s Manual translations, and more, visit www.MillerWelds.com ORIGINAL INSTRUCTIONS – PRINTED IN USA © Miller Electric Mfg. LLC 2024-02...
